Поз.
Артикул
Описание
10
COVER F ENGINE COMP. BM FRONT
20
CLIP-TYPE NUT BUMPER TO FRONT MODULE 4,8, J 47253620070424
50
CLIP-TYPE NUT LINING TO RIGHT LONGITUDINAL MEMBER 4,8
60
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
80
ENCAPSULATION CENTRAL
80
UNDERBODY PROTECTION CENTRAL
90
COVER F ENGINE COMP. BM ANTINOISE CAPSULE
140
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
160
SPRING-THREAD NUT PROTECTIVE PLATE
160
CLIP-TYPE NUT LINING TO RIGHT LONGITUDINAL MEMBER 4,8
180
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
190
SPRING-THREAD NUT PROTECTIVE PLATE
190
CLIP-TYPE NUT LINING TO RIGHT LONGITUDINAL MEMBER 4,8
200
ENCAPSULATION CENTRAL LEFT
220
BOLT AND WASHER ASSEMBLY FASTENING, SOUNDPROOFING AT LEFT AND RIGHT M5X15
240
AIR BAFFLE FRONT LEFT
250
AIR BAFFLE REAR LEFT
300
ENCAPSULATION CENTRAL RIGHT
320
AIR BAFFLE RIGHT
400
COVER F ENGINE COMP. BM
420
BRACKET FASTENING, REAR COVER
430
NUT INSULATION AND BRACKET TO BODY
450
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
460
CLIP-TYPE NUT LINING TO RIGHT LONGITUDINAL MEMBER 4,8
470
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
480
SHEET METAL SCREW FRONT MODULE 4.8X19, J 47253520070424
490
CLIP-TYPE NUT LINING TO RIGHT LONGITUDINAL MEMBER 4,8
500
CLIP-TYPE NUT REAR NOISE ENCAPSULATION TO SIDE MEMBER
600
STRUT FRONT LEFT
605
COMBINATION NUT STRUT AT LEFT FRONT M8
607
LOCK RINGTO 000 553 37 01,000 553 39 01,
610
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
620
BOLT STRUT TO FRAME-TYPE INTEGRAL SUPPORT
630
HEXAGON HEAD BOLT HEAT SHIELD MOUNTING M10X20
650
STRUT FRONT RIGHT
700
STRUT REAR LEFT
710
NUT LINKAGE TO REAR AXLE M10, J 45136320070307
720
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
750
STRUT REAR RIGHT
