Поз.
Артикул
Описание
10
REAR SUBFRAME WITH RUBBER MOUNTING
20
RUBBER MOUNT FRONT SUBFRAME CARRIER
30
RUBBER MOUNT CHASSIS SUBFRAME MOUNTING REAR
40
SPRING CONTROL ARM SSP. SPRING CONTROL ARM TO REAR SUBFRAME
40
SPRING CONTROL ARM SSP. SPRING CONTROL ARM TO REAR SUBFRAME
50
RUBBER MOUNT AXLE HOUSING TO REAR SUBFRAME,REAR
60
CROSS MEMBER CROSS STABILIZER FRONT
70
RUBBER MOUNT AXLE HOUSING TO REAR SUBFRAME,REAR
80
NUT LINKAGE TO REAR AXLE M10, J 45136320070307
80
MULTIPLE NUT CROSS STABILIZER FRONT TO SIDE ELEMENT
85
HEXAGON HEAD BOLT BRACKET TO DISTRIBUTOR
90
ADAPTER DRIVE SUPPORT ON REAR AXLE TRANSVERE CASING, A 20140131
90
EXTENSION ON REAR AXLE TRANSVERE CASING, A 20140131
100
STOP FRONT LEFT SUBFRAME CARRIER
100
STOP FRONT RIGHT SUBFRAME CARRIER
110
COMBINATION BOLT REAR SUBFRAME TO FRAME FLOOR UNIT, FRONT
120
HEXALOBULAR BOLT STOP TO FRAME
360
BOLT EXTENSION TO REAR AXLE CARRIER
370
WASHER BRACKET TO FRAME
370
WASHER EXTENSION TO REAR AXLE CARRIER, A 20130123
380
HEXAGON NUT EXTENSION TO REAR AXLE CARRIER
390
INDEXING PLATE PROPELLER SHAFT BEARING
390
INDEXING PLATE PROPELLER SHAFT BEARING
390
INDEXING PLATE PROPELLER SHAFT BEARING
400
BOLT
405
WASHER DIFFERENTIAL TO CROSS STABILIZER REAR
410
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
