Поз.
Артикул
Описание
5
BEARING BRACKET ,4 247126 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 655107, Replaced By: A3812901219
8
STUD BOLT PEDAL UNIT TO WINDOW SILL GIRDER
11
WASHER TRAILER PLUG SOCKET TO BRACKET
14
NUT , Replaced By: N913004008001
17
STOP PEDAL ASSEMBLY
20
LOCK RING , Replaced By: A0079942041
23
LOCK PEDAL TO BEARING BRACKET
26
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
29
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
32
PEDAL , Replaced By: A3812901016
35
PAD , Replaced By: A1072910182
38
SPRING CLUTCH PEDAL RESET
41
PIVOT PIN PEDAL TO BEARING BRACKET
44
NEEDLE BEARING
44
NEEDLE BEARING
44
NEEDLE BEARING , Replaced By: A0119813410
47
SPACER TUBE CLUTCH PEDAL
50
LOCK RING
53
ROD OVER-CENTER ACTING SPRING
53
ROD OVER-CENTER ACTING SPRING
56
NEEDLE BEARING JOINT TO PIN
56
NEEDLE BEARING JOINT TO PIN
56
NEEDLE BEARING JOINT TO PIN
59
PIN PUSH ROD TO PEDAL
62
WASHER PULL ROD TO SHIFT LEVER
65
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
68
NUT GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER
71
SPRING RETAINER SPRING TO PUSH ROD
74
SPRING (DEAD CENTER SPRING) 35 MM
77
SPRING RETAINER SPRING TO PUSH ROD
80
STOP
83
PIN CLUTCH PEDAL,5 238024
86
NUT
