Поз.
Артикул
Описание
11
BEARING BRACKET , Replaced By: A3452900119
11
31
31
BEARING TUBE , Replaced By: A3522900336
37
BUSHING
37
BUSHING , Replaced By: A3442940150
37
BUSHING , Replaced By: A3529920901
43
GREASE NIPPLE PROTECTIVE TUBE
48
PIN ,A 006845
56
PEDAL BRAKE PEDAL
56
PEDAL
60
BUSHING
60
BUSHING , Replaced By: A3442940150
60
BUSHING
64
68
72
76
BUSHING
81
SPACER RING PEDAL TO BEARING BRACKET
81
SPACER RING AS REQUIRED 3.50 MM
87
LOCK RING SHACKLE TO CONSOLE TO 393 326 00 63,965965
95
100
107
WASHER CLUTCH PEDAL AND BRAKE PEDAL
111
SEAL RING CLUTCH PEDAL AND BRAKE PEDAL
111
SEAL WASHER
118
PEDAL PLATE , Replaced By: A3452907224
118
PEDAL PLATE CLUTCH PEDAL
118
PEDAL PLATE CLUTCH AND BRAKE
126
PAD BRAKE AND CLUTCH LEVERS
130
BEARING BRACKET BRAKE BOOSTER, INAPPLICABLE TO SUPERCHARGING SYSTEM609835
140
BEARING TUBE
144
148
LOCK WASHER FITTING TO BRACKET
152
SCREW
156
LEVER , INAPPLICABLE TO SUPERCHARGING SYSTEM
160
164
BUSHING
168
GREASE NIPPLE PROTECTIVE TUBE
172
SPRING , Replaced By: A3649937010
176
PULL ROD SUPPORT TO CONSOLE, TO BE ADAPTED DURING ASSEMBLY
181
YOKE PULL ROD TO LEVER
181
YOKE , Replaced By: A0009961501
185
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
193
ROD FRONT
198
TURNBUCKLE
207
BALL SOCKET BELT TIGHTENER
212
RELEASE LEVER ,KB846166
212
RELEASE YOKE , Replaced By: A3402500013
212
RELEASE LEVER IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 327 293 01 11,302 991 00 15,KB846165 INAPPLICABLE TO SUPERCHARGING SYSTEM
216
BALL PIVOT RELEASE YOKE
216
BALL PIVOT RELEASE YOKE
220
SPRING LOCK RELEASE LEVER TO RELEASE BEARING, UP TO CHASSIS 4 691315, FROM CHASSIS 4 691316 SEE STANDARD VERSION
224
BEARING OUTSIDE, INAPPLICABLE TO SUPERCHARGING SYSTEM609835
224
BEARING OUTSIDE, UP TO IDENT NO. 148036 EXCEPT FOR 140555,142078
229
BRACKET INSIDE, INAPPLICABLE TO SUPERCHARGING SYSTEM609835
229
BRACKET RELEASE YOKE TO BELL HOUSING, UP TO IDENT NO. 148036 EXCEPT FOR 140555,142078
237
RELEASE BEARING , Replaced By: A3402500215
237
RELEASE BEARING , Replaced By: A3522500515
237
RELEASE BEARING CLUTCH, UP TO IDENT NO. 4 473926,FROM IDENT NO. SEE MICROFICHE STANDARD
241
RELEASE BEARING , UP TO IDENT NO. 4 473926,FROM IDENT NO. SEE MICROFICHE STANDARD
241
RELEASE BEARING
246
STRIP RELEASE BEARING TO 340 250 02 15, UP TO IDENT NO. 4 473926,FROM IDENT NO. SEE MICROFICHE STANDARD
246
STRIP ,KB846165
250
SPRING CLUTCH PEDAL
254
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
SPRING WASHER , Replaced By: N000137010205
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW PIPE CLAMP
999
SNAP RING DOUBLE LEVER TO BRACKET
999
BALL PIVOT AT SHIFT LEVER
999
PIN , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
999
NUT L.H. THREAD
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW , Replaced By: N304017010002
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017008021
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW MOUNTING AND RAIL TO LEAF SPRING
999
WASHER VIBRATION ABSORBER TO BRACKET
999
WASHER , Replaced By: N000433010510
999
HEADLESS SETSCREW , Replaced By: A3529900080
999
SPRING WASHER SHIFTING ROD TO BRACKET
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
COTTER PIN CYLINDER TO BRACKET
999
999
999
999
999
WASHER PEDAL TO PEDAL LEVER
999
999
PEDAL PLATE BRAKE
999
LEVER , Replaced By: A3512907834
999
999
999
ROD REAR
999
999
ROD CLUTCH,A 012247
999
999
PEDAL PLATE
999
SPACER RING AS REQUIRED 3.25 MM
999
BALL PIVOT ,FB001827
999
999
COVERTO 352 250 01 15, UP TO IDENT NO. 145736 ALSO INSTALLED ON: 145741,145768,145770,145774,145786,145787,145795,145807,145808,145819,145825,145830,145837,145840, 145846,145860,145861,145888,145901,145907,145910,145911,145913-145917,146138. EXCEPT FOR 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660,145697,145701.
999
RING AS REQUIRED 3.0 MM
