Поз.
Артикул
Описание
141
SUPPORT RADIATOR BASE FRAME
144
PART NAME MISSING. VALVE , Replaced By: A3645007827
144
SUPPORT LEFT
147
BEARING BODY FAN DRIVE
150
FAN SHAFT
153
ANG. CONTACT BALL BEARING FAN DRIVE
156
RADIAL SEAL RING
159
SPACER TUBE
162
SPACER WASHER
165
LOCK RING52X2 MM
168
SPACER TUBE
171
LOCK PLATE SHACKLE TO CONSOLE A 24,393379
174
NUT SHACKLE TO CONSOLE,393379
177
SEAL RING PNEUMATIC VALVE
180
SCREW PLUG
183
WOODRUFF KEY POWER STEERING PUMP
186
PULLEY
189
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
192
NUT , Replaced By: N308675014000
195
SCREW AIR DUCT TO CAB
198
LOCK WASHER RAIL TO BATTERY SUPPORT
201
WASHER TRAILER PLUG SOCKET TO BRACKET
204
FAN
207
LOCK
210
SCREW PLUG SOCKET TO FRAME
213
RUBBER STRIP TOP
216
RUBBER STRIP RADIATOR TO SUPPORT
219
SCREW CLUTCH TO FLYWHEEL M8X18,4 188090-4 277323
221
LOCK WASHER RAIL TO BATTERY SUPPORT
223
BUFFER REAR
225
SCREW REAR EXHAUST PIPE TO CONSOLE M 12X25,600893617872
227
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
229
HEX. NUT M 12 DIN 934-5 S. NUT , Replaced By: N000934012021
231
SCREW , Replaced By: N304017010040
233
LOCK WASHER , Replaced By: N912004010102
235
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
447
V-BELT
999
HOSE FROM RADIATOR TO OIL COOLER 210 MM,617872
999
999
WASHER BRACKET TO FRAME
999
COTTER PIN6.3X63 MM
999
999
999
SUPPORT RIGHT
999
VALVE
999
SHIM
999
PART NAME MISSING , Replaced By: A3645007927
999
SCREW ,D 027195
999
PULLEY , Replaced By: A3552050210
999
V-BELT SET2 PIECES 12.5X1950 MM
999
V-BELT , Replaced By: A0039974992
