Поз.
Артикул
Описание
7
CABLE HARNESS MAIN CABLE HARNESS,A 067872
7
CABLE HARNESS MAIN CABLE HARNESS, FROM IDENT NO.: A 066249A 067871
7
CABLE HARNESS MAIN CABLE HARNESS, UP TO IDENT NO.: A 066248
8
GROMMET HOSE LINE PROTECTION TO 000 546 16 30,71 30
8
GROMMET5.0 MM
8
GROMMET3.0 MM
9
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
9
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
9
PIN BUSHING , Replaced By: A0075457426
9
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
9
PIN BUSHING , Replaced By: A0005453726
9
PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 4-6 MM2
9
PIN BUSHING , Replaced By: A0075458226
11
PIN BUSHING HOUSING BIPOLAR
13
PIN BUSHING HOUSING 3-POLE
15
PIN BUSHING HOUSING 4-POLE
17
PIN BUSHING HOUSING 6-POLE
19
PIN BUSHING HOUSING 8-POLE
21
PLUG SOCKET HOUSING. PROTECTIVE CAP
23
PLUG
23
PIN BUSHING HOUSING 3-POLE,4 483482
25
PLUG HAZARD WARNING LIGHT SWITCH, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-5999995 107260
27
PIN BUSHING HOUSING
30
CONTACT PIECE
32
BOOT PIN BUSHING
37
CABLE HARNESS FROM FRONT PLUG CONNECTION TO REAR CABLE CONNECTOR
39
PLUG HOUSING 8-POLE
41
BOOT. PLUG SOCKET FRAME MOUNTED CABLE HARNESS,TB099687
41
PLUG SOCKET , Replaced By: A3805402181
41
PLUG SOCKETTO 341 540 82 10
44
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
47
GROMMET3.0 MM
50
LOOM TIE , Replaced By: A0019978390
50
LOOM TIE LINE MOUNTING
50
LOOM TIE , Replaced By: A0019978490
53
CLAMP
53
FIXING CLAMP. CLAMP , Replaced By: A0005460875
56
CLAMP , Replaced By: A0005460875
59
SCREW SWITCH TO APPARATUS PLATE, 10/20 UP TO IDENT NO. 4 422632, 50/60 UP TO IDENT NO. 4 422723
62
LOCK WASHER CLAMP TO BRACKET
65
NUT BALL PIVOT TO LEVER
84
SWITCH QUICK-RELEASE VALVE,A 080183
84
SWITCH , Replaced By: A0005456314
91
FUSE BOX TERMINALS 1-2,3-4,5-6,AND 8-12 BRIDGED OVER, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-599999
98
SCREW ELECTRIC CABLE TO FUSE BOX
105
LOCK WASHER
112
FUSEA8
112
FUSE , Replaced By: A0005458334
112
FUSEA16
119
CAP FUSE BOX, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-599999
126
SHEET METAL SCREW , Replaced By: N007981004233
140
SENDER UNIT TEMPERATURE GAUGE, FOR VEHICLES HAVING HIGH CAB 344
140
SENDER UNIT , Replaced By: A3455427717
141
SWITCH RELAY VALVE,CONNECTION "2",RIGHT
141
SWITCH SUPPLY PRESSURE,5 966147
142
SWITCH TWO-CIRCUIT BRAKE VALVE
142
SWITCH EXHAUST BRAKE,K 251255
144
SENDER UNIT OIL PRESSURE GAUGE
144
SENDER UNIT , Replaced By: A0045428917
148
SEAL RING
170
CABLE CONNECTION 6-POLE. CABLE CONNECTOR ,4 248860
170
CABLE CONNECTOR 6-POLE
171
COVERING WITH GASKET
172
SCREW
176
LOCK WASHER T-FITTING TO BRACKET
180
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
268
CLIP
268
CLIP
272
PIN BUSHING , Replaced By: A0075458226
276
FUSE BOX , Replaced By: A3455458301
280
FUSE
284
PLUG SOCKET HOUSING. PROTECTIVE CAP
288
SCREW ELECTRIC CABLE TO FUSE BOX
292
LOCK WASHER
332
SENDER UNIT , Replaced By: A0015448032
332
SENDER UNIT , Replaced By: A0025447332
334
SENDER UNIT
338
SCREW
339
LOCK WASHER T-FITTING TO BRACKET
340
NUT
342
RELAY
343
SCREW LICENSE PLATE MOUNTING
344
NUT CLAMP TO BRACKET
345
LOCK WASHER RESISTOR
999
PIN BUSHING HOUSING HAZARD WARNING LIGHT SWITCH,5 220080
