Поз.
Артикул
Описание
20
SIDE MEMBER LEFT
20
SIDE MEMBER RIGHT
22
REINFORCEMENT RIGHT
25
REINFORCEMENT SIDE MEMBER
30
SUPPORT LEFT FRONT SIDE MEMBER
30
SUPPORT RIGHT FRONT SIDE MEMBER
35
NUT , Replaced By: N913023006001
35
HEXAGON HEAD BOLT LINE MOUNTING M6X10
40
REINFORCEMENT FRONT BOTTOM LEFT
40
REINFORCEMENT FRONT BOTTOM RIGHT
50
REINFORCEMENT LEFT SUPPORT
50
REINFORCEMENT RIGHT SUPPORT
55
REINFORCEMENT LEFT, ONLY FOR GERMANY: PRIOR TO REPAIR, PLEASE CONTACT THE BODY TEAM AT TEL. NO.: +49-9001-847770. IN THE EVENT OF REPAIRS OUTSIDE OF GERMNAY, PLEASE CONTACT THE RESPECTIVE MPC.
55
REINFORCEMENT RIGHT, ONLY FOR GERMANY: PRIOR TO REPAIR, PLEASE CONTACT THE BODY TEAM AT TEL. NO.: +49-9001-847770. IN THE EVENT OF REPAIRS OUTSIDE OF GERMNAY, PLEASE CONTACT THE RESPECTIVE MPC.
70
REINFORCEMENT LEFT
70
REINFORCEMENT RIGHT
90
RIVETED NUT NET RETAINER M6
100
A-PILLAR RIGHT
100
A-PILLAR LEFT
110
WHEELHOUSE REAR OUTSIDE RIGHT
110
WHEELHOUSE REAR OUTSIDE LEFT
115
REAR STRUT ON REAR PILLAR AND ON REAR END FLOOR, LEFT
115
REAR STRUT ON REAR PILLAR AND ON REAR END FLOOR, RIGHT
120
SIDE MEMBER INSIDE RIGHT
120
SIDE MEMBER INSIDE LEFT
140
STRIKING PLATE RIGHT
140
STRIKING PLATE LEFT
180
REINFORCEMENT OUTSIDE REAR, RIGHT
180
REINFORCEMENT EXTERIOR,REAR,LEFT
200
REINFORCEMENT ON SIDE PANEL, RIGHT
200
REINFORCEMENT ON SIDE PANEL, LEFT
210
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
230
HOLDER RH TOP RIGHT, REAR
230
HOLDER LH TOP LEFT, REAR
240
WELD NUTM5
250
SCREW STEERING SHAFT BEARING TO CAB
270
BRACKET B-PILLAR
300
ROOF RAIL OUTSIDE LEFT
300
ROOF RAIL OUTSIDE RIGHT
320
HOLDER RH RIGHT
320
HOLDER LH LEFT
350
A-PILLAR INSIDE LEFT
350
A-PILLAR INSIDE RIGHT
360
ROOF RAIL INSIDE RIGHT
360
ROOF RAIL INSIDE LEFT
370
BRACKET SUN VISOR, LEFT
370
BRACKET SUN VISOR ON THE RIGHT
375
BOLT. SCREW CAN NEUTRAL POINT ON EQUIPMENT PLATE M5 X 14
390
ROOF RAIL OUTSIDE RIGHT
390
ROOF RAIL OUTSIDE LEFT
410
C-PILLAR OUTSIDE BOTTOM RIGHT
410
C-PILLAR OUTSIDE BOTTOM LEFT
420
C-PILLAR IN RIGHT INSIDE BOTTOM RIGHT
420
C-PILLAR IN LEFT INSIDE BOTTOM LEFT
430
C-PILLAR IN LEFT LEFT
430
C-PILLAR IN RIGHT RIGHT
450
STRIKING PLATE RIGHT
450
STRIKING PLATE LEFT
490
WHEELHOUSE BOTTOM REAR RIGHT
490
WHEELHOUSE REAR LEFT,BOTTOM
500
INSULATION SIDE PANEL,FRONT
500
SOUNDPROOFING SIDE PANEL,REAR
600
SCREW (PARTS KIT) PARTITION PANEL TO WHEELHOUSE
610
TS GLUING COMPONENT REPAIR KIT
620
BLIND RIVET REPAIR SOLUTION 6,4 X 12MM / 1-3,5MM, NO LONGER AVAILABLE RIVET ONLY VALID FOR BR222. REPAIR INFORMATION SEE WIS. ADDITIONAL INFORMATION ON TECHNICAL MARKET SUPPORT
710
2-COMPONENT FILLING FOAM DAMPING MATERIAL REPAIR SOLUTION
