Поз.
Артикул
Описание
10
WATER PUMP WITH GASKETS,492711 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
10
WATER PUMP , Replaced By: A3142003701
10
WATER PUMP , Replaced By: A3142003901
10
WATER PUMP , Replaced By: A3142004201
15
SHAFT ,937666/89, Replaced By: A3662010205, +001N000625900208, +001N000625900209
15
SHAFT
22
THRUST RINGTO 000 201 66 19/72 19
28
BOOTTO 000 201 66 19,000 201 72 19
35
SEAL WITH THRUST RING AND BOOT
35
SEAL , Replaced By: A0002019919
35
SEAL , Replaced By: A0002015719
35
SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002018019
35
SEAL , Replaced By: A0002016719
35
SEAL , Replaced By: A0002019219
35
SEAL , Replaced By: A0012011719
35
SEAL , Replaced By: A0012011819
35
SEAL , Replaced By: A0012011919
35
SEAL , Replaced By: A0012011919
35
SEAL , Replaced By: A0012012619
41
SEAL RING
41
SEAL RING
47
GROOVED BALL BEARING INTERMEDIATE BEARING
53
GROOVED BALL BEARINGTO 001 466 15 01
60
SEAL RING WATER PUMP
66
SEAL HOLDER
66
SEAL HOLDER
72
SEAL RING
72
SEAL RING
80
SCREW PLUG STABILIZER
90
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
98
HUB
110
IMPELLER PARTS KIT
110
IMPELLER PARTS KIT
110
IMPELLER , Replaced By: A3142000604
110
IMPELLER , Replaced By: A3142000704
110
IMPELLER , Replaced By: A3142000304
110
IMPELLER , Replaced By: A3142000904
110
IMPELLER , Replaced By: A3142001004
110
REPAIR KIT , Replaced By: A3142000104
118
GASKET KIT
118
REPAIR KIT , Replaced By: A3142000060
118
GASKET KIT WATER PUMP
125
GASKET WATER PUMP TO CYLINDER CRANKCASE
125
GASKET , Replaced By: A3642010280
131
HEXAGON HEAD BOLT. SCREW LEVER TO RELEASE SHAFT
138
SCREW WATER PUMP TO CYLINDER CRANKCASE
145
HOUSING
152
GASKET , Replaced By: A3522032380
152
GASKET1 MM
159
SCREW PIPE SOCKET TO THERMOSTAT M 8X45
165
GASKET COVER TO THERMOSTAT HOUSING, NOT USED
165
GASKET , Replaced By: A3522032280
171
COVER THERMOSTAT
178
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
185
GASKET , Replaced By: A3522032680
185
GASKET , Replaced By: A3522032480
192
THERMOSTAT ELEMENT , Replaced By: A0042038475
192
THERMOSTAT ELEMENT , Replaced By: A0052032875
192
THERMOSTAT ELEMENT 71 DEGREES
200
LINE UPPER COOLING WATER LINE
200
LINE
210
SCREW PLUG FUEL TANK
218
SEAL RING CLUTCH BOOSTER
225
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
225
GASKET HEATING PIPE TO ENGINE
225
GASKET , Replaced By: A3662030380
232
FLANGE
232
FLANGE HOT WATER HEATING CONNECTION
247
SCREW ON STOP M 8X65
255
HEXAGON HEAD BOLT. SCREW , Replaced By: N910143008016
265
PULLEY
272
FAN ,A 068263, Replaced By: A3142001223, +006N000933008050
272
FAN 7-BLADE,A 068264 USED 343 200 71 24 DELIVER ADDITIONALLY 000933 008040
280
INTERMEDIATE PIECE FAN
295
SCREW STOP TO BATTERY CASE
302
SCREW (NECKED-DOWN BOLT),FAN MOUNTING
310
V-BELT ALTERNATOR,545241
999
WATER PUMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 430644 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A3142002901
999
SPRING WASHER , Replaced By: N000137008212
