Поз.
Артикул
Описание
3
CAMSHAFT ,085524 INAPPLICABLE TO ENGINES WITH CAMSHAFT DRIVEN INJECTION TIMING DEVICE
5
COMPRESSOR (ASSEMBLY KIT),FOUR-HOLE MOUNTING 94 MM
5
COMPRESSOR ASSEMBLY KIT
5
COMPRESSOR ASSEMBLY KIT
6
CONNECTING ROD ,082679
6
CONNECTING ROD
24
SCREW CONNECTING ROD COVER TO CONNECTING ROD, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
30
NUT
36
BUSHING ,082679
36
BUSHING ,082678
42
BEARING SHELL REPAIR SIZE III 31.25 MM
42
BEARING SHELL REPAIR SIZE I 31.75 MM
42
BEARING SHELL PARTS KIT,REPAIR SIZE II 31.50 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
42
BEARING SHELL CONNECTING ROD BEARING SHELLS,31.90 MM STANDARD SIZE I,082679
42
BEARING SHELL PARTS KIT,REPAIR SIZE III 31.25 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
42
BEARING SHELL STANDARD,082678
42
BEARING SHELL PARTS KIT,REPAIR SIZE I 31.75 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
42
BEARING SHELL CONNECTING ROD BEARING SHELLS,32.00 MM STANDARD SIZE,082679
42
BEARING SHELL REPAIR SIZE II 31.50 MM
42
BEARING SHELL STANDARD SIZE I 31.90 MM
42
REPAIR KIT , Replaced By: A3525860213
42
REPAIR KIT , Replaced By: A3521312033
54
PISTON , Replaced By: A3441301417
60
PISTON RING , Replaced By: A0001317711
66
PISTON RING , Replaced By: A0001317711
72
PISTON RING , Replaced By: A3521311111
78
PISTON PIN
84
LOCK RING
86
PISTON RING PARTS KIT,STANDARD 77.000 MM, TO 321 130 00 17
86
PISTON RING STANDARD 77.000 MM, TO 344 130 14 17
90
GASKET AS REQUIRED 0.30 MM,085523
90
GASKET AS REQUIRED 0.50 MM,085523
90
GASKET , Replaced By: A3211310080
90
GASKET , Replaced By: A3211310180
93
GASKET , Replaced By: A3661310280
93
GASKET , Replaced By: A3661310180
93
GASKET AS REQUIRED 0.65 MM
93
GASKET AS REQUIRED 0.90 MM
96
CYLINDER LINER , Replaced By: A3401300008
102
CYLINDER LINER WITH PISTON,082678
102
CYLINDER LINER WITH PISTON,082679
102
CYLINDER LINER STANDARD
102
CYLINDER LINER WITH PISTON
102
CYLINDER LINER WITH PISTON 94 MM
108
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
108
SCREW , Replaced By: N910105008005
114
CYLINDER HEAD
114
CYLINDER HEAD
126
WASHER
132
VALVE DISC
135
VALVE CYLINDER HEAD
138
VALVE DISC
141
VALVE (PRESSURE VALVE)
144
VALVE DISC
144
VALVE DISC
156
SPRING
162
SPRING CASE
162
SPRING CASE
163
SEAL RING
164
NUT PRESSURE VALVE TO CYLINDER HEAD
164
NUT PRESSURE VALVE TO CYLINDER HEAD
164
NUT PRESSURE VALVE TO CYLINDER HEAD
165
SCREW BEARING BRACKET TO CAB M 8X30
166
REPAIR KIT AIR COMPRESSOR CYLINDER HEAD
166
REPAIR KIT AIR COMPRESSOR CYLINDER HEAD
168
GASKET
168
GASKET
168
GASKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 082678, Replaced By: A3521310480
174
SCREW
999
NUT , Replaced By: N080705022002
999
FLANGE
999
GASKET , Replaced By: A3211310180
999
REPAIR KIT , Replaced By: A0001317711
999
REPAIR KIT , Replaced By: A3525860313
999
REPAIR KIT , Replaced By: A3525860413
999
REPAIR KIT , Replaced By: A3525860513
999
REPAIR KIT , Replaced By: A3525860613
999
REPAIR KIT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 082678, Replaced By: A3521300020
999
PISTON77,00 MM
999
PISTON RING , Replaced By: A0001317711
999
REPAIR KIT , Replaced By: A3521312133
999
REPAIR KIT , Replaced By: A3521312233
999
REPAIR KIT , Replaced By: A3521312333
999
REPAIR KIT , Replaced By: A3521312433
999
CLAMP , Replaced By: A0059970190
