Поз.
Артикул
Описание
86
TANK EXPANSION TANK TO SEAT BOX,4 205212
86
TANK EXPANSION TANK TO SEAT BOX,4 205212
88
RADIATOR CAPTO 335 500 12 03
90
GASKET O.D., 37 MM
92
TANK , 318.351,352,353,354,372 UP TO IDENT NO. 4 497675,318.356,357,358,359,392 UP TO IDENT NO. 4 477457
92
TANK , 318.351,352,353,354,372 UP TO IDENT NO. 4 497675,318.356,357,358,359,392 UP TO IDENT NO. 4 477457
92
TANK , 318.351,352,353,354,372 UP TO IDENT NO. 4 497675,318.356,357,358,359,392 UP TO IDENT NO. 4 477457
96
RADIATOR CAPTO 335 500 12 03
96
RADIATOR CAPTO 335 500 12 03
96
RADIATOR CAPTO 335 500 12 03
98
RADIATOR CAP
98
RADIATOR CAP
98
RADIATOR CAP
98
RADIATOR CAP
104
GASKET O.D., 37 MM
106
SCREW , Replaced By: N304017008021
106
SCREW PIPE CLAMP
106
SCREW PIPE CLAMP
106
SCREW PIPE CLAMP
108
WASHER , Replaced By: N009021008213
108
WASHER BRACKET TO LEFT SIDE MEMBER
108
WASHER BRACKET TO LEFT SIDE MEMBER
108
WASHER BRACKET TO LEFT SIDE MEMBER
110
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
112
SPACER TUBE EXPANSION TANK TO SEAT BOX
112
SPACER TUBE EXPANSION TANK TO SEAT BOX
112
SPACER TUBE EXPANSION TANK TO SEAT BOX
114
NUT , Replaced By: N913004008001
114
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
114
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
114
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
138
HOSE LEAK LINE, ORDER BY THE METER
138
HOSE LEAK LINE, ORDER BY THE METER
140
HOSE FROM EXPANSION TANK TO ENGINE, NOT FOR USE WITH MERCEDES-BENZ CAB ORDER BY THE METER
142
HOSE FROM EXPANSION TANK TO ENGINE, 318.351,352,353,354,372 UP TO IDENT NO. 4 497675,318.356,357,358,359,392 UP TO IDENT NO. 4 477457
142
HOSE FROM EXPANSION TANK TO ENGINE, 318.351,352,353,354,372 UP TO IDENT NO. 4 497675,318.356,357,358,359,392 UP TO IDENT NO. 4 477457
142
HOSE OVERFLOW, EXPANSION TANK,4 205213
144
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
144
CLAMP25-40X13 MM
144
CLAMP25-40X13 MM
144
CLAMP25-40X13 MM
146
BRACKET COMPRESSED AIR LINE
148
LINE FROM EXPANSION TANK TO ENGINE, NOT FOR USE WITH MERCEDES-BENZ CAB
148
LINE FROM EXPANSION TANK TO ENGINE, NOT FOR USE WITH MERCEDES-BENZ CAB
150
BRACKET COOLING WATER HOSE TO ENGINE,4 755510
152
SCREW END PIECE TO EXHAUST PIPE M 10X25
152
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
154
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
156
WASHER , Replaced By: N000125010532
156
WASHER RADIATOR TO RUBBER MOUNTING
158
CLAMP OIL FILLER PIPE TO BRACKET
160
SCREW , Replaced By: N304017006018
160
SCREW COVER PLATE TO COVER PLATE M 6 X 12
162
NUT , Replaced By: N913002006009
162
NUT OIL TANK TO BRACKET
164
HOSE DE-AERATION,4 205212
164
HOSE DE-AERATION,854137-4 205212
166
HOSE80 MM, OM 326,L UP TO CHASSIS 004265,LP UP TO CHASSIS 001437 ORDER BY THE METER
168
CLAMP , Replaced By: N000000000671
168
CLAMP
170
SEAL RING AT OPERATING VALVE
172
SCREW PLUG , Replaced By: N000908012009
172
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
174
HOSE FROM RADIATOR TO THERMOSTAT,4 467135
178
CLAMP , Replaced By: N000000000671
178
CLAMP
180
HOSE FROM RADIATOR TO WATER PUMP,4 822760
180
HOSE FROM RADIATOR TO WATER PUMP,4 822760
180
HOSE FROM RADIATOR TO WATER PUMP,4 822760
180
HOSE FROM RADIATOR TO WATER PUMP,4 822761
188
CLAMP , Replaced By: N000000000671
188
CLAMP
190
HOSE80 MM, OM 326,L UP TO CHASSIS 004265,LP UP TO CHASSIS 001437 ORDER BY THE METER
226
CLAMP LINE MOUNTING
228
SHIM BRACKET TO LEFT SIDE MEMBER
230
SCREW COVER PLATE TO BRACKET
232
NUT , Replaced By: N913004006001
232
NUT PUMP TO BRACKET
234
CLAMP , Replaced By: N916016016201
234
CLAMP OIL DIPSTICK TO BRACKET
234
CLAMP , Replaced By: A6739950001
234
CLAMP FEED LINE TO THERMOSTAT
234
CLAMP DELIVERY AND SUCTION LINES TO STEERING
262
COOLING WATER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK
262
COOLING WATER PIPE BREATHING, FROM RADIATOR TO EXPANSION TANK, 318.351,352,353,354,372 UP TO IDENT NO. 4 497675,318.356,357,358,359,392 UP TO IDENT NO. 4 477457
262
COOLING WATER PIPE BREATHING, FROM RADIATOR TO EXPANSION TANK, 318.351,352,353,354,372 UP TO IDENT NO. 4 497675,318.356,357,358,359,392 UP TO IDENT NO. 4 477457
264
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
264
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
264
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
266
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
266
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
266
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
266
CLAMP , Replaced By: N916017011001
268
CLAMP ,K 147121, Replaced By: N000000000319
268
CLAMP ,K 147121, Replaced By: N000000000319
268
CLAMP ,K 147121, Replaced By: N000000000319
268
CLAMP , Replaced By: N916016008200
268
CLAMP , Replaced By: A3604300143
270
SCREW COVER PLATE TO BRACKET
270
SCREW COVER PLATE TO BRACKET
270
SCREW COVER PLATE TO BRACKET
272
WASHER COMPRESSED AIR LINE TO BRACKET
272
WASHER COMPRESSED AIR LINE TO BRACKET
272
WASHER COMPRESSED AIR LINE TO BRACKET
272
WASHER , Replaced By: N009021006208
274
NUT PUMP TO BRACKET
274
NUT PUMP TO BRACKET
274
NUT PUMP TO BRACKET
274
NUT , Replaced By: N913004006001
999
RUBBER BUFFER EXHAUST MUFFLER
999
BRACKET , Replaced By: A3184291540
999
BRACKET , Replaced By: A3185000331
999
FAN SHROUD RADIATOR
999
LINE , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 375862, Replaced By: A3185011682
999
LINE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 375862, Replaced By: A3185011982
999
FAN SHROUD , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:4 467135, Replaced By: A3185051155
999
FAN SHROUD , Replaced By: A3185001155
999
LINE , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 375862, Replaced By: A3185060360
999
HOSE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 375862, Replaced By: A3185011682
999
HOSE ,854136, Replaced By: A3185011282, +001A3185000572, +002N916017025000
999
HOSE , Replaced By: N073379006203
999
HOSE DE-AERATION,854136
999
HOSE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:4 467135, Replaced By: A3185011982
999
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3185060640
999
CLAMP LINE MOUNTING
999
TANK , Replaced By: A3815001649
999
SHIM , Replaced By: A3815010495
