Поз.
Артикул
Описание
800
ENGINE COVER CENTRAL, A 02991020111222
800
COVER CENTRAL, A 02990920111222
805
COVER LEFT
810
COVER RIGHT
815
DAMPER FILTER AIR FILTER HOUSING LEFT
815
DAMPER FILTER AIR FILTER HOUSING LEFT
817
WARNING STRIP "DANGER!HIGH TENSION!", IN GERMAN,ENGLISH,AND FRENCH
818
BRACKET
820
DAMPER FILTER AIR FILTER HOUSING RIGHT
820
DAMPER FILTER AIR FILTER HOUSING RIGHT
822
BRACKET
825
PRESSURE SENSOR ON AIR CLEANER
827
ELECTRICAL WIRING HARNESS TO PRESSURE SENSOR, A 02688220101027
827
ENGINE WIRING HARNESS TO PRESSURE SENSOR, A 02688320101027
827
ELECTRICAL WIRING HARNESS TO PRESSURE SENSOR, A 02688320101027 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 02790220110228, Replaced By: A2781506020
830
AIR FILTER INSERT
835
AIR INTAKE HOSE LEFT AIR INTAKE, A 03055120120419
835
AIR INTAKE HOSE LEFT AIR INTAKE, A 03055020120419
840
AIR INTAKE HOSE RIGHT AIR INTAKE, A 03055120120419
840
AIR INTAKE HOSE RIGHT AIR INTAKE, A 03055020120419
845
CLEAN AIR LINE LEFT AIR INTAKE
845
CLEAN AIR LINE LEFT AIR INTAKE, Replaced By: A2780940797
847
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
850
CLEAN AIR LINE RIGHT AIR INTAKE
852
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
855
BOOT LEFT
856
CLAMP W WORM DRIVE BOOT TO AIR FILTER HOUSING
858
CLAMP W WORM DRIVE BOOT TO CLEAN AIR LINE
860
BOOT RIGHT WITHOUT VENT LINE
860
BOOT RIGHT WITH VENT LINE
863
CLAMP W WORM DRIVE BOOT TO AIR FILTER HOUSING
865
CLAMP W WORM DRIVE BOOT TO CLEAN AIR LINE
875
SEAL RING
880
LOOM TIE LINE MOUNTING
