Поз.
Артикул
Описание
3
6
12
15
18
GREASE NIPPLE INTERMEDIATE LEVER
21
DRIVE FLANGE
24
UNIVERSAL JOINT CROSS , Replaced By: A3854100231
27
BEARING BUSHING
30
NEEDLE , Replaced By: A3189810287
33
EXPANSION PLUG
36
GREASE NIPPLE
39
SNAP RING2.700 MM
39
SNAP RING2.750 MM
39
SNAP RING2.500 MM
39
SNAP RING2.600 MM
39
SNAP RING2.550 MM
39
SNAP RING2.650 MM
42
SEAL HOLDER , PROPELLER SHAFT WITH BOOT
45
SEAL RING , PROPELLER SHAFT WITH BOOT
48
DRIVE FLANGE
51
UNIVERSAL JOINT CROSS , Replaced By: A3854100231
54
BEARING BUSHING
57
NEEDLE , Replaced By: A3189810287
60
EXPANSION PLUG
63
GREASE NIPPLE
66
SNAP RING2.750 MM
66
SNAP RING2.700 MM
66
SNAP RING2.500 MM
66
SNAP RING2.600 MM
66
SNAP RING2.550 MM
66
SNAP RING2.650 MM
69
BALANCING PLATE AS REQUIRED 60 MM
69
BALANCING PLATE AS REQUIRED 190 MM
69
BALANCING PLATE AS REQUIRED 160 MM
69
BALANCING PLATE AS REQUIRED 95 MM
69
BALANCING PLATE AS REQUIRED 120 MM
69
BALANCING PLATE AS REQUIRED 20 MM
75
BOOT
75
BOOT
78
WIRE RING , WITH BOOT
81
CLAMP , WITH BOOT
84
SCREW , Replaced By: A0079901001
84
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
87
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
90
NUT , Replaced By: N308673010001
999
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
999
999
BEARING BUSHING , Replaced By: A3224100542
