Поз.
Артикул
Описание
13
SWITCH (BATTERY MASTER SWITCH)
13
SWITCH (BATTERY MASTER SWITCH)
13
SWITCH , Replaced By: A0005458408
26
SWITCH BATTERY, UP TO IDENT NO. 932020
26
SWITCH BATTERY, UP TO IDENT NO. 932020
39
SWITCH. BATT.SWITCH (BATTERY MASTER SWITCH)
52
KEY
65
SCREW CAP TO BRACKET
78
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
91
NUT BALL PIVOT TO LEVER
104
SCREW BRACKET TO CROSS CONNECTION STRUT
104
SCREW , Replaced By: N304017008034
104
SCREW PIPE CLAMP
104
SCREW , Replaced By: N304017008021
117
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
130
NUT
156
GUIDE SIGN BATTERY MASTER SWITCH
169
GROOVED NAILTO 352 584 03 21
182
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
182
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
182
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
182
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
182
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
182
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
182
ELECTRIC CABLE , Replaced By: A6735460013
182
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
182
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
182
ELECTRIC CABLE FROM BATTERY MASTER SWITCH TO CABLE CONNECTOR
195
NEG. CABLE FROM BATTERY TO CAB REAR CROSS MEMBER
208
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
221
LOOM TIE LINE MOUNTING 280 MM
234
PLUG SOCKET WITH ELECTRIC CABLES
234
PLUG SOCKET WITH ELECTRIC CABLES
247
SCREW LICENSE PLATE TO BRACKET
247
SCREW , Replaced By: N304017006020
260
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
273
NUT BALL PIVOT TO LEVER
286
CABLE CONNECTOR UNIPOLAR
286
CABLE CONNECTOR , Replaced By: A3155460041, +001N000084010114, +001N000439010210
299
SCREW REAR EXHAUST PIPE TO MUFFLER
312
NUT
312
NUT , Replaced By: N304035010001
325
CAP CABLE CONNECTOR
338
SCREW TEST CONNECTION TO BRACKET
351
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
364
NUT
377
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
390
NUT
390
NUT , Replaced By: N304035010001
403
CLAMPING PIECE ,4 956524
403
CLAMPING PIECE ,4 956524
416
CLAMPING PIECE
429
SCREW RESIDUAL PRESSURE VALVE AND BRACKET TO FRAME M 5X50, 407 5 032812 408 5 030603
442
LOCK WASHER LINE MOUNTING
455
WASHER BOOT TO CAB FLOOR
455
WASHER , Replaced By: N000433005304
468
NUT IN CASE OF SUBSEQUENT INSTALLATION
468
NUT , Replaced By: N304032005005
481
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
481
SCREW , Replaced By: N304017006012
494
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
507
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
PLUG SOCKET , Replaced By: A4165400081
999
GUIDE SIGN BATTERY MASTER SWITCH
999
ADHESIVE FOIL GUIDE SIGN
999
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR
999
CABLE SHOE FROM BATTERY MASTER SWITCH TO FRAME
999
CABLE SHOE BATTERY CABLE 10-70 MM
999
CABLE SHOE BATTERY CABLE TO BATTERY MASTER SWITCH
999
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
999
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
999
SOLDERING TERMINAL POS. POLE
999
SOLDERING TERMINAL NEG.POLE
999
PLUG SOCKET BIPOLAR
999
ELECTRIC CABLE , Replaced By: A6735460011
