Поз.
Артикул
Описание
8
16
GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
24
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
32
NUT CONNECTOR TO EXHAUST MANIFOLD
40
CLAMP , 003 078976 086 003333 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332.
40
CLAMP , Replaced By: A1074900141
40
CLAMP , Replaced By: A1074900041
48
SCREW VALVE TO BRACKET M 8X55
48
SCREW , Replaced By: N304017008043
56
WASHER BRACKET TO CROSS MEMBER
64
HEXAGON NUT SCREENING PLATE,5 163561
64
NUT , Replaced By: A1201420072
72
EXHAUST MUFFLER
80
BRACKET EXHAUST MUFFLER SUSPENSION
88
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
96
NUT BRACKET TO FRAME M 10X1
96
NUT , Replaced By: N910113010004
104
104
104
112
SCREWM 8X40
120
NUT , Replaced By: N913004008001
120
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
120
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
128
SUSPENSION PROTECTIVE PLATE TO EXHAUST PIPE
128
REPAIR KIT , Replaced By: A3094900037
136
CLAMP , Replaced By: N000000001641
136
CLAMP , Replaced By: A9424310043
136
CLAMP LINE MOUNTING
144
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
144
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
NUT , Replaced By: A1201420072
