Поз.
Артикул
Описание
30
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
33
BANJO UNION FROM PRESSURE REGULATOR TO ANTI-FREEZE DEVICE,6 900001-6 900006
33
BANJO UNION HOSE WIDTH, / I.D., 8/22 MM
33
BANJO UNION , Replaced By: N000000000363
81
PROTECTIVE CAP COMPRESSED AIR LINE MOUNTING
460
BRAKE MASTER CYLINDERTEVES
460
BRAKE MASTER CYLINDERSCHAEFER
460
BRAKE MASTER CYLINDER , Replaced By: A0034309401
461
SCREWTO 003 430 72 01,SCHAEFER
462
SEAL RINGTO 002 430 69 01
463
THREADED UNIONTO 003 430 72 01,SCHAEFER
464
SEAL RINGTO 002 430 72 01,SCHAEFER
465
VALVE
466
SPRINGTO 002 430 69 01
467
SPRING RETAINERTO 003 430 72 01,SCHAEFER
468
SPRINGTO 003 430 72 01,SCHAEFER
469
SPRINGTO 003 430 72 01,SCHAEFER
470
WASHERTO 003 430 72 01,SCHAEFER
471
THREADED UNIONTO 003 430 72 01,SCHAEFER
472
SEAL RINGTO 002 430 69 01
473
VALVE CLUTCH SLAVE CYLINDER
473
VALVE , Replaced By: A3075530107
473
BLEEDER VALVE , Replaced By: A0004310265
474
PROTECTIVE CAP , Replaced By: A0004217187
474
PROTECTIVE CAP ,5 962906
474
PROTECTIVE CAP , Replaced By: A0004217187
474
PROTECTIVE CAP , Replaced By: A0004210887
474
PROTECTIVE CAP , Replaced By: A0004210887
475
REPAIR KITTO 003 430 94 01,003 430 72 01
475
REPAIR KIT , Replaced By: A0035860143
477
CONNECTOR MASTER CYLINDER,CONNECTION "2.1",4 338292
478
SEAL RING FUEL LINE TO FEED PUMP
479
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
481
FITTING TWO-WAY VALVE "12",4 4121264 691315
483
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
483
SEAL RING LINE CONNECTION
483
SEAL RING LINE CONNECTION
487
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
487
HOLLOW SCREW OIL LINE TO TRANSMISSION
487
HOLLOW SCREW FUEL LINE TO FEED PUMP
487
HOLLOW SCREW , Replaced By: N915036010108
490
SEAL RING FUEL LINE TO FEED PUMP
495
BRACKET MASTER CYLINDER TO BRAKE BOOSTER,4 373946
502
SCREW HAND PUMP TO BRACKET
507
BRACKET BRAKE MASTER CYLINDER,4 373947
510
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
510
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
512
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
512
SCREW , Replaced By: N304014008001
515
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
515
NUT , Replaced By: N913004008001
520
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
520
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
522
SCREWM 8X40
524
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
524
NUT , Replaced By: N913004008001
530
RESERVOIR WITH BRAKE SYSTEM WARNING DEVICE FAG
530
RESERVOIR WITH WARNING DEVICE,4 314610
535
FILLER CAPTO 001 431 38 02,000 431 58 02
535
FILLER CAP , Replaced By: A0004317633
535
FILLER CAP , Replaced By: A0004316533
535
FILLER CAP , Replaced By: A0004313733
538
STRAINERTO 001 431 38 02
541
CLAMPTO 000 431 58 02
546
SCREW COVER PLATE TO BRACKET
549
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
552
NUT PUMP TO BRACKET
552
NUT , Replaced By: N913004006001
553
LINE FROM CLUTCH MASTER CYLINDER TO CLUTCH HOSE
554
LINE1750 MM, UP TO IDENT NO. 721608 EXCEPT FOR:500001-599999
554
LINE FROM VALVE TO BRAKE HOSE 1500 MM
562
SCREW VALVE TO BRACKET
564
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
566
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
566
NUT , Replaced By: N913004008001
568
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
570
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
594
BRAKE HOSE AT REAR AXLE
596
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
596
BRACKET. LOCK , Replaced By: A6525040038
598
ANGLE AT FRAME, FRONT
600
GROMMET BATTERY CASE
602
SCREW END PIECE TO EXHAUST PIPE M 10X25
604
NUT STRAP TO BRACKET
604
NUT , Replaced By: N910113010000
614
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
616
TUBE. BUSHING CAB FLOOR COVERING
616
TUBE. BUSHING CAB FLOOR COVERING
620
SPACER TUBE
620
SPACER TUBE , Replaced By: A4082910153
625
ANGLE LINE MOUNTING
626
SCREW PIPE CLAMP
626
SCREW , Replaced By: N304017008021
627
NUT , Replaced By: N913004008001
627
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
629
SCREW , Replaced By: N304017006026
629
SCREW , Replaced By: N304017006026
630
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
631
NUT , Replaced By: N913004006001
631
NUT PUMP TO BRACKET
634
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
636
NUT , Replaced By: N913004006001
636
NUT PUMP TO BRACKET
638
SPACER TUBE , Replaced By: A3094310249
638
GUIDE BUSHING TWO-WAY VALVE TO FRAME
640
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
641
LINE FROM BRAKE POWER REGULATOR,CONNECTION "2",TO BRAKE HOSE 1250 MM
641
LINE FROM BRAKE POWER REGULATOR,CONNECTION "2",TO BRAKE HOSE 1250 MM
641
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 1200 MM
642
BRACKET FUEL LINES
642
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
643
BRACKET , Replaced By: A3853530440
643
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
646
NUT , Replaced By: N913004006001
646
NUT PUMP TO BRACKET
650
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
650
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 600 MM
652
BRAKE HOSE
652
BRAKE HOSE
652
BRAKE HOSE
654
ANGLE AT FRAME, FRONT
656
BRACKET. LOCK , Replaced By: A6525040038
656
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
657
SCREW END PIECE TO EXHAUST PIPE M 10X25
660
BRACKET , Replaced By: A3184280440
660
BRACKET RIGHT,7914218 000001
662
SCREW , Replaced By: N304017008016
664
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
666
CLAMP BRAKE LINE MOUNTING
668
HOSE BRAKE LINE TO REAR AXLE,4 644238
670
TEST CONNECTION FRONT AXLE
670
TEST CONNECTION FRONT AXLE
671
SCREW , Replaced By: N304017008034
671
SCREW BRACKET TO CROSS CONNECTION STRUT
999
COUPLING PIECE AT CAB FLOOR,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
COUPLING PIECE ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
999
VALVEBOSCH
999
BLEEDER VALVE , Replaced By: A0004310265
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
HANDLE (PARTS KIT) TO 001 430 07 81/20 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
999
HANDLETO 001 430 17 81,KNORR
999
REPAIR KITTO 001 430 18 81/78 81
999
REPAIR KITTO 001 431 47 06,WABCO 2210, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
999
REPAIR KITBOSCH
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE BOSCH
999
REPAIR KITTO 001 431 84 06,KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT SEAL RING BOSCH,209
999
FILTER BOTTOMTO 000 431 24 14
999
COVERTO 001 431 85 14,4 282708
999
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
COVERTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
999
ACTUATING PARTTO 001 430 07 81/20 81
999
DIAPHRAGMTO 001 431 90 06,GRAU,5 148812
999
HOLLOW SCREW HEATING CONNECTION
999
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
999
PLUG ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
BANJO UNION HEATING CONNECTION,K 169122
999
SLEEVE LINE CONNECTION
999
CLAMP ,K 147121, Replaced By: N000000000319
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
UNION NUT LINE CONNECTION
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
999
SCREW LICENSE PLATE TO BRACKET
999
NUT CHECK VALVE TO AIR RESERVOIR
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
WASHER , Replaced By: N009021008213
999
SCREW PLATE TO BRACKET, Replaced By: N000000001481
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW , Replaced By: N007985006580
999
SCREW PLATE TO BRACKET, Replaced By: N007985006590
999
SHEET METAL SCREW ,4 383114 ALSO INSTALLED ON 4 366280,4 366695,4 367047.
999
SHEET METAL SCREW BOOT TO CAB FLOOR
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING , Replaced By: N007603010110
999
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
999
GLAND LINE CONNECTION
999
SCREW COVER PLATE TO BRACKET
999
NUT , Replaced By: N308673016001
999
NUT L.H. THREAD
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW EXHAUST PIPE TO BRACKET
999
SCREWTO 001 431 72 14,BOSCH
999
SCREW DISTRIBUTOR TO CAB
999
SCREW COVER PLATE TO BRACKET
999
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
999
SCREW , Replaced By: N304017006020
999
SCREW BRAKE BOOSTER ASSEMBLY TO APPARATUS SUPPORT M 10X40,4 338291
999
SCREW STRAP TO BRACKET
999
SCREW CONNECTOR
999
SCREW , Replaced By: N000933006151
999
LOCK RINGTO 001 431 71 14,001 431 73 14
999
EXPANSION PLUG ,4 819869
999
WASHER ROCKER PANEL TO SUPPORT
999
WASHER RADIATOR TO RUBBER MOUNTING
