Поз.
Артикул
Описание
235
T-FITTING
235
T-FITTING AT HAND BRAKE VALVE, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 872788 EXCEPT FOR, 500033-599999
236
O-RING CHECK VALVE TO AIR RESERVOIR
237
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
237
THRUST RING CHECK VALVE TO AIR RESERVOIR
238
NUT CHECK VALVE TO AIR RESERVOIR
240
BRAKE BOOSTER , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
241
PROTECTIVE CAP , Replaced By: A0004311087
241
PROTECTIVE CAP BRAKE BOOSTER
243
REPAIR KIT BRAKE BOOSTER
245
SCREW PLUG , Replaced By: N000908022011
245
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
247
SCREW PLUG , Replaced By: N007604014110
247
SCREW PLUG FUEL TANK
249
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
249
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
249
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236
251
SCREW-IN FITTING HYDRAULIC LINE TO CLUTCH BOOSTER
255
TEST CONNECTION
255
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
255
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
255
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
257
SEAL RING LINE CONNECTION
259
SEAL RING FUEL LINE TO FEED PUMP
261
FITTING , Replaced By: A0039979972
261
FITTING
262
ELBOW FITTING , Replaced By: A0019907571
262
ELBOW FITTING 3/2-WAY VALVE,CONNECTION "1"
263
SCREW PLUG 4/2-WAY VALVE
264
SEAL RING , Replaced By: N007603010110
264
SEAL RING PNEUMATIC VALVE
264
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
265
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
266
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
267
CONSOLE BRAKE BOOSTER TO INTERMEDIATE LEVER
267
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
268
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
269
SCREW END PIECE TO EXHAUST PIPE M 10X25
275
COVERING
278
SCREW , Replaced By: N304017008008
278
HEXAGON HEAD BOLT PROTECTIVE PLATE TO BRACKET
278
SCREW , Replaced By: N304017008016
278
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
279
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
280
NUT , Replaced By: N913004008001
280
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
281
BRACKET
282
SCREW CONSOLE TO SIDE MEMBER
282
SCREW , Replaced By: N304014008001
282
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
283
NUT AIR CLEANER ELEMENT
283
NUT PLATFORM MOUNTING
283
NUT , Replaced By: N913004008001
283
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
284
WASHER BEARING BRACKET TO FRAME
285
VALVE
287
REPAIR KITTO 001 429 55 44
289
ADAPTER FITTING
292
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
292
SHEET METAL SCREW BRACKET TO FLOOR PLATE
296
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
296
SHEET METAL SCREW BRACKET TO FLOOR PLATE
297
CLAMP , Replaced By: A3604300143
297
CLAMP , Replaced By: N916016008200
297
CLAMP ,K 147121, Replaced By: N000000000319
297
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
298
SCREW COVER PLATE TO BRACKET
299
NUT , Replaced By: N913002006009
299
NUT OIL TANK TO BRACKET
355
LINE , Replaced By: A0004296201
355
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
999
LEVER BRAKE LINKAGE,4 282707
999
CONSOLE BRAKE BOOSTER,4 282707
999
RESERVOIR FROM AIR RESERVOIR TO ANTI-FREEZE DEVICE
999
LEVER
999
BRACKET
999
BRACKET TWO-WAY VALVE, UP TO IDENT NO. 4 282707 AND FROM IDENT NR. 8 000001-8 001702
999
BRACKET
999
CONSOLE
999
BRACKET
999
CLAMP , NOT USED
999
RESERVOIR , Replaced By: A3454308205
999
CONSOLE AIR RESERVOIR TO SUPPORT
999
RESERVOIR , Replaced By: A0024320501
999
CONSOLE , Replaced By: A3604301311
999
WIRE120 MM, UP TO IDENT NO. 4 477510 FROM IDENT NO. SEE UNIT MICROFICHE MODEL 750.5 ORDER BY THE METER
999
SEAL RING SCREW PLUG
999
PULL ROD , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
DIAPHRAGMTO 344 429 73 44
999
DIAPHRAGM , Replaced By: A0004290745
999
DIAPHRAGM
999
T-FITTING AIR RESERVOIR I
999
VALVE
999
VALVE (SAFETY VALVE)
999
VALVE , Replaced By: A3075530107
999
BLEEDER VALVE. VALVE , Replaced By: A0004201055
999
WASHER , Replaced By: A0004311176
999
COVER. THREADED UNION
999
SPRING RETAINER BRAKE MASTER CYLINDER
999
WASHERTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
WASHER
999
BRAKE CYLINDER. BRAKE BOOSTER , Replaced By: A0004319114
999
BRAKE BOOSTER , Replaced By: A0004319014
999
VALVE , Replaced By: A0004320807
999
VALVE , Replaced By: A0004320807
999
SPRING
999
PLUG
999
BRAKE MASTER CYLINDER , Replaced By: A0024300701
999
VALVE
999
BRAKE MASTER CYLINDER ,4 282707
999
RESERVOIR , Replaced By: A0034322501
999
RESERVOIR40L,276 MM,8.5 BAR
999
LEVER BRAKE LINKAGE,6951998 0000014 2827078 000001
999
BRAKE INTERMEDIATE SHAFT
999
LEVER
999
LEVER
999
ROD FROM HAND BRAKE LEVER TO FRONT INTERMEDIATE LEVER
999
CONSOLE , 10/20 695199 50/60 695577 8 0000014 2827078 000001-8 001702
999
BRACKET , 10/20 695199-986791 50/60 695577-986791
999
BRACKET ,4 282707
