Поз.
Артикул
Описание
2
GASKET P.T.O. TO TRANSMISSION
2
GASKET COVER TO CASE REAR COVER
2
GASKET , Replaced By: A3522611980
2
GASKET , Replaced By: A3522611680
2
GASKET , Replaced By: A3522611180
4
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
4
SPRING WASHER , Replaced By: N000137008212
6
SCREWM 8X40
11
P.T.O.
15
CASE
18
SEAL RING
20
SHIFTING ROD
22
LOCK-OUT
24
SCREW SHIFTING FORK TO SHIFTING ROD
26
COLLAR. SLEEVE
28
EXPANSION PLUG ENGINE LEFT AND RIGHT SUPPORTS
30
INTERLOCK PIN
32
SPRING
34
SCREW PLUG
36
SEAL RING FUEL LINE TO FEED PUMP
38
DRIVE SHAFT
40
SLIDING COLLAR DRIVE SHAFT
42
GROOVED BALL BEARING
44
SNAP RING
46
RETAINING RING BEARING TO DRIVE SHAFT
48
NEEDLE BEARING DRIVE SHAFT
50
LOCK STEERING KNUCKLE,TOP AND BOTTOM
50
LOCK RING
52
GASKET BRACKET TO TRANSMISSION CASE
54
COVER
56
SEAL RING
56
RADIAL SEAL RING
58
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
58
SPRING WASHER , Replaced By: N000137008212
60
SCREW COVER TO P.T.O. CASE
62
KEY COUPLING FLANGE TO P.T.O.
64
NUT DRAG LINK TO LEVER
66
LEVER (SHIFTING SHAFT)
72
BALL SOCKET ROD TO BALL PIVOT
74
SECURING CLIP. CIRCLIP
76
PULL ROD SHIFTING ROD
78
YOKE OPERATING ROD
80
PIN PULL ROD TO TRANSMISSION SHIFT LEFER
999
COVER AT TRANSMISSION CASE REAR COVER,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
999
UNIT IDENTIFICATION PLATE
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
SCREW , Replaced By: N304017008018
999
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
999
BALL PIVOT
999
SNAP RING
999
SCREW SUPPORT TO FENDER
999
NUT
