Поз.
Артикул
Описание
121
STEERING WHEEL , 032,033,040,041: UP TO CAB 1606714 132,133,140,141: UP TO CAB 1600091
124
ORNAMENTAL RING
127
CONTACT PLATE
130
ELECTRIC CABLE , 341.250 UP TO CHASSIS A 002103
133
BRACKET
136
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
139
SCREW BRACKET TO CONTACT PLATE M 4X8,A 061071
142
CLAMP
145
SCREW DIODE CASE
148
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
151
HEX. NUT M 4 DIN 934-5 S. NUT FUEL CONSUMPTION DISPLAY
154
CLAMP
157
SCREW CONTACT PLATE TO STEERING WHEEL
160
SPACER TUBE CONTACT PLATE TO STEERING WHEEL
163
SCREW CONTACT PLATE TO STEERING WHEEL
166
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
169
KONTAKTTELLER. CONTACT CUP
172
ISOLIERPLATTE. INSULATING PLATE
175
SPRING
178
KONTAKTSCHEIBE. CONTACT RING
181
NUT
187
SIGNAL RING
190
RATCHET LEVER. LEVER
193
RELEASE SPRING. SPRING
196
RING
199
THRUST WASHER
202
FIRMENZEICHEN AM LENKRAD. BADGE
205
GUMMISCHEIBE. SEAL RING
208
STEERING SUPPORT , 341.250 UP TO CHASSIS A 002103
211
SCREW REINFORCEMENT TO SIDE MEMBER
214
NUT SHOCK ABSORBER TO CONSOLE AND TO CAB,A 053090
262
DRAG LINK FRONT, 341.250 UP TO CHASSIS A 002103
265
DRAG LINK TUBE , 341.250 UP TO CHASSIS A 002103
268
GREASE NIPPLE INTERMEDIATE LEVER
271
BALL SOCKET , Replaced By: A0005860033
274
BALL PIVOT
277
BALL SOCKET , Replaced By: A0004630061, +001A0004631656, +001A0009930105
280
SPRING , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009930105, +001A0004631656, +001A0004630061
283
LOCKING CAP , Replaced By: A0004631656, +001A0004630061, +001A0009930105
286
SNAP RING , 650871
289
DUST CAP
292
NUT DRAG LINK TO LEVER
295
TRUNNION BEARING , 341.250 UP TO CHASSIS A 002103
298
SCREW , Replaced By: N308765014006
301
SCREW BEARING BRACKET TO SUBSTRUCTURE
304
WASHER RAIL TO SUBSTRUCTURE
307
NUT BRACKET TO BATTERY CASE
310
STEERING INTERMEDIATE ARM , 341.250 UP TO CHASSIS A 002103
313
GREASE NIPPLE
316
SPACER WASHER INTERMEDIATE LEVER TO BEARING BRACKET
319
SEAL RING
319
RADIAL SEAL RING , Replaced By: A0079976446
322
SPACER WASHER INTERMEDIATE LEVER TO BEARING BRACKET
325
TAPERED ROLLER BEARING FRONT
328
TAPERED ROLLER BEARING INTERMEDIATE LEVER TO BEARING BRACKET
331
THRUST WASHER STEERING INTERMEDIATE ARM BEARING
334
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
337
CAP AT STEERING INTERMEDIATE ARM
340
SPACER WASHER INTERMEDIATE LEVER TO BEARING BRACKET
343
DRAG LINK REAR, 341.250 UP TO CHASSIS A 002103
349
DRAG LINK TUBE , 341.250 UP TO CHASSIS A 002103
352
SCREW DRAG LINK END TO DRAG LINK, 341.250 UP TO CHASSIS A 002103
355
NUT , L 1113 FROM CHASSIS 071990,LP/LPO 1113 FROM CHASSIS 071679 344.030,032,033,040,041,057,058 UP TO CHASSIS 415524,UP TO CHASSIS SEE SPARE PARTS LIST 732.7
358
DRAG LINK END , 341.250 UP TO CHASSIS A 002103
361
HOUSING , 341.250 UP TO CHASSIS A 002103
364
GREASE NIPPLE INTERMEDIATE LEVER
367
BALL SOCKET , Replaced By: A0005860033
370
BALL PIVOT
373
BALL SOCKET , Replaced By: A0004630061, +001A0004631656, +001A0009930105
376
SPRING , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009930105, +001A0004631656, +001A0004630061
379
LOCKING CAP , Replaced By: A0004631656, +001A0004630061, +001A0009930105
382
SNAP RING , 650871
385
DUST CAP
388
NUT DRAG LINK TO LEVER, 10/20 615359-695198 50/60 615359-695576 ALSO INSTALLED ON 615344,615349.
391
SHOCK ABSORBER , 341.250 UP TO CHASSIS A 002103
394
RUBBER RINGTO 321 463 05 32
397
BUSHING
400
RUBBER RINGTO 321 463 05 32
403
BALL JOINTTO 321 463 05 32
406
GREASE NIPPLE INTERMEDIATE LEVER
409
CLAMPING SLEEVETO 321 463 05 32,344 460 01 66
412
DUST CAPTO 321 463 05 32
415
TUBETO 321 463 05 32
418
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER M 14X1.5X35
421
NUT TORSION BAR TO FRAME
424
NUT , 341.250 UP TO CHASSIS A 002103
427
LOCK PLATE
430
BRACKET
430
BRACKET , Replaced By: A3214630340
433
SCREW
436
NUT SHOCK ABSORBER TO CONSOLE AND TO CAB,A 053090
999
SCREW PLUG , Replaced By: A3029970035
999
COTTER PIN6.3X63 MM
999
COTTER PIN
999
COTTER PIN4X32, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
COTTER PIN SHIFT CASE
999
COTTER PIN , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
COTTER PIN
999
BADGE STEERING
999
999
STEERING BOX COVER , Replaced By: A3214600414, +001A0029900251
999
THRUST RING , Replaced By: A3174630062
999
BALL CUP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3214620537
999
PIN
999
BADGE STEERING WHEEL, NO.8316INO.7C52INO.7B90INO.9051I II I
