Поз.
Артикул
Описание
5
BRACKET CLUTCH PEDAL AND BRAKE PEDAL,314243
14
STOP
23
PEDAL BRAKE
32
BUSHING BRAKE PEDAL
32
BUSHING , Replaced By: A1242920050
41
PEDAL CLUTCH,526441
50
BUSHING BRAKE PEDAL
50
BUSHING , Replaced By: A1242920050
59
PAD BRAKE
68
WASHER PEDALS TO PIVOT PINS
77
LOCK AT WATER EXPANSION TANK
86
SWITCH STOP LIGHT
95
NUT SWITCH
104
SPRING RELEASE SPRING
113
ROD OVER-CENTER ACTING SPRING
122
SPRING (DEAD CENTER SPRING) 35 MM
131
SPRING RETAINER SPRING TO PUSH ROD
140
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
149
SPRING RETAINER SPRING TO PUSH ROD
153
REPAIR KIT DEAD CENTER SPRING
158
MASTER CYLINDER , 077222
158
MASTER CYLINDER , Replaced By: A0012958706
158
MASTER CYLINDER , 000,003,007,102,103,105,200 A 091118 083,086,093,183,190,193,280,283 F 015866, Replaced By: A0012954406, +001A0002950833
158
MASTER CYLINDER , Replaced By: A0002959106
167
BOOT
176
LOCK RING19 MM
185
PLUG
194
INTERMEDIATE PIECE FROM CLUTCH MASTER CYLINDER TO RESERVOIR
203
REPAIR KIT MASTER CYLINDER, 000,003,007,102,103,105,200 A 091118 083,086,093,183,190,193,280,283 F 015866
212
REPAIR KIT TO MASTER CYLINDER HAVING ALUMINUM PISTON TO 000 295 77 06
221
SCREW DISTRIBUTOR TO CAB
221
SCREW DISTRIBUTOR TO CAB
221
SCREW , Replaced By: N000933006151
230
SPACER TUBE MASTER CYLINDER TO CONSOLE TO 000 295 91 06
239
NUT , Replaced By: N913004006001
239
NUT PUMP TO BRACKET
248
ROD FROM CLUTCH PEDAL TO MASTER CYLINDER,526441
257
BUSHING PISTON ROD TO CLUTCH PEDAL
266
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
266
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
266
NUT , Replaced By: N913004008001
275
SCREW , Replaced By: N304017008018
275
SCREW SUPPORT TO FENDER
284
HOSE FROM CLUTCH HOSE TO SLAVE CYLINDER
293
GROMMET
293
GROMMET , Replaced By: A0079975881
302
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
311
LOCK HYDRAULIC LINE TO CAB
320
SCREW PIPE CLAMP
320
SCREW , Replaced By: N304017008021
329
WASHER EXHAUST MUFFLER TO STRAP
338
GROMMET PLUG SOCKET
338
GROMMET ,D 314239
347
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
