Поз.
Артикул
Описание
124
THERMOSTAT
128
POCKET
132
GASKET
136
POCKET
137
SCREW CONTACTOR
139
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
140
THERMOSTAT ELEMENT
144
GASKET
146
LINE , TO 312 010 51 20,312 010 50 20
147
LINE , 004710
148
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
148
GASKET HEATING PIPE TO ENGINE
148
GASKET , Replaced By: A3662030380
150
LOCK WASHER
151
SCREW BRACKET TO INTAKE MANIFOLD
160
SEALING RING. SEAL RING FUEL TANK
164
PROTECTIVE SLEEVE
172
HOSE , UP TO CHASSIS 000015, Replaced By: A1115010482, +001A1105000191, +001A1105010482
176
HOSE , UP TO CHASSIS 000015, Replaced By: A1115010482, +001A1105000191, +001A1105010482
178
LOOM TIE , Replaced By: N916017040000
178
CLAMP , Replaced By: N000000000671
178
CLAMP
180
HOSE , UP TO CHASSIS 000015, Replaced By: A1115010482, +001A1105000191, +001A1105010482
184
HOSE , 004710
186
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
186
LOOM TIE , Replaced By: N916017020000
186
CLAMP , Replaced By: N000000000667
188
HOSE
192
CLAMP
192
LOOM TIE , Replaced By: N916017040000
192
CLAMP , Replaced By: N000000000671
196
T-FITTING
200
HOSE
204
CLAMP
204
LOOM TIE , Replaced By: N916017040000
204
CLAMP , Replaced By: N000000000671
208
HOSETO 312 200 08 15
212
LOOM TIE , Replaced By: N916017040000
212
CLAMP , Replaced By: N000000000671
212
CLAMP
999
TAPERED ROLLER BEARING
999
V-BELT
999
PROTECTIVE SLEEVE
999
LOOM TIE , Replaced By: N916017040000
999
PRESSURE SPRING. SPRING , Replaced By: A0002012719
999
LINE , TO 312 010 28 20,312 010 30 20
999
LINE , TO 312 010 28 20,312 010 30 20
999
SLIP RING. SEAL , Replaced By: A0002012719
999
SEALING RING. INTERMEDIATE RING , Replaced By: A0002012719
999
COVER , Replaced By: A0002012719
999
IMPELLER , Replaced By: A3122010507
999
SLIP RING CAGE. SEAL HOLDER , Replaced By: A0002012719
999
SPACER WASHER0.10 MM
999
SPACER WASHER AS REQUIRED 0.15 MM
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPLASH RING ,005245
999
SPACER WASHER0.50 MM
999
BRACKET , TO 312 200 06 51,312 200 24 51
999
FAN , Replaced By: A3522050106
999
COOLING WATER HOSE , Replaced By: A3405010282
999
SPRINGRING. SNAP RING , Replaced By: A0002012719
999
SHAFT , Replaced By: A3212010105
999
PART NAME MISSING ,005627
999
PART NAME MISSING ,005627
999
WATER PUMP ,005245, Replaced By: A3222000801
999
HOUSING ,005245, Replaced By: A3222010203
999
SHAFT
999
BODY , Replaced By: A3522002301, +001A3522010012, +001A3522012080, +001A3522032380, +001A3405010382, +002N000931008031
999
WATER PUMP ,005246-005627, Replaced By: A3522001501
999
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
SCREW
999
SCREW
999
SCREW STOP PLATE TO BELL HOUSING
999
SCREW RUBBER MOUNTING TO FRONT AXLE
999
SCREW CLUTCH TO FLYWHEEL
999
HOSE28 X 36 X 60 MM
999
CLAMP , Replaced By: A0419970590
999
CLAMP , Replaced By: A0419970690
999
CLAMP , Replaced By: N000000000671
