Поз.
Артикул
Описание
10
RADIATOR , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE EXHAUST STOCK OF OLD PART NUMBER FIRST UP TO CHASSIS 4 610757, Replaced By: A3185002002
14
SEAL RING FUEL LINE TO FEED PUMP
18
SCREW PLUG FUEL TANK
18
SCREW PLUG , Replaced By: N007604014110
19
BREATHER PIPETO 318 500 19 02
20
LOCKTO 318 500 19 02
21
SCREW WATER DRAIN
22
SUPPORT LEFT,4 467136
30
WASHER BRACKET TO COVERING
30
WASHER , Replaced By: N009021010209
34
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
34
SCREW , Replaced By: N304017010028
40
BRACKET RADIATOR TO CONSOLE AT ENGINE FRONT CROSS MEMBER,4 467136
44
SCREW REAR EXHAUST PIPE TO MUFFLER
48
WASHER RADIATOR TO RUBBER MOUNTING
48
WASHER , Replaced By: N000125010532
52
NUT BRACKET TO SUPPORT AND TO END PIECE
56
RUBBER MOUNTING
56
RUBBER MOUNTING
60
NUT STRAP TO BRACKET
60
NUT , Replaced By: N910113010000
70
FAN SHROUD
75
SCREW LICENSE PLATE TO BRACKET
75
SCREW LICENSE PLATE TO BRACKET
75
SCREW , Replaced By: N304017006020
79
WASHER COMPRESSED AIR LINE TO BRACKET
79
WASHER COMPRESSED AIR LINE TO BRACKET
79
WASHER , Replaced By: N009021006208
83
NUT PUMP TO BRACKET
83
NUT PUMP TO BRACKET
83
NUT , Replaced By: N913004006001
90
RADIATOR STRUT ,4 467135
94
NUT BRACKET TO SUPPORT AND TO END PIECE
98
RUBBER RING SHOCK ABSORBER MOUNTING
102
SPACER TUBE RADIATOR STRUT TO SUPPORT AND TO CAB
106
WASHER BRACKET TO COVERING
106
WASHER , Replaced By: N009021010209
110
NUT BRACKET TO SUPPORT AND TO END PIECE
120
PROTECTIVE GRILL
124
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
128
NUT STRAP TO BRACKET
128
NUT , Replaced By: N910113010000
999
GASKET O.D., 52 MM
999
GASKET O.D., 37 MM
999
RADIATOR CAP
999
RADIATOR CAP FILLER NECK
999
RADIATOR CAP FILLER NECK
999
GROMMET , UP TO CHASSIS 603580 ON SPECIAL REQUEST, SEPARATE BRAKE FLUID RESERVOIR FOR HYDRAULIC BRAKE
999
RUBBER BUFFER EXHAUST MUFFLER
999
RUBBER BUFFER BRACKET TO SUPPORT
999
LOOM TIE LINE MOUNTING 280 MM
999
RUBBER RING AT CAB REAR PANEL
999
GROMMET
999
BRACKET , Replaced By: A3185000331
999
EXPANSION PLUG EXPANSION TANK TO CAB REAR PANEL,4 497676-4 603307
999
LINE , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 375862, Replaced By: A3185011682
999
SUPPORT RIGHT
999
BRACKET EXPANSION TANK TO CAB REAR PANEL,4 497676 FOR USE WITH MERCEDES-BENZ CAB
999
BRACKET , NOT FOR USE WITH MERCEDES-BENZ CAB4 886778
999
FAN SHROUD , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:4 467135, Replaced By: A3185051155
999
LINE , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 375862, Replaced By: A3185060360
999
SUPPORT RADIATOR TO CONSOLE AT ENGINE FRONT CROSS MEMBER,4 467136
999
SUPPORT RADIATOR TO CONSOLE AT ENGINE FRONT CROSS MEMBER,4 467136
999
RADIATORBEHR,4 467136
999
HOSE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 375862, Replaced By: A3185011682
999
SHIM CAB,4 755510
999
COOLING WATER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK
999
COOLING WATER PIPE ENGINE BREATHING,4 497676-4 822760 FOR USE WITH MERCEDES-BENZ CAB
999
HOSE OVERFLOW, EXPANSION TANK,4 205213
999
COOLING WATER PIPE DE-AERATION,4 497676 FOR USE WITH MERCEDES-BENZ CAB
999
COOLING WATER PIPE ENGINE BREATHING,4 822761 FOR USE WITH MERCEDES-BENZ CAB
999
HOSE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.:4 467135, Replaced By: A3185011982
999
HOSE COOLING WATER PIPE TO THERMOSTAT HOUSING,4 467136
999
HOSE FROM RADIATOR TO WATER PUMP,4 497676-4 822760 FOR USE WITH MERCEDES-BENZ CAB
999
HOSE FROM RADIATOR TO WATER PUMP,4 822761 FOR USE WITH MERCEDES-BENZ CAB
999
HOSE FROM RADIATOR TO WATER PUMP,4 822761
999
HOSE FROM PIPE TO HEATER UNIT,4 811761
999
BRACKET COOLING WATER LINE TO BODY,4 822761
999
BRACKET COOLING WATER HOSE TO ENGINE,4 755510
999
PIPE HEATING WATER PIPE TO ENGINE,4 822761
999
GROMMET ELECTRIC CABLE THRU WINDOW SILL
999
CLAMP LINE MOUNTING
999
TANK , Replaced By: A3815001649
999
TANK
999
TANK BEHIND CAB, WITH 387.134 ON VEHICLES HAVING NO MERCEDES BENZ CAB UP TO CHASSIS 4 3673984 661211
999
SHIM , Replaced By: A3815010495
999
SHIM STRAP, 415 5 014668 416 5 000515 417 4 972023
999
RIVET ,4 497676
999
GROMMET ROCKER PANEL TO FRAME,5 328147
999
SHEET METAL SCREW FUEL STRAINER SCREEN TO FUEL TANK
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
CLAMP25-40X13 MM
999
CLAMP
999
SCREW CLAMP MOUNTING M 6X16
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW EXPANSION TANK TO CAB REAR PANEL, 318.351,352,353,354,372 FROM IDENT-NO. 4 497676,318.356,357,358,359,392 FROM IDENT-NO. 4 477458 ONLY ON VEHICLES HAVING MERCEDES-BENZ CAB
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW SPRING CLAMP TO SPRING LEAF NO.2
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW , Replaced By: N007981004339
999
SHEET METAL SCREW , Replaced By: N007981004233
999
SHEET METAL SCREW , Replaced By: N000000000459
999
SCREW , Replaced By: N007985006580
999
SCREW , Replaced By: N000000001146
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW
999
RIVETED NUT
999
CLAMP HOSE TO FITTING AND TO OIL TANK
999
CLAMP , Replaced By: N000000000667
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
CLAMP , Replaced By: N000000000671
