Поз.
Артикул
Описание
300
BACKREST FRAME ASSEMBLY RIGHT SEAT, A 09007320080709809 WITHOUT LUMBAR SUPPORT
300
BACKREST FRAME ASSEMBLY , A 32101520070928808
300
BACKREST FRAME ASSEMBLY , A 32101520070928808
300
BACKREST FRAME ASSEMBLY RIGHT SEAT, A 09007320080709809 WITH LUMBAR SUPPORT
300
BACKREST FRAME ASSEMBLY RIGHT SEAT, A 09007320080709809 WITH LUMBAR SUPPORT
300
BACKREST FRAME ASSEMBLY RIGHT SEAT MEMORY, A 09007320080709809 WITHOUT LUMBAR SUPPORT
305
HOOK TO BACKREST FRAME
310
SCREW BACKREST FRAME TO SEAT FRAMEWORK
320
REST BACKREST, RIGHT
320
REST BACKREST, RIGHT, A 09007320080709809
320
REST BACKREST, RIGHT, A 09007320080709809
320
REST BACKREST, RIGHT, A 09007320080709809
320
REST BACKREST, RIGHT, A 09007320080709809
320
REST BACKREST, RIGHT, A 09007320080709809
320
REST BACKREST, RIGHT, A 09007320080709809
320
REST BACKREST, RIGHT, A 06859520070928808
320
REST BACKREST, RIGHT, A 09007320080709809
320
REST BACKREST, RIGHT
330
COVER FRONT SEAT BACKREST BACKREST, RIGHT
330
COVER EXCLUSIVE LEATHER TRIM
330
COVER ALCANTARA
330
COVER FRONT SEAT BACKREST BACKREST, RIGHT
330
COVER ARTICO LEATHER
330
COVER EXCLUSIVE LEATHER TRIM
330
COVER ARTICO LEATHER
330
COVER ARTICO LEATHER
330
COVER BACKREST, RIGHT
330
COVER EXCLUSIVE LEATHER TRIM
330
COVER ALCANTARA
330
COVER EXCLUSIVE LEATHER TRIM
330
COVER FRONT SEAT BACKREST ARTICO LEATHER
330
COVER ARTICO LEATHER
330
COVER LEATHER
330
COVER LEATHER
330
COVER FABRIC
330
COVER EXCLUSIVE LEATHER TRIM
330
COVER MB-TEX
330
COVER FABRIC
330
COVER FABRIC
330
COVER LEATHER
330
COVER ARTICO LEATHER, Replaced By: A2519100693
330
COVER EXCLUSIVE LEATHER TRIM
330
COVER BACKREST, RIGHT
330
COVER LEATHER
330
COVER FABRIC
330
COVER MB-TEX
330
COVER LEATHER, Replaced By: A2519102093
330
COVER LEATHER
330
COVER "EXCLUSIV"LEATHER TRIM
330
COVER ALCANTARA
330
COVER LEATHER
330
COVER ALCANTARA, Replaced By: A2519101493
330
COVER LEATHER
330
COVER ALCANTARA, Replaced By: A2519101693
340
PANELING BACKREST FRAME
340
PANELING BACKREST FRAME
350
HOOK RIGHT, RIGHT SEAT
360
HOOK LEFT, RIGHT SEAT
370
SCREW PANELLING TO FRONT SEAT BACKREST
380
GUIDE FOR HEADREST HEAD RESTRAINT SEAT LEFT, LEFT
380
GUIDE FOR HEADREST HEAD RESTRAINT SEAT RIGHT, RIGHT
382
LOCK TAIL LAMP
385
GUIDE FOR HEADREST HEAD RESTRAINT SEAT RIGHT, LEFT
385
GUIDE HEAD RESTRAINT
385
GUIDE FOR HEADREST HEAD RESTRAINT SEAT LEFT, LEFT
390
ADJUSTER HEAD RESTRAINT, E 01872520030630804 A 55589720030630804 F 45737520031014804 R 13114520031203804
410
AIR BAG TO BACKREST FRAME
420
RIVET
430
BRACKET MONITOR AT LEFT SEAT, A 06859520070928808, Replaced By: A0009190000
440
REINFORCEMENT MONITOR AT RIGHT SEAT
445
BOLT BACKREST SHELL TO BACKREST FRAME 5X18
450
MOUNTING BRACKET TRANSVERSAL TACKING, A 48000720081001809
460
MOUNTING BRACKET LONGITUDINAL STAPLE UPHOLSTERY, CENTER RIGHT SEAT
470
CLIP SEAT COVER MOUNTING,TRANSVERSE
480
SEAT ADAPTER IN BACKREST
480
TRUSS BACKREST, RIGHT, Replaced By: A0009105202
480
ADJUSTABLE INSERT LEFT, A 32101520070928808
482
CLUTCH HOSE TO INSERT, A 32101520070928808
484
BRACKET
486
HOUSING TAXI OR PREINSTALLATION FOR RENTAL CAR 2-PIN SLK2.8
488
PARTS BOX (LUMBAR SUPPORT (FFO))
495
SEAT ADAPTER RIGHT
495
SEAT ADAPTER LEFT
500
FAN SEAT VENTILATION
500
ELECTRIC MOTOR SEAT VENTILATION, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. A 75022420110604, Replaced By: A1649060015
510
CLUTCH HOSE TO INSERT, A 32101520070928808
520
HOUSING TAXI OR PREINSTALLATION FOR RENTAL CAR 2-PIN SLK2.8
530
BRACKET
540
CABLE STRAP FOR SHEET THICKNESS: 1.0-3.0 MM
550
HEAD RESTRAINT ALCANTARA
550
HEAD RESTRAINT VELOURS "EXCLUSIVE/ALCANTARA"
550
HEAD RESTRAINT RIGHT SEAT
550
HEADREST "EXCLUSIV"LEATHER TRIM
550
HEAD RESTRAINT "TWIN" LEATHER
550
HEAD RESTRAINT RIGHT SEAT
550
HEADREST LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT RIGHT SEAT
550
HEADREST LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEADREST "TWIN" LEATHER
550
HEAD RESTRAINT LEFT SEAT
550
HEADREST ALCANTARA
550
HEAD RESTRAINT ALCANTARA
550
HEAD RESTRAINT UNI-COLOR "DESIGNO" "EXCLUSIVE/ALCANTARA"
550
HEADREST FABRIC/LEATHER "TWIN"/ALCANTARA
550
HEAD RESTRAINT RIGHT SEAT
550
HEADREST LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEADREST LEFT SEAT
550
HEAD RESTRAINT ALCANTARA
550
HEAD RESTRAINT ALCANTARA
550
HEAD RESTRAINT LEFT SEAT
550
HEADREST LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT ALCANTARA
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT ALCANTARA
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEAD RESTRAINT LEFT SEAT
550
HEADREST LEATHER
550
HEAD RESTRAINT RIGHT SEAT
550
HEADREST "TWIN" LEATHER
560
LEVER BACKREST ADJUSTER
565
SPRING CLAMP TO LEVER, A 44851420080709809
570
BRACKET LEFT BACKREST
580
BLIND RIVET NUT AT BRACKET
590
CONTROL UNIT SEAT VENTILATION
590
CONTROL UNIT SEATS SEAT VENTILATION, RIGHT BACKREST, Replaced By: A2218705387
600
HEXALOBULAR BOLT CAN NEUTRAL POINT ON EQUIPMENT PLATE M4X12,V 202043
700
PLUG HOUSING FRONT PASSENGER FOOTWELL ILL. 2-PIN MCP2.8
700
HOUSING CRASH ACTIVE HEAD RESTRAINT 2-PIN MQS,Y24/12, Y24/13
700
COUPLER STRIP HOSE LINE
705
CONTACT BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
705
PLUG PINX 209, 0.75 MM2
710
PIN BUSHING HOUSING RAIN SENSOR 4 POLIG
710
CLAMP. EXTENDABLE SPACER BREATHER LINE
715
FEMALE CONTACT SWITCH, POWER WINDOW, DRIVER 0.25-0.5 MM2 MQS,S20
715
REP.SET CONTACT0.75 MM2 MQS, CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS.SOLDER CONNECTOR SLEEVES:TOTAL WIRE CROSS-SECTION: A 001 546 99 41GREEN0.7 -2.4 MM2 A 002 546 00 41RED2.0 -4.0 MM2 A 002 546 01 41BLUE 3.5 -8.0 MM2 A 002 546 11 41YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2
720
CLUTCH PLUG CONNECTION TRAILER PLUG SOCKET 4-PIN SLK2.8,X52
725
CONTACT SPRING0.5MM2-1.0MM2, A 843748 X 019421
725
CONTACT SPRINGTO A 038 545 76 28
730
REP.SET CONTACT WINDOWBAG SQUIB, REAR 2-PIN 0.5MM2,R12/22 R12/23
