Поз.
Артикул
Описание
5
HOUSING REAR AXLE CENTER ASSEMBLY WITH FLANGE 1:2.82, A 00018220030407MA 000142
5
REAR AXLE DIFFERENTIAL REAR AXLE CENTER ASSEMBLY W/O FLANGE, A 00159520060321806
5
HOUSING REAR AXLE CENTER ASSEMBLY W/O FLANGE 1:2.82, A 00018320030407 P A 000142 A 00189420061031807
50
COVER BEARING COVER, FROM IDENT NO. A 212245 ALSO INSTALLED ON A 187334 - A 212243 WITH CODE 867
60
SCREW STEERING SHAFT BEARING TO CAB M 8X22
70
SEAL RING INTERIOR FLANGE
70
SEAL RING INTERIOR FLANGE, IMPORTANT: SEALING RING AND PROTECTIVE RING MUST ALWAYS BE EXCHANGED TOGETHER!
80
SEAL RING BEARING COVER TO AXLE HOUSING
90
SEAL RING DRIVE PINION
90
SEAL RING DRIVE PINION
100
FLANGE PROPELLER SHAFT 120 MM, A 00183020061201807
100
FLANGE PROPELLER SHAFT 120 MM
110
SEAL RING FLANGE
120
NUT
120
NUT JOINT FLANGE
120
NUT FLANGE TO DRIVE PINION
130
END COVER REAR AXLE HOUSING WITH DIFFERENTIAL
130
END COVER
140
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
140
SCREW PLATE TO FRAME M 10X45
150
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
160
SCREW PLUG BELL HOUSING
170
FLANGE INSIDE, NO LONGER AVAILABLE SEPARATE PARTS VALID FOR BOLTED AXLE SHAFTS ONLY
170
FLANGE INSIDE RIGHT, A 00018220030407MA 000142
180
SNAP RING AS REQUIRED 1,40 MM
190
SIDE GEAR
190
SIDE GEAR
195
DIFFERENTIAL PINION
200
PRESSURE PLATE AS REQUIRED 1.40 MM
200
PRESSURE PLATE AS REQUIRED 1.30 MM
200
PRESSURE PLATE AS REQUIRED 1.00 MM
200
PRESSURE PLATE AS REQUIRED 1.20 MM
200
PRESSURE PLATE AS REQUIRED 1.50 MM
200
PRESSURE PLATE AS REQUIRED 1.60 MM
200
PRESSURE PLATE AS REQUIRED 1.10 MM
210
VENTILATION NECK , Replaced By: A1663510265
210
BREATHER
220
CAP BREATHER
220
BREATHER
250
EXTENSION
260
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
260
HEXAGON HEAD BOLT AXLE HOUSING TO EXTENSION M12X25, A 00183020060901807
270
WASHER DUMPING PLATFORM MOUNTING
280
HEXAGON HEAD BOLT. SCREW REINFORCEMENT TO SIDE MEMBER M 12X55
290
WASHER DUMPING PLATFORM MOUNTING
300
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
300
HEXAGON NUT ROD TO TORSION BAR, A 00206520070405
310
VALVE
