Поз.
Артикул
Описание
10
FRONT FENDER RIGHT
10
FRONT FENDER RIGHT
10
FRONT FENDER LEFT
10
FRONT FENDER LEFT
20
NUT FENDER ON SIDE PANEL M6
40
STUD FENDER AT A-PILLAR, BOTTOM, THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019909614
60
BRACKET TOP REAR LEFT
60
BRACKET TOP REAR RIGHT
65
RIVET NUT RAIL TO BRACKET, FROM IDENT NO.: 234549
70
BRACKET CENTRAL TOP RIGHT
70
BRACKET CENTRAL TOP LEFT
75
RIVET NUT RAIL TO BRACKET, FROM IDENT NO.: 234549
80
BRACKET FRONT TOP RIGHT
80
BRACKET FRONT TOP LEFT
90
SCREW-AND-WASHER ASSEMBLY BASS BOX FASTENING M6X12
100
COVER, FENDER GAP LEFT FENDER
100
COVER, FENDER GAP RIGHT FENDER
110
STOP PLUG BRAKE CABLE
120
BOLT SUPPORT TO CROSS MEMBER M6X16
140
SCREW-AND-WASHER ASSEMBLY BASS BOX FASTENING M6X12
150
ABSORBER RIGHT FRONT FENDER
150
ABSORBER LEFT FRONT FENDER
160
SCREW BRACKET TO COVERING
160
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
160
BOLT SUPPORT TO CROSS MEMBER M6X16
160
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
160
HEXALOBULAR BOLT HEIGHT ADJUSTMENT,LEFT M8X16
180
BOLT SUPPORT TO CROSS MEMBER M6X16
240
INTERMEDIATE LAYER LEFT FRONT FENDER
240
INTERMEDIATE LAYER RIGHT FRONT FENDER
280
WHEEL HOUSE COVERING FRONT RIGHT
280
WHEEL HOUSE COVERING FRONT LEFT
280
WHEEL HOUSE COVERING FRONT LEFT
285
WHEEL ARCH LINING FRONT, RIGHT AMG
290
CLIP-TYPE NUT LINING TO RIGHT LONGITUDINAL MEMBER 4,8
310
PLASTIC NUT WHEELHOUSE COVERING LEFT
310
PLASTIC NUT COVER AT LOAD COMPARTMENT WELL
320
EXPANSION RIVET UNDERBODY SHIELD, J 06837520041130MJ 064877J 064880
320
RIVET COVERING TO SIDE MEMBER
400
PENNANT HOLDER RIGHT TOP
400
PENNANT HOLDER LEFT TOP
410
NUT BRACKET MOUNTING M6
420
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
440
PENNANT HOLDER LEFT BOTTOM
440
PENNANT HOLDER RIGHT BOTTOM
450
NUT BRACKET MOUNTING M6
460
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
470
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
500
PENNANT HOLDER RIGHT
500
PENNANT HOLDER LEFT
510
FIXTURE LEFT
510
FIXTURE RIGHT
520
PENNANT HOLDER LEFT BRACKET
520
PENNANT HOLDER RIGHT
530
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
550
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
560
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
600
PENNANT STAFF RIGHT
600
PENNANT STAFF
610
SPRING
620
SPACER RING ROD
620
BUSHING BRACKET TO ROOF RAIL
630
DISK SPRING ROD TO BRACKET LEFT
640
SCREW
650
HEXALOBULAR BOLT. SCREW HAND BRAKE VALVE TO BRACKET M 8X12
680
FIXTURE FLAGPOLE
690
COVER LEFT, TO BE PAINTED PRIOR TO INSTALLATION
700
STRIP AT REAR PANEL 4 MM 50X130 MM, NOT USED
710
PROTECTIVE BAG PENNANT, LEFT, 9E65 947/948QFT222A4150 BLACK
