Поз.
Артикул
Описание
4
STEERING BOX ASSEMBLY , Replaced By: A3174601001
4
STEERING BOX ASSEMBLY
340
STEERING SHAFT , Replaced By: A3174600109
340
STEERING SHAFT
344
STEERING SHAFT , Replaced By: A0004622101
344
STEERING SHAFT
346
BUSHING
348
BEARING RING
356
COUPLING COLLAR , FROM IDENT NO. 001765 EXCEPT FOR, 003051-003071,003074-003077,003096,003099,003102,003104,003105,003108,003109,003110,003112,003115, 003125,003145,003146.
360
SCREW
362
LOCK , UP TO IDENT NO. 001764 ALSO INSTALLED ON, 003051-003071,003074-003077,003096,003099,003102,003104,003105,003108,003109,003110,003112,003115, 003125,003145,003146.
368
NUT
370
STEER.COLUMN JACKET TUBE
372
CLAMP
374
SCREW BRACKET TO BELL HOUSING
376
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
378
NUT BRACKET TO SUPPORT AND TO END PIECE
380
BUSHING
384
RING
386
SPRING
388
WOODRUFF KEY
392
NUT SPRING SHACKLE TO SPRING REAR BRACKET
396
CONTACT PIECE , Replaced By: A0004640319
396
CONTACT PIECE
450
HOSE , Replaced By: A0079973082
450
HOSE
456
LINE , Replaced By: A3174600624
456
LINE HIGH PRESSURE, FROM HOSE TO STEERING
462
UNION NUT RETURN LINE
464
SEAL CONE
468
LINE LOW PRESSURE, FROM HOSE TO STEERING
472
UNION NUT FEED LINE
476
SEAL CONE
482
MOUNTING CLAMP. CLAMP DE-AERATION LINE TO BRACKET,4 465189
484
CLAMP , Replaced By: A1109950401
484
CLAMP FUEL LINE TO BRACKET
486
BRACKET
492
HOSE
496
LINE LOW PRESSURE,FROM PIPE TO OIL TANK
498
HOSE
510
HYDRAULIC PUMP , 001778, Replaced By: A3174600780
510
HYDRAULIC PUMP , 001778, Replaced By: A3174600780
510
HYDRAULIC PUMP , 001778
514
COVER , 001778
516
SEAL RING , 001778
518
COVER , 001778
520
SEAL RING , 001778
522
SEAL RING , 001778
524
NUT STOP LIGHT SWITCH TO PEDAL BEARING BRACKET
526
STUD , 001778
528
WASHER , 001778
530
SPRING , 001778
532
FILTER , 001778
534
NUT , 001778
538
SEAL RING , 001778 NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
542
SEAL RING , 001778 NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
546
WOODRUFF KEY , 001778
562
SEAL RING , 001778
564
FITTING , 001778
566
BRACKET
572
SCREW , Replaced By: A0039901101
572
SCREW REFRIGERANT LINE TO COMPRESSOR,5 017486
574
SPRING WASHER STEERING COLUMN BRACKET TO CAB
576
PULLEY
578
WASHER
580
SPRING WASHER CAB FLOOR
582
NUT
592
NARROW V-BELT12.5X1200
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW , Replaced By: N304017010053
999
SCREW PIPE ELBOW TO BRACKET M 10X50
999
SCREW END PIECE TO EXHAUST PIPE M 12X30
999
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
LOCK WASHER T-FITTING TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
CLAMP , Replaced By: N000000000667
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET,4 410133
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017010030
999
SCREW , Replaced By: N304017012020
999
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT BALL PIVOT TO LEVER
999
NUT , Replaced By: N304032008006
999
NUT COVER PLATE
999
NUT , Replaced By: N308673016001
999
NUT CLAMP, TWO-HOLE, UP TO CHASSIS 5 034559, FROM CHASSIS SEE SERIE
999
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
NUT STEERING SHOCK ABSORBER TO STEERING ARM
999
NUT TORSION BAR TO FRAME
999
NUT DRAG LINK TO LEVER
999
STUD BOLT
999
SCREW BRACKET TO CROSS MEMBER
999
SCREW CLAMP TO DRAG LINK
999
SCREW SHOCK ABSORBER TO UPPER BEARING BRACKET,5 261497
999
SCREW SHOCK ABSORBER TO TOP BRACKET
999
SCREW , Replaced By: N308676012012
999
SCREW STEERING BRACKET TO FRAME
999
999
SCREW STEERING SHAFT BEARING TO CAB
999
GREASE NIPPLE , Replaced By: N071412008102
999
GREASE NIPPLE
999
GREASE NIPPLE
999
GREASE NIPPLE PROTECTIVE TUBE
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
HEX. HEAD. SCREW BRACKET TO TRANSMISSION CASE
999
SCREW CLUTCH TO FLYWHEEL
999
999
SCREW CONSOLES TO SIDE MEMBER M 10X25
999
LOCK RING , Replaced By: A0079942041
999
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
999
SPRING WASHER
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
WASHER BRACKET TO FRAME
999
WASHER , Replaced By: N000125017016
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
COTTER PIN , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN LEVER TO SUPPORT
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN TO SECURE BRAKE CABLE
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
COTTER PIN ROD TO LEVER
999
COTTER PINTO 345 460 94 05
999
SCREW PLUG SOCKET TO COVERING
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0004621796
999
999
999
SIGNAL RING
999
SIGNAL RING ,006548,001,002,006,008,009,015,041, Replaced By: A3204640215, +001A0004640437, +001A3214640062, +001A3204640182
999
999
PIN
999
BRACKET , 014426, Replaced By: A3224640034, +001N072573001006
999
999
SCREW STEERING SHOCK ABSORBER TO BRACKET, FROM IDENT NO. 001928 ALSO INSTALLED ON 001904,001906-001920,001922-001926.
999
SCREW STEERING SHOCK ABSORBER TO BRACKET, UP TO IDENT NO. 001927 EXCEPT FOR 001904,001906-001920,001922-001926.
999
BRACKET LEFT, FROM IDENT NO. 001928 ALSO INSTALLED ON 001904,001906-001920,001922-001926.
999
STEERING INTERMEDIATE ARM , 004714
999
999
BRACKET AT CROSS MEMBER, UP TO IDENT NO. 001927 EXCEPT FOR 001904,001906-001920,001922-001926.
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
999
FIRMENZEICHEN AM LENKRAD. BADGE
999
CONTACT PLATE. PLATE ,009343, Replaced By: A0004640417, +001A3224600040, +001A3224640050, +001A3214640062, +001A3204640182
999
LOCK STOP TO BEARING BRACKET
999
NUT DRAG LINK END M 24X1.5
999
SNAP RING REAR, FROM IDENT NO. 796991 EXCEPTO 801111
999
999
999
SEALING CORD , Replaced By: A0119973645
