Поз.
Артикул
Описание
4
AIR CLEANER OIL BATH KNECHT
4
AIR CLEANER (PAPER AIR CLEANER) KNECHT
4
AIR CLEANER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0110941702
4
AIR CLEANER (PAPER AIR CLEANER) MANN & HUMMEL
4
AIR CLEANER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0110940902
8
FILTER ELEMENT AIR CLEANER MANN & HUMMEL
8
FILTER ELEMENT
12
FILTER BOWL LOWER PART TO 007 094 68 02
12
FILTER BOWL
16
FASTENERKNECHT
16
FASTENER
18
GASKET INSIDE, ON OM 352 126-PS ENGINE,UP TO ENGINE 041863
18
GASKET INSIDE
20
GASKET OUTSIDE, ON OM 352 126-PS ENGINE,UP TO ENGINE 041863
20
GASKET OUTSIDE
22
NUT
23
WASHER FELT
24
MAINTENANCE INDICATORTO 011 094 09 02/17 02
25
RUBBER BUFFER OIL BATH AIR CLEANER MOUNTING,701361-965592
30
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
30
NUT , Replaced By: N913004008001
32
SCREW END PIECE TO EXHAUST PIPE M 10X25
32
SCREW BRACKET TO SIDE MEMBER
32
SCREW , Replaced By: N304017010002
34
NUT STRAP TO BRACKET
34
NUT , Replaced By: N910113010000
36
WASHER RADIATOR TO RUBBER MOUNTING
36
WASHER , Replaced By: N000125010532
40
SCOOP FIRE WALL,LEFT
40
SCOOP FIRE WALL,LEFT
41
SCREW BRACKET TO COVERING
41
SCREW , Replaced By: N000000001145
42
WASHER COMPRESSED AIR LINE TO BRACKET
42
WASHER , Replaced By: N009021006208
44
COVER AIR INTAKE
45
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
46
SCREW CLAMP MOUNTING M 6X16
46
SCREW , Replaced By: N000000001146
47
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
48
NUT OIL TANK TO BRACKET
48
NUT , Replaced By: N913002006009
49
RIVET COVER TO SCOOP,4 633346
50
WASHER COMPRESSED AIR LINE TO BRACKET
50
WASHER , Replaced By: N009021006208
51
AIR INTAKE PIPE INTAKE SCOOP
52
AIR INTAKE PIPE FROM INTAKE PIPE TO AIR CLEANER
52
AIR INTAKE PIPE FROM INTAKE PIPE TO AIR CLEANER
55
REINFORCEMENT FROM INTAKE PIPE TO AIR CLEANER
56
RUBBER SEAL FROM INTAKE PIPE TO AIR CLEANER
58
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
58
SCREW CLAMP MOUNTING M 6X16
58
SCREW , Replaced By: N000000001146
59
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
60
HOSE FROM INTAKE PIPE TO AIR CLEANER
60
AIR INTAKE PIPE FROM INTAKE PIPE TO AIR CLEANER
60
HOSE OIL BATH AIR CLEANER,724595
61
SEAL RING AIR INTAKE PIPE
62
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
62
CLAMP , Replaced By: A0059972990
62
CLAMP , Replaced By: N000000000675
63
HOSE DRAIN
64
CLAMP
64
CLAMP , Replaced By: N000000000670
76
COVERING AT ENGINE,4 497835
77
COVERING COVER PLATE TO CAB REAR PANEL,4 659294
78
SCREW CLAMP MOUNTING M 6X16
78
SCREW , Replaced By: N000000001146
79
SHEET METAL SCREW BRACKET TO FLOOR PLATE
79
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
80
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
81
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
81
WASHER , Replaced By: N009021005205
82
CLAMP MUFFLER TO BRACKET,4 775769
83
BRACKET INTAKE PIPE TO CAB
83
BRACKET AIR INTAKE PIPE
84
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
85
NUT AIR CLEANER ELEMENT
86
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
87
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
87
SCREW , Replaced By: N304017008016
88
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
89
EXPANSION PLUG BREATHER HOSE THRU FLOOR PLATE,775095
90
GROMMET ENGINE COVERING
91
PLUG FIRE WALL,RIGHT
92
CAP STARTER PILOT, 808268
999
HOSE , Replaced By: A3185280908
999
KEY WITHOUT LOCK UNDEFINED
999
FILTER ELEMENTTO 007 094 68 02
999
ADHESIVE TAPE , Replaced By: A0019899585
999
ADHESIVE TAPE , ORDER BY THE METER
999
AIR CLEANER
999
BRACKET AIR CLEANER,965592
999
BRACKET INTAKE PIPE TO CAB
999
BRACKET ,4 497834, Replaced By: A3185200122, +001A3185280482
999
HOSE , Replaced By: A3189970482
999
HOSE INTAKE MUFFLER TO ENGINE,4 256298
999
AIR INTAKE PIPE , Replaced By: A3185281208
999
HOSE ,4 497834, Replaced By: A3185280482, +001A3185200122
999
BRACKET INTAKE PIPE TO CAB
999
AIR INTAKE PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 282707, Replaced By: A3185281508
999
HOSE , Replaced By: A3189970482
999
PLUG , Replaced By: A3520100285
999
CLAMP AIR INTAKE PIPE TO BRACKET
