Поз.
Артикул
Описание
10
TRIM BUMPER FRONT BUMPER, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT212L9000 COLORLESS
10
PANELING FRONT BUMPER, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT212L9000 COLORLESS
10
TRIM BUMPER FRONT BUMPER, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT212L9000 COLORLESS
10
PANELING FRONT BUMPER, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT212L9000 COLORLESS
10
TRIM BUMPER FRONT BUMPER, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT212L9000 COLORLESS
15
BLIND RIVET AT COVERING
30
COVER TOWING EYE TOWING EYE, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT212L9000 COLORLESS
30
CAP TOWING EYE
40
RAIL LEFT
40
RAIL RIGHT
45
ENGINE HOOD SEAL FOR ENGINE HOOD
60
BASIC MOUNTING FOR BUMPER BOTTOM, CENTER
60
BASIC MOUNTING FOR BUMPER BOTTOM, CENTER
60
FRAME CENTRAL
60
FRAME CENTRAL
70
BASIC MOUNTING FOR BUMPER LEFT BOTTOM
70
BASIC MOUNTING FOR BUMPER RIGHT BOTTOM
70
BASIC MOUNTING FOR BUMPER LEFT BOTTOM
70
BASIC MOUNTING FOR BUMPER RIGHT BOTTOM
75
COVER BUMPER AREA GRILLE CENTER, RIGHT
75
COVER BUMPER AREA GRILLE CENTER, LEFT
78
BLIND RIVET AT COVERING
80
BASIC MOUNTING FOR BUMPER CENTRAL
80
BASIC MOUNTING FOR BUMPER CENTRAL
80
BASIC MOUNTING FOR BUMPER CENTRAL
85
RIVET SEALING LIP TO RADIATOR
90
ENERGY-ABSORBING UNIT CENTRAL
90
IMPACT ABSORBER CENTRAL
90
IMPACT ABSORBER CENTRAL
200
COVER BUMPER AREA BOTTOM, CENTER
200
COVER BUMPER AREA BOTTOM, CENTER
200
COVER
200
COVER BUMPER AREA BOTTOM, CENTER
207
ORNAMENTAL MOLDING UNDER AIR INLET GRILLE AT FRONT CENTER
208
ORNAMENTAL MOLDING UNDER CENTER AIR INLET GRILL
209
ORNAMENTAL MOLDING UNDER LEFT AIR INLET GRILL
209
ORNAMENTAL MOLDING UNDER RIGHT AIR INLET GRILL
213
EXPANSION RIVET BRACKET MOUNTING
215
COVER BUMPER AREA BOTTOM, RIGHT
215
COVER BUMPER AREA BOTTOM, RIGHT
215
COVER BUMPER AREA BOTTOM LEFT
215
COVER BUMPER AREA BOTTOM LEFT
225
MOULDING ON LEFT COVERING
225
MOULDING ON RIGHT COVERING
227
COVER BUMPER AREA GRILLE RIGHT
227
COVER BUMPER AREA GRILLE LEFT
235
COVER BUMPER AREA BOTTOM LEFT
235
COVER BUMPER AREA BOTTOM, RIGHT
245
COVER BUMPER AREA SIGHTPROOFING, BOTTOM RIGHT
245
COVER BUMPER AREA SIGHTPROOFING, BOTTOM LEFT
247
TAPPING SCREW CENTRAL HOUSING TO BRACKET 3.5X22,F 029921
249
SPRING NUT
370
LICENSE PLATE MOLDING
370
LICENSE PLATE MOLDING
370
LICENSE PLATE MOLDING
380
SHEET METAL SCREW ORNAMENTAL COVER TO BUMPER
385
NUT. RIVETED NUT PAN HEAD WITH CLAMPING RANGE: M6X2.4-4.5,V 207570
385
LOCK NUT. LOCK PANELLING TO BUMPER
410
SCREW BRACKET TO COVERING
420
BOLT WIPER MOTOR TO REAR PANEL DOOR M6X24
430
TAPPING SCREW BRACKET TO CAB REAR PANEL 6.3X16
440
LOCK NUT. SPRING NUT HEADLINER TO BODY
450
TAPPING SCREW , A 192209 ALSO INSTALLED ON A 159651 - A 192207 WITH CODE 805 FROM MODEL YEAR'95
460
LOCK INSTRUMENT PANEL TO PANELLING
465
ELECTRICAL WIRING HARNESS
465
ELECTRICAL WIRING HARNESS
465
ELECTRICAL WIRING HARNESS , L 11715620130831
470
DISTANCE SENSOR OUTSIDE LEFT AND RIGHT, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT246L9000 COLORLESS
470
DISTANCE SENSOR INSIDE LEFT AND RIGHT, TO BE PAINTED PRIOR TO INSTALLATION 9999QFT246L9000 COLORLESS
480
DECOUPLING RING PARKTRONIC SYSTEM
520
RADAR SENSOR PROXIMITY-CONTROLLED CRUISE CONTROL, PART MUST BE CHECKED AFTER INSTALLATION FOR CURRENT FLASHWARE
520
RADAR SENSOR , PART MUST BE CHECKED AFTER INSTALLATION FOR CURRENT FLASHWARE
520
RADAR SENSOR , PART MUST BE CHECKED AFTER INSTALLATION FOR CURRENT FLASHWARE
530
BRACKET RADAR SENSOR
