Поз.
Артикул
Описание
460
BRACKET BRACKET TO SHACKLE, FROM CHASSIS 5 086743,UP TO CHASSIS SEE SA 17015/16-/19
460
BRACKET BRACKET TO SHACKLE, FROM CHASSIS 5 086743,UP TO CHASSIS SEE SA 17015/16-/19
465
RIVET GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS 10X26 MM
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
548
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING , Replaced By: A0004297830
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING SUPPLY, RED
548
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
548
BRAKE LINE COUPLING , Replaced By: A0004299630
548
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
548
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
548
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
551
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
551
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
551
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
551
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
551
BRAKE LINE COUPLING BRAKE,YELLOW GRAU
551
BRAKE LINE COUPLING BRAKE,YELLOW GRAU
551
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
551
BRAKE LINE COUPLING , Replaced By: A0004299730
551
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
551
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
551
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
551
BRAKE LINE COUPLING , Replaced By: A0004297930
551
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
551
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
551
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
551
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
554
SEAL RING"WABCO"
554
SEAL RING"WABCO"
554
SEAL RING"WABCO"
554
SEAL RING"WABCO"
554
SEAL RING , Replaced By: A0004292184
554
BRAKE LINE COUPLINGTO 000 429 38 30
554
SEAL RING , Replaced By: A0004296930
557
SEAL RING"GRAU"
557
SEAL RINGTO 000 429 38 30
560
COVER"WABCO", NOT USED
560
COVER SUPPLY, RED "WABCO"
560
COVERTO 000 429 49 30
560
COVERTO 000 429 51 30,4 434235
560
COVER"WABCO", NOT USED
560
COVER SUPPLY, RED "WABCO"
563
SEAL RING"GRAU"
563
SEAL RING30X2 MM,BOSCH
566
VALVE TAPPET22X4 MM,BOSCH
566
SEAL RING22X4 MM,BOSCH
566
SEAL RING , Replaced By: A0049978240, +001A0004290483
566
SEAL RING33X2.5 MM,BOSCH
566
SEAL RING25X2 MM,BOSCH
569
GROOVED PINTO 000 429 51 30,4 434235
572
REPAIR KITTO 000 429 63 30
572
REPAIR KITTO 000 429 78 30,4 434236
572
REPAIR KIT"KNORR"
572
REPAIR KIT BRAKE LINE COUPLING TO 000 429 61 30,62 30,KNORR,4 434235
572
REPAIR KITTO 000 429 63 30
572
REPAIR KITTO 000 429 78 30,4 434236
572
REPAIR KITTO 000 429 37 30
572
REPAIR KIT BRAKE LINE COUPLING "WABCO"
572
REPAIR KIT BRAKE LINE COUPLING "KNORR"
575
FITTING BRAKE LINE COUPLING TO BRACKET
575
FITTING BRAKE LINE COUPLING TO BRACKET
578
NUT BRACKET TO SIDE MEMBER
578
NUT BRACKET TO SIDE MEMBER
581
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
581
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
584
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
584
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
587
FITTING DELIVERY LINE TO PUMP
587
FITTING DELIVERY LINE TO PUMP
590
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
593
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
596
WASHER BRACKET TO LEFT SIDE MEMBER
596
WASHER BRACKET TO LEFT SIDE MEMBER
599
WASHER BRACKET TO LEFT SIDE MEMBER
599
WASHER BRACKET TO LEFT SIDE MEMBER
599
WASHER BRACKET TO LEFT SIDE MEMBER
599
WASHER BRACKET TO LEFT SIDE MEMBER
599
WASHER , Replaced By: A3609902340
603
BRAKE VALVE TRAILER PARKING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
606
CUPBOSCH
609
CUPBOSCH
612
VALVE DISCTO 000 429 48 30
615
T-FITTING (SAFETY VALVE)
618
ELBOW FITTING TWO-WAY VALVE,CONNECTION "1.2"
618
ELBOW FITTING , Replaced By: A0019904371
621
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
624
T-FITTING INSIDE AND OUTSIDE AIR RESERVOIRS, FRONT CONNECTION
624
T-FITTING , Replaced By: A0019901070
627
O-RING CHECK VALVE TO AIR RESERVOIR
630
THRUST RING CHECK VALVE TO AIR RESERVOIR
630
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
633
NUT CHECK VALVE TO AIR RESERVOIR
636
SEAL RING LINE CONNECTION
639
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
642
SEAL RING LINE CONNECTION
645
BREATHER FILTER. FILTER TRAILER CONTROL VALVE,CONNECTION: "4"
648
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
651
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
651
NUT , Replaced By: N913004008001
654
BRACKET
657
BRACKET
660
NUT BRACKET TO SIDE MEMBER
660
NUT AIR CLEANER ELEMENT
666
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
666
SCREW , Replaced By: N308676012012
669
NUT PLATFORM MOUNTING
675
PIN TRAILER CONTROL VALVE, UP TO CHASSIS 4 282707,AND FROM CHASSIS 8 000001
678
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
681
BALL SOCKET ROD TO BALL PIVOT
684
NUT
687
SECURING CLIP. CIRCLIP
999
REPAIR KIT PARKING BRAKE TO 001 430 16 81
999
VALVE PARKING BRAKE KNORR
999
COVERING BRACKET TO FRAME SIDE MEMBER, UP TO CHASSIS 4 282707,AND FROM CHASSIS 8 000001
999
BRACKET
999
SUPPORT RIGHT AIR RESERVOIR
999
BRACKET BRAKE LINE COUPLING TO REAR CROSS MEMBER, UP TO CHASSIS 4 282707,AND FROM CHASSIS 8 000001
999
BRACKET TWO-WAY VALVE, 314.0.2 ALL,316.0.2 ALL,318.051-054 UP TO CHASSIS 4 383113,318.056-599 UP TO CHASSIS 4 373946 EXCEPT FOR FOOTN.15
999
BRACKET , Replaced By: A3853530440
