Поз.
Артикул
Описание
1
BRACKET SPARE WHEEL MOUNTING
1
BRACKET SPARE WHEEL MOUNTING
1
BRACKET SPARE WHEEL MOUNTING
1
BRACKET SPARE WHEEL MOUNTING
1
BRACKET SPARE WHEEL MOUNTING
2
RUBBER BUFFER
6
CHAIN
8
CONNECTING RAIL SPARE WHEEL CARRIER
8
CONNECTING RAIL SPARE WHEEL CARRIER
8
CONNECTING RAIL SPARE WHEEL CARRIER
8
CONNECTING RAIL , Replaced By: A3094001842
9
NUT , Replaced By: N913004008001
9
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
9
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
10
SCREW BRACKET TO FRAME
12
NUT SPARE WHEEL TO BRACKET
12
NUT , Replaced By: A0004000072
14
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
19
BRACKET DISC WHEEL
22
SCREW PIPE CLAMP
22
SCREW , Replaced By: N304017008021
23
NUT , Replaced By: N913004008001
23
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
23
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT , Replaced By: N910113010000
999
NUT AIR CLEANER ELEMENT
999
NUT STRAP TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
SPRING LOCK WASHER. LOCK WASHER , Replaced By: A9019900047
999
NUT DISC WHEELS TO FRONT AND REAR AXLES
999
NUT , Replaced By: N074361014205
999
WASHER SPARE WHEEL CARRIER
999
SCREW , Replaced By: N304017010002
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
LOCK WASHER DISC WHEELS TO FRONT AND REAR AXLES
999
BRACKET SPARE WHEEL CARRIER
999
NUT DISC WHEEL TO SUPPORT
999
BASE BLOCK BRACKET TO FRAME
999
BRACKET , Replaced By: A3094006739
999
BRACKET SPARE WHEEL
999
NUT BRACKET TO FRAME
999
NUT , Replaced By: A0004000072
