Поз.
Артикул
Описание
8
OIL FILLER NECK
8
OIL FILLER NECK , Replaced By: A3520107064, +001A0009971348
15
OIL FILLER NECK
23
SEAL RING OIL FILLER PIPE
23
SEAL RING
25
CAP OIL REFILLING
27
GASKET , Replaced By: A1020180380
27
GASKETTO 352 010 01 68
27
GASKET
27
GASKET , Replaced By: A1020180080
47
SEAL RING
47
SEAL RING OIL FILLER PIPE
87
CAP OIL REFILLING
89
COVER WITH BREATHER FILTER AND CHECK VALVE
91
GASKET , Replaced By: A1020180080
91
GASKET
91
SEALING RING. GASKET
91
GASKET , Replaced By: A1020180380
91
GASKETTO 352 010 01 68
97
SCREW FITTING RETURN
99
SEAL RING VALVE TO VALVE,K 025179
105
BREATHER PIPE ,298066
109
BREATHER PIPE ,298066
109
BREATHER PIPE ,635894
113
SEAL RING LINE CONNECTION
113
SEAL RING VALVE TO VALVE,K 025179
115
SEAL RING RELAY VALVE,CONNECTION: "20"
117
SCREW PLUG
117
FITTING
119
FITTING
121
HOLLOW SCREW
121
HOLLOW SCREW BREATHER PIPE TO CONNECTION FITTING
147
AIR INTAKE PIPE
149
BRACKET
151
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
153
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
153
SCREW , Replaced By: N304017008039
155
HOSE FAN SHROUD
157
CLAMP HOSE 70-90X13 MM
157
CLAMP , Replaced By: N000000000674
161
BREATHER PIPE
163
SEAL RING LINE CONNECTION
165
HOLLOW SCREW
167
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
169
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
171
CLAMP
171
CLAMP HOSE TO FITTING AND TO OIL TANK
173
NOZZLE THROTTLE
175
CLAMP LINES TO BRACKET
177
SCREW EXHAUST PIPE TO BRACKET
179
NUT
179
NUT , Replaced By: N304032008006
183
CLAMP HOSE TO FITTING AND TO OIL TANK
185
BRACKET
187
BREATHER PIPE
189
CLAMP , Replaced By: A1109950401
189
CLAMP FLEXIBLE SHAFT
189
CLAMP FUEL LINE TO BRACKET
191
SCREW STEERING COLUMN PANELLING M 5X12
193
LOCK WASHER BRACKET TO STEERING COLUMN END
195
NUT TACHOGRAPH TO BRACKET
197
SCREW PLUG
199
SEAL RING VALVE TO VALVE,K 025179
999
EXPANSION PLUG , Replaced By: A3520100019
999
HOSE , Replaced By: A3520183482
999
OIL SEPARATOR , Replaced By: A4030100162
999
OIL SEPARATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 511373, Replaced By: A3520100062
999
FILTER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0000184460
999
OIL SEPARATOR , Replaced By: A0000185935
999
FILTER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 460466, Replaced By: A0000182635
999
OIL SEPARATOR
999
OIL SEPARATOR , Replaced By: A0000185735
999
OIL SEPARATOR , FROM ENGINE 234538 YEAR OF MANUFACTURE 1992
999
BRACKET
999
CLAMP , Replaced By: N916016032201
999
HOSE , Replaced By: A4969970082
999
LOOM TIE
999
LOOM TIE , Replaced By: N916017020000
999
LOOM TIE , Replaced By: N916017070000
999
LOOM TIE , Replaced By: N916017025000
999
LOOM TIE , Replaced By: N000000000668
999
COVER , Replaced By: A3140101216
999
OIL FILLER NECK , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3520106964
999
OIL FILLER NECK , Replaced By: A3520107164
999
OIL FILLER NECK , Replaced By: A3520107564
999
BRACKET , Replaced By: A3520181840
999
BREATHER PIPE , Replaced By: A3140102270
999
BREATHER PIPE , Replaced By: A3140100970
999
BREATHER PIPE , Replaced By: A3140102570
999
BREATHER PIPE ,298065, Replaced By: A3140101670, +001N900271015080
999
BREATHER PIPE ,298065, Replaced By: A3140101770, +001N900271015080
999
BREATHER PIPE
999
COVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 370475, Replaced By: A3140101716, +001A3140183240, +001N000933008130, +001N916017040000
999
BREATHER PIPE
999
HOSE , Replaced By: A3140180482
999
HOSE , Replaced By: A3520183582
999
EXPANSION PLUG , Replaced By: A3660100019
999
CAP , Replaced By: A0000180702
999
BREATHER PIPE
999
BREATHER PIPE
999
COVER COVER WITH PIPE, UP TO ENGINE 978,979 331710 YEAR OF MANUFACTURE 1994
999
OIL FILLER NECK , Replaced By: A3520106164
999
OIL FILLER NECK , Replaced By: A3520106564
999
OIL FILLER NECK , Replaced By: A3520107264
999
OIL FILLER NECK , Replaced By: A3520106864
999
CYLINDER HEAD COVER , Replaced By: A3520105730, +001A0000182935
999
CYLINDER HEAD COVER , Replaced By: A3520108330
999
OIL FILLER NECK , Replaced By: A3520109464
999
COVER
999
ANGLE , Replaced By: A3520180141
999
GASKET , Replaced By: A3520180180
999
ANGLE PRESSURE GAUGE LINE LEADING TO PARTICLE FILTER, TO BE ADAPTED DURING ASSEMBLY
999
GASKETTO 352 010 01 68
999
PIPE OIL FILLER NECK, NOT USED
999
HOSE INTAKE PIPE TO BREATHER PIPE,OM 352
999
HOSE , Replaced By: A3520183082
999
HOSE , Replaced By: A3520183082
999
HOSE , Replaced By: A3520183082
999
HOSE , Replaced By: A3520183082
999
HOSE , Replaced By: A3520183582
999
BRACKET ,352.900-412-520919
999
BRACKET OIL FILLER NECK TO CYLINDER HEAD
999
INTAKE PIPE , Replaced By: A3521302301
999
HOSE HOSE TO AIR INTAKE PIPE AND TO INTAKE PIPE SOCKET
999
HOSE , Replaced By: N900271018017
999
HOSE FAN SHROUD
999
COVER PUSH ROD CHAMBER COVER
999
HOSE , Replaced By: A3520182182
999
HOSE HOSE TO AIR INTAKE PIPE & TO AIR COMPRESSOR & ENGINE BREATHER,RESP., ORDER BY THE METER
999
OIL DRIP PAN , THE OLD PART MUST NOT BE INSTALLED ON THE ITEMS LISTED OPPOSITE, Replaced By: A3520100062
999
HOSE , Replaced By: A3520182182
999
HOSE , Replaced By: A3520182182
999
HOSE , Replaced By: A4255280482
999
HOSE , Replaced By: A3909970682
999
PIPE SOCKET
999
HOSE , ORDER BY THE METER
999
CAP , Replaced By: A3520100168
999
CLAMP25-40X13 MM
999
SCREW , Replaced By: N304017008039
999
SCREW , Replaced By: A4609900601
999
NUT , Replaced By: N304032008006
999
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
CLAMP , Replaced By: A0069970490
999
GASKET AT CYLINDER HEAD COVER
