Поз.
Артикул
Описание
5
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
10
FITTING , NOT USED
10
PIPE BEND ENGINE BREATHING
10
PIPE BEND AT AIR COMPRESSOR
10
INTAKE PIPE , Replaced By: A3521302801
10
INTAKE PIPE , Replaced By: A3521302801
10
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
15
FITTING AT AIR COMPRESSOR
20
INTAKE PIPE FROM AIR COMPRESSOR TO CYLINDER HEAD COVER
25
INTAKE PIPE
30
INTAKE PIPE AIR COMPRESSOR
65
INTAKE PIPE , Replaced By: A3521340256
65
FITTING , Replaced By: A4032030008
65
CONNECTOR , Replaced By: A6012030008
65
FITTING INTAKE MANIFOLD
65
CONNECTOR
70
INTAKE PIPE FROM AIR COMPRESSOR TO CYLINDER HEAD COVER
100
SEAL RINGTO 376 131 74 01
100
SEAL RING LINE CONNECTION
105
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
110
NUT CHECK VALVE TO AIR RESERVOIR
110
NUT STEERING WHEEL TO STEERING COLUMN
110
NUT INTERMEDIATE SPEED STOP
115
NUT INTERMEDIATE SPEED STOP
115
NUT SUCTION LINE TO OIL PUMP
115
NUT 3/2-WAY VALVE TO CAB,4 685151
115
NUT , Replaced By: N080705026003
125
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
125
THRUST RING CHECK VALVE TO AIR RESERVOIR
125
THRUST RING SUCTION LINE TO OIL PUMP
130
SEAL RING LINE CONNECTION
130
O-RING CHECK VALVE TO AIR RESERVOIR
155
HOSE 18-MM-DIA. LINE
155
HOSE AIR COMPRESSOR CONNECTION 240 MM, ORDER BY THE METER
155
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR, ORDER BY THE METER
155
HOSE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR 22X29 MM, ORDER BY THE METER
155
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
160
HOSE INTAKE PIPE TO BREATHER PIPE,OM 352
160
HOSE HOSE TO AIR INTAKE PIPE & TO AIR COMPRESSOR & ENGINE BREATHER,RESP., ORDER BY THE METER
160
HOSE , ORDER BY THE METER
160
HOSE , Replaced By: A4969970082
160
HOSE , Replaced By: A4969970082
160
HOSE , Replaced By: A3909970682
160
HOSE , Replaced By: A3909970682
160
HOSE340 MM
160
HOSE HOSE TO OIL FILLER PIPE AND TO PIPE SOCKET ON OIL PAN 135 MM, ORDER BY THE METER
160
HOSE , Replaced By: A3909970682
195
INTAKE PIPE FROM AIR CLEANER TO AIR COMPRESSOR
205
INTAKE PIPE
230
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
230
LOOM TIE FROM AIR COMPRESSOR TO OIL PAN
230
LOOM TIE , Replaced By: N000000000668
230
LOOM TIE , Replaced By: A1049970590
230
CLAMP , Replaced By: N000000000667
230
CLAMP , Replaced By: A0069970490
230
CLAMP25-40X13 MM
240
BRACKET AIR INTAKE HOSE
245
BRACKET GUIDE TUBE
265
BRACKET INTAKE LINE TO CYLINDER HEAD COVER
275
SCREW STOP TO BATTERY CASE
275
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
280
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
285
CLAMP BRAKE HOSE BRACKET
285
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
285
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
285
CLAMP
285
CLAMP HOSE TO FLANGE AND TO VALVE
285
CLAMP FRAME MOUNTED CABLE HARNESS TO CAB
285
CLAMP HOSE TO BRACKET 25/20,5 206397
290
SCREW CLAMP MOUNTING M 6X16
290
SCREW , Replaced By: N304017008016
290
SCREW , Replaced By: N914146006102
290
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
290
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
290
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
295
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
300
NUT SPRING-LOADED PUSH ROD
300
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
305
CLAMP HOSE TO FLANGE AND TO VALVE
310
SCREW COVER PLATE TO BRACKET
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
LOOM TIE LINE MOUNTING 280 MM
999
SEAL RING , NOT USED
999
CLAMP HOSE FASTENING 28-35 MM,V 207570
999
FITTING AIR COMPRESSOR AND OIL PAN
999
BRACKET INTAKE MANIFOLD
999
BRACKET INTAKE MANIFOLD
999
HOSE , Replaced By: A3641870082
999
CONNECTOR AT ENGINE,591819
999
INTAKE PIPE AIR COMPRESSOR
999
HOSE (INTAKE HOSE)
999
INTAKE PIPE BELT-DRIVEN AIR COMPRESSOR
999
INTAKE PIPE AT CYLINDER HEAD, NOT USED
999
INTAKE PIPE SUCTION LINE TO AIR COMPRESSOR, FROM ENGINE 234538 YEAR OF MANUFACTURE 1992 UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
999
HOSE
999
BRACKET SUCTION LINE TO CHARGING AIR ELBOW, NOT USED
999
BRACKET INTAKE HOSE TO FILTER
999
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
999
SCREW PLUGTO 376 131 74 01
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
NUT BALL PIVOT TO LEVER
999
NUT , Replaced By: N304032008006
999
SCREW SCREENING PLATE TO ALTERNATOR M 10X1X12,027925
999
HEXAGON HEAD BOLT BRACKET TO BRACKET
999
NUT
999
NUT STEERING WHEEL TO STEERING COLUMN
999
HEXAGON HEAD BOLT COVERING TO CAB
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: N000000000667
999
CLAMP , Replaced By: A0069974290
