Поз.
Артикул
Описание
728
LINE FROM AIR RESERVOIR T-FITTING TO FITTING, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
766
LINE FROM FITTING TO FITTING, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
767
LINE FROM FITTING TO BRAKE HOSE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
768
LINE FROM HOSE TO HAND BRAKE VALVE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
769
UNION NUT LINE CONNECTION
770
GLAND LINE CONNECTION
771
LINE FROM HAND BRAKE VALVE TO THE OPEN AIR, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
772
UNION NUT , USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
773
GLAND LINE CONNECTION
774
CONNECTION FITTING ,880809
791
LINE FROM HAND BRAKE VALVE FITTING II TO COMPRESSED AIR HOSE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
792
BRAKE HOSE
793
HOSE CLAMP. CLAMP COMPRESSED AIR HOSE TO COMPRESSED AIR LINE
794
LINE FROM COMPRESSED AIR HOSE TO FITTING, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
795
LINE FROM HAND BRAKE VALVE TO RELAY VALVE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
796
LINE FROM FITTING TO RELAY VALVE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
800
UNION NUT LINE CONNECTION
801
GLAND LINE CONNECTION
802
CONNECTION FITTING ,880809
825
VALVE QUICK-RELEASE VALVE
826
DIAPHRAGMTO 341 431 70 65
827
SEAL RINGTO 341 431 70 65
828
ELBOW FITTING AT QUICK-RELEASE VALVE
829
ELBOW FITTING AT QUICK-RELEASE VALVE
830
ELBOW FITTING AT QUICK-RELEASE VALVE
831
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
832
SEAL RING
833
SWITCH SUPPLY PRESSURE,5 966147
833
SWITCH RELAY VALVE,CONNECTION "2",RIGHT
834
BRACKET SPRING LOAD ACCUMULATOR
835
NUT , Replaced By: N304032008006
836
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
837
SCREW INTERMEDIATE BEARING TO BRACKET M 8X20
838
VALVE TWO-WAY VALVE, B03543/06/08 UP TO IDENT NO.: 549429
841
REPAIR KIT , B03543/06/08 UP TO IDENT NO.: 549429
850
CONNECTOR TWO-WAY VALVE
851
CONNECTOR AT TWO-WAY VALVE
852
ADAPTER FITTING TWO-WAY VALVE
853
LINE TWO-WAY VALVE T-FITTING,TEST CONNECTION, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
854
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
854
THRUST RING BUTT SCREW CONNECTION
855
SEAL RING LINE CONNECTION
856
LINE FROM TWO-WAY VALVE TO LEFT BRAKE CYLINDER
857
LINE FROM TWO-WAY VALVE TO RIGHT BRAKE CYLINDER
858
UNION NUT BUTT SCREW CONNECTION
859
GLAND LINE CONNECTION
860
THRUST RING BUTT SCREW CONNECTION
860
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
861
SEAL RING LINE CONNECTION
901
VALVE , Replaced By: A0029975836
901
VALVE , Replaced By: A0039971736
902
REPAIR KIT , Replaced By: A0024302260
902
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
903
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
904
FITTING OIL LINE CONNECTION
905
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
906
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
907
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
908
BRACKET SOLENOID VALVE
909
SCREW OIL TANK TO BRACKET
910
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
911
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
912
HEX. HEAD. SCREW TRANSMISSION CASE TOP COVER TO TRANSMISSSION CASE, UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
913
LOCK WASHER
914
NUT LEVER TO SHIFTING SHAFT
915
LINE FROM T-FITTING TO SOLENOID VALVE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
916
LINE FROM SOLENOID VALVE,CONNECTION "A",TO TWO-WAY VALVE, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
DIAPHRAGM , Replaced By: A0004290745
999
SLIDETO 000 431 50 14,000 431 24 14
999
CUP , Replaced By: A0015864342
