Поз.
Артикул
Описание
10
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 105724, Replaced By: A0031517401
10
STARTING MOTOR , Replaced By: A0031518601
10
STARTING MOTOR , Replaced By: A0031518801
10
STARTING MOTOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0041515901
10
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 325960YEAR OF MANUFACTURE 1993 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0041518601
10
STARTING MOTOR24 V/4 KW, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
20
BUSHINGTO 004 151 58 01
23
BEARINGTO 004 151 58 01
26
PINIONTO 003 151 04 01/74 01
26
PINION , Replaced By: A0011513213
26
PINION , Replaced By: A0011514113
26
PINIONTO 004 151 86 01, Replaced By: A0011514913
26
PINIONTO 004 151 58 01/003 151 87 01
32
BUSHING STARTER PINION TO 003 151 04 01/74 01
32
BUSHINGTO 004 151 58 01
38
BUSHING STARTER PINION TO 004 151 58 01/003 151 87 01
40
CONTROL LEVERTO 004 151 58 01/003 151 87 01
40
CONTROL LEVERTO 001 151 96 01
40
CONTROL LEVERTO 004 151 86 01
41
SCREW , Replaced By: A0009909130
42
NUT AT FILTER BRACKET
43
SPRING WASHER , Replaced By: N000137008212
45
EXCITER COILTO 003 151 04 01/74 01/88 01
45
EXCITER COIL , Replaced By: A0001519255
45
EXCITER COIL , Replaced By: A0001519255
48
SCREWTO 003 151 87 01
48
SCREWTO 004 151 58 01
48
SCREWTO 004 151 86 01
58
SPRINGTO 003 151 87 01
58
SPRINGTO 004 151 58 01
65
BUSHINGTO 004 151 58 01/003 151 87 01
65
BUSHING COMMUTATOR END SHIELD TO 004 151 86 01
75
CARBON BRUSH SET
85
CLAMPING BOLT ARMATURE TO 004 151 58 01/003 151 87 01
85
REPAIR KIT , Replaced By: A0001500572
85
REPAIR KITTO 003 151 04 01/74 01
94
SOLENOID SWITCHTO 004 151 86 01
94
SOLENOID SWITCH , Replaced By: A0011524710
94
SOLENOID SWITCHTO 003 151 04 01/74 01,001 151 96 01
94
SOLENOID SWITCHTO 003 151 86 01/88 01,004 151 59 01
110
INTERMEDIATE PIECE STARTING MOTOR INTERMEDIATE FLANGE
114
NUT
120
ALTERNATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 845546, Replaced By: A0071542302
120
ALTERNATOR14V/65A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
126
BALL BEARING , Replaced By: A0059812225
126
BALL BEARINGTO 005 154 32 02
132
BALL BEARINGTO 005 154 34 02
136
RECTIFIERTO 005 154 83 02,006 154 67 02
136
RECTIFIER , Replaced By: A0001545716
140
SEAL RINGTO 005 154 34 02
147
CONDENSER
153
GASKET
160
REPAIR KIT
160
REPAIR KIT , Replaced By: A0001500472
166
REGULATOR AND CUT-OUT , Replaced By: A0001541805
166
REGULATOR AND CUT-OUTTO 005 154 32 06
172
SPRING
180
CARBON BRUSH SETTO 007 154 27 02
182
SPRING WASHER ALTERNATOR CONNECTION W
182
SPRING WASHER HEATER PLUG CABLE HARNESS
184
NUT , Replaced By: N304032005005
184
NUT BALL PIVOT TO LEVER
186
FAN ALTERNATOR
194
BRACKET ALTERNATOR
200
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
206
SPRING WASHER CAB FLOOR
206
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
212
NUT STRAP TO SUPPORT
220
SCREW ALTERNATOR MOUNTING
226
SPRING WASHER STEERING COLUMN BRACKET TO CAB
232
WASHER SUPPORT TO ALTERNATOR TO 352 150 09 73
238
NUT AIR CLEANER ELEMENT
252
CLAMPING BOLT FOR V-BELT TENSIONING
252
CLAMPING BOLT , Replaced By: A4031500572
256
BUSHING
260
SCREW CLAMPING BOLT TO CYLINDER CRANKCASE
266
NUT TIGHTENER PULLEY TO LEVER
275
CLAMPING PIECE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3141550228
275
CLAMPING PIECE TIGHTENER PULLEY
282
SCREW MOUNTING PLATE,SHOCK ABSORBER CROSS MEMBER & SHIM TO FRAME SIDE MEMBER M 12X45
310
GROUND CABLE GENERATOR TO ENGINE SUPPORT
314
SPRING WASHER ALTERNATOR CONNECTION D+
318
NUT , Replaced By: N304032005005
