Поз.
Артикул
Описание
20
CLAMP
101
BRACKET. LOCK , Replaced By: A6525040038
135
ANGLE LEFT AND RIGHT BRAKE HOSES
137
HEX. HEAD. SCREW TRANSMISSION CASE TOP COVER TO TRANSMISSSION CASE, UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
139
LOCK WASHER RAIL TO BATTERY SUPPORT
141
NUT LEVER TO SHIFTING SHAFT
142
BRACKET. LOCK , Replaced By: A6525040038
167
LINE FROM MASTER CYLINDER TO INTERMEDIATE PIECE 6X0.7 MM, 364.101 UP TO CHASSIS 37067, 364.111 UP TO CHASSIS 38387, 364.152 UP TOCHASSIS 36729, 364.162 UP TO CHASSIS 36745, 364.173 UP TO CHASSIS 36748
167
LINE FROM MASTER CYLINDER TO INTERMEDIATE PIECE 6X0.7 MM, 364.101 UP TO CHASSIS 37067, 364.111 UP TO CHASSIS 38387, 364.152 UP TOCHASSIS 36729, 364.162 UP TO CHASSIS 36745, 364.173 UP TO CHASSIS 36748
168
UNION SCREW , Replaced By: A0004280072
168
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
169
CLAMP LINE TO SIDE MEMBER
170
SCREW COMPRESSED AIR LINE MOUNTING
171
WASHER5,3
172
LOCK WASHER PLUG SOCKET
173
NUT TACHOGRAPH TO BRACKET
174
HOSE , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
175
LOOM TIE , Replaced By: A3459977390
175
LOOM TIE ELECTRIC CABLE MOUNTING
180
CONNECTOR OIL DELIVERY LINE
180
CONNECTOR
183
LINE FROM INTERMEDIATE PIECE TO INTERMEDIATE PIECE 6X0.7 MM
183
LINE FROM INTERMEDIATE PIECE TO INTERMEDIATE PIECE 6X0.7 MM, 364.101 UP TO CHASSIS 37067, 364.111 UP TO CHASSIS 38387, 364.152 UP TOCHASSIS 36729, 364.162 UP TO CHASSIS 36745, 364.173 UP TO CHASSIS 36748
185
UNION SCREW , Replaced By: A0004280072
185
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
191
CONNECTOR OIL DELIVERY LINE
191
CONNECTOR
195
LINE FROM CONNECTOR II TO BRAKE HOSE 6X0.7 MM,D 037447
195
LINE FROM INTERMEDIATE PIECE TO INTERMEDIATE PIECE 6X0.7 MM, 364.101 UP TO CHASSIS 37067, 364.111 UP TO CHASSIS 38387, 364.152 UP TOCHASSIS 36729, 364.162 UP TO CHASSIS 36745, 364.173 UP TO CHASSIS 36748
197
UNION SCREW , Replaced By: A0004280072
197
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
201
BRAKE HOSE , Replaced By: A0014287435
201
BRAKE HOSE , Replaced By: A3644287335
201
BRAKE HOSE
201
BRAKE HOSE BETWEEN THE LINES
201
BREMSSCHLAUCH F 380 LANG. BRAKE HOSE FRONT WHEEL BRAKE CYLINDER
201
BRAKE HOSE
205
BRACKET
207
BRACKET. LOCK , Replaced By: A6525040038
209
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
209
DISTRIBUTOR REAR AXLE
211
BRACKET
213
SCREW POWER CYLINDER TO BEARING BRACKET
215
LOCK WASHER RAIL TO BATTERY SUPPORT
217
NUT LEVER TO SHIFTING SHAFT
219
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL 6X0.7 MM,D 037447
219
LINE FROM DISTRIBUTOR TO LEFT REAR WHEEL 6X0.7 MM,D 037447
220
LINE FROM DISTRIBUTOR TO RIGHT REAR WHEEL 6X0.7 MM, 364.101 FROM CHASSIS 37068, -364.111 FROM CHASSIS 38388, -364.152 FROM CHASSIS 36730, -364.162 FROM CHASSIS 35746, -364.173 FROM CHASSIS 36749
221
UNION SCREW , Replaced By: A0004280072
221
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
223
CLAMP BRAKE LINE MOUNTING
225
HOSE BRAKE LINE TO REAR AXLE,4 644238
227
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
229
LOCK WASHER RAIL TO BATTERY SUPPORT
999
VALVE"WABCO DO BRASIL", USED WITH AIR BRAKE
999
WASHERTO 344 430 73 01,002 430 27 01
999
CUPTO 344 430 73 01,002 430 27 01
999
PRESSURE REGULATOR"WABCO",486597
999
WASHERTO 002 430 71 01
999
VALVE , Replaced By: A0004320807
999
ELBOW FITTING
999
DISTRIBUTORTO 345 430 73 01
999
HOLLOW SCREW DISTRIBUTOR TO MASTER CYLINDER
999
LOOM TIE. CLAMP HOSE TO HEATING PIPE
999
REPAIR KITTO 000 429 28 44
999
999
BRACKET HAND-BRAKE/TRAILER-BRAKE COMPRESSEDAIR LINE
999
CONSOLE
999
999
THRUST RING LOCKING VALVE
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RING17.12X2.62 MM, 402,407 FROM CHASSIS 657000
999
PISTON
999
CUP , Replaced By: A3454317286
999
CUPTO 344 430 73 01
999
WASHER , Replaced By: A3454317376
999
WASHER , Replaced By: A3454317076
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
999
SEAL RING , Replaced By: A0179974148
999
LOCKTO 345 431 70 05
999
LOCK , Replaced By: N000472047001
999
LOCK , Replaced By: N000984038000
999
LOCK , Replaced By: N000472045000
999
LOCK , Replaced By: N000472060000
999
REPAIR KIT SMALL SCOPE TO 345 430 73 81
999
SEAL RING
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
999
FITTING
999
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
FITTING , Replaced By: A0039978972
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
SPRINGTO 000 429 63 44,000 429 59 44
999
REPAIR KITBOSCH
999
PRESSURE REGULATOR"KNORR",FB486598 USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
SPRINGTO 345 431 71 05
999
SPRINGTO 001 431 83 05
999
SPRINGTO 345 431 70 05
999
SPRINGTO 345 431 70 05
999
SPRINGTO BOSCH-NR.0481 027 024
999
CUP101
999
CUPTO BOSCH-NR.0481 027 104
999
CUP , Replaced By: A0014312386
999
REPAIR KIT SMALL SCOPE TO 000 434 30 01
999
REPAIR KIT , Replaced By: A0004304106
999
REPAIR KIT SMALL SCOPE TO 345 431 70 05
999
VALVE (OVERFLOW VALVE) GRAU
999
VALVE (OVERFLOW VALVE) WABCO
999
VALVE (OVERFLOW VALVE) BOSCH
999
HANDLETO 345 430 73 81
999
HANDLETO 000 434 23 01
999
FITTING
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
SPRINGWABCO,002 0,012 0
999
SPRING
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
REPAIR KIT , Replaced By: A0004305760
999
GASKETTO 000 429 16 30
999
CUP 3/2-WAY VALVE WABCO
999
CUPTO 000 431 76 14
999
PISTONTO 345 431 70 05
999
PISTONTO 002 431 27 05
999
PISTONTO 002 431 27 05
999
PISTONTO 345 431 71 05
999
PISTONTO 001 431 83 05,WABCO
999
FILLER CAP
999
VALVEWABCO,002 0,012 0
999
CUPBOSCH
999
SEAL RING
999
FILLER RINGTO 001 431 83 05,WABCO
999
PROTECTIVE CAP BRAKE BOOSTER
999
BREATHER PIPETO 001 431 83 05,WABCO
999
999
REPAIR KIT , Replaced By: A0004304206
999
REPAIR KITTO 000 430 55 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT LARGE SCOPE TO 345 431 70 05
999
REPAIR KIT LARGE SCOPE TO 000 434 30 01
999
999
VALVE (OVERFLOW VALVE) WESTINGHOUSE
999
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
999
DIAPHRAGMTO 001 429 48 44
999
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
999
SPRING RETAINERTO 000 429 63 44,000 429 59 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
CONNECTOR
999
HOLLOW SCREW
999
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
999
REPAIR KITTO 001 431 98 06
999
CLAMP HOSE TO FITTING AND TO OIL TANK
999
CLAMP LINE MOUNTING
999
CLAMP COMPRESSED AIR LINE MOUNTING
999
THRUST RING BUTT SCREW CONNECTION
999
SEAL RING LINE CONNECTION
999
SEAL RING , Replaced By: N007603012121
999
UNION NUT BUTT SCREW CONNECTION
999
UNION NUT LINE CONNECTION
999
UNION NUT
999
UNION NUT
999
NUT BRACKET TO SIDE MEMBER,XB209706
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
FITTING
999
FITTING AIR RESERVOIR,CONNECTION: "2"
999
NUT CHECK VALVE TO AIR RESERVOIR
999
INSULATING HOSE BLACK 12 X 0,8 MM
999
WASHER , Replaced By: N009021006208
999
SCREW CABLE TO ALTERNATOR
999
SCREW CAP TO BRACKET
999
SHEET METAL SCREW COMPRESSED AIR LINE MOUNTING
999
SEAL RING BOTTOM
999
SEAL RING LINE CONNECTION
999
SEAL RING TO MOUNT FUEL LINES 16X22 - TO A 688 470 00 90
999
CONNECTION FITTING ,880809
999
GLAND LINE CONNECTION
999
GLAND LINE CONNECTION
999
GLAND , Replaced By: A0019901667
999
TURNBUCKLE , Replaced By: A3859960034
999
LOCK RINGTO 345 431 71 05
999
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
999
NUT PULL ROD
999
HEX, NUT. NUT L.H. THREAD
999
NUT
999
SCREW PISTON ROD TO CLUTCH PEDAL
999
SCREW PLUG SOCKET TO FRAME
999
SCREW BRACKET TO SIDE MEMBER,A 069681
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
LOCK RING PLANETARY CARRIER
999
LOCK RING
999
LOCK RINGTO 345 431 71 05
999
SPRING WASHER CAB FLOOR
999
SPRING WASHER CABLE TO ALTERNATOR
999
LOCK WASHER , Replaced By: N912004010102
999
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
999
WASHER TRAILER PLUG SOCKET TO BRACKET
