Поз.
Артикул
Описание
8
LINE FROM FITTING TO FITTING
8
LINE FROM SPRING LOAD ACCUMULATOR TO DOUBLE FITTING
8
LINE FROM OEVERFLOW VALVE TO FOOT OPERATED VALVE
24
GLAND , Replaced By: A0019901667
27
SLEEVE LEAK LINE
32
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
32
T-FITTING BETWEEN THE LINES
32
FITTING
40
LINE FROM DOUBLE FITTING TO OPERATING VALVE
40
LINE FROM DOUBLE FITTING TO OPERATING VALVE
40
LINE FROM DOUBLE FITTING TO OPERATING VALVE
48
UNION NUT
56
GLAND , Replaced By: A0019901667
60
SLEEVE LEAK LINE
64
VALVE"WABCO DO BRASIL"
64
VALVE"WESTINGHOUSE"
64
VALVE , Replaced By: A0004342401
72
HANDLETO 000 434 24 01
80
CUP 3/2-WAY VALVE WABCO
88
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
96
SEAL RINGTO 000 434 23 01
120
REPAIR KIT 3/2-WAY VALVE WABCO
120
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
120
REPAIR KIT SMALL SCOPE TO 345 434 71 01
120
REPAIR KIT , Replaced By: A0034301281
136
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
139
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
144
SEAL RING , Replaced By: N007603010110
144
SEAL RING LINE CONNECTION
152
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
160
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
168
NUT , Replaced By: N080705026003
176
LINE FROM OPERATING VALVE TO CONNECTION FITTING
176
LINE FROM OPERATING VALVE TO CONNECTION FITTING
184
UNION NUT
192
GLAND , Replaced By: A0019901667
196
SLEEVE LEAK LINE
200
HOSE PRESSURE GAUGE
224
CLAMP COMPRESSED AIR LINE MOUNTING
232
BRACKET COMPRESSED AIR LINE MOUNTING
240
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
240
CLAMP SENSOR CABLE TO FRONT AXLE
248
SCREW FUEL LINE TO BRACKET
248
SCREW STEERING COLUMN PANELLING M 5X12
256
WASHER , Replaced By: N000433005304
264
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
264
LOCK WASHER T-FITTING TO BRACKET
272
NUT BALL PIVOT TO LEVER
272
NUT
416
SEAL RING LINE CONNECTION
416
SEAL RING LINE CONNECTION
424
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
424
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
425
ELBOW FITTING AT CYLINDER
426
NUT ,D 091466
427
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
427
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
428
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
NUT
999
VALVE PART
999
PROTECTIVE CAP
999
SEAL RING
999
PIN AT PRESSURE REGULATOR
999
T-FITTING
999
MAGNET12 V, TO 345 997 74 36
999
CONNECTION FITTING , Replaced By: A0039979172
