Поз.
Артикул
Описание
121
ELBOW FITTING AT CYLINDER
121
ELBOW FITTING TEST CONNECTION TO BRACKET
122
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
122
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
123
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
124
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
431
CROSS FITTING AT PRESSURE REGULATOR
435
PIN AT PRESSURE REGULATOR
439
UNION NUT
443
GLAND , Replaced By: A0019901667
447
LINE FROM 3/2-WAY VALVE TO PRESSURE REGULATOR
451
UNION NUT
455
GLAND , Replaced By: A0019901667
459
FITTING
463
UNION NUT
467
GLAND , Replaced By: A0019901667
471
HOSE PRESSURE GAUGE
475
LINE FROM 3/2-WAY VALVE TO CONNECTOR
475
LINE
479
UNION NUT
483
GLAND , Replaced By: A0019901667
487
CONNECTION FITTING , Replaced By: A0039979172
491
LINE
495
UNION NUT
499
GLAND , Replaced By: A0019901667
999
NUT
999
VALVE PART
999
PROTECTIVE CAP
999
SEAL RING
999
T-FITTING
999
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
999
MAGNET12 V, TO 345 997 74 36
999
SEAL RING LINE CONNECTION
