Поз.
Артикул
Описание
833
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
834
PULL ROD
835
TURNBUCKLE
836
NUT BRACKET TO BRACKET
840
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
842
CONNECTOR
842
CONNECTOR , Replaced By: A3224270189
844
PIN PULL ROD TO BRAKE INTERMEDIATE SHAFT
844
PIN PULL ROD TO BRAKE INTERMEDIATE SHAFT
846
GUIDE
848
GROMMET
850
SCREW
852
LOCK WASHER
854
NUT LEVER TO SHIFTING SHAFT
856
BEARING BRACKET BRAKE INTERMEDIATE SHAFT
858
BUSHING
861
GREASE NIPPLE PROTECTIVE TUBE
863
SHIM1.5 MM
863
SHIM0.5 MM
865
SCREW INTERMEDIATE PIECE,ADAPTER HOUSING
867
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
869
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
871
BRAKE INTERMEDIATE SHAFT
871
BRAKE INTERMEDIATE SHAFT , Replaced By: A3414207180
873
THRUST WASHER
875
END PIECE
877
PIN , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
879
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
884
PULL ROD
886
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
888
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
890
YOKE INTERMEDIATE SHAFT
892
PIN PULL ROD TO LEVER
894
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
896
BRAKE SHAFT
900
ADJUSTING LEVER RIGHT
900
ADJUSTING LEVER LEFT
903
STUD
906
NUT
909
SCREW
912
NUT
915
LEVER RIGHT
915
LEVER LEFT
918
SPHERICAL PIECE
921
SPACER TUBE AS REQUIRED 16.0 MM
921
SPACER TUBE AS REQUIRED 14.5 MM
921
SPACER TUBE AS REQUIRED 15.5 MM
921
SPACER TUBE AS REQUIRED 14.0 MM
921
SPACER TUBE AS REQUIRED 15.0 MM
925
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
999
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
999
BREMSSCHLAUCHHALTER. LOCK , Replaced By: A0004280473
999
BRACKET. LOCK , Replaced By: A6525040038
999
CONNECTOR , Replaced By: A0004292736
999
VALVE"BOSCH"
999
DIAPHRAGMTO 000 429 00 44
999
THRUST WASHERTO 000 429 00 44
999
LOCKTO 000 429 00 44
999
SPRING RETAINERTO 000 429 00 44
999
VALVE NIPPLETO 000 429 00 44
999
SPRINGTO 000 429 00 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
SPRINGTO 000 429 00 44
999
VALVE
999
REPAIR KITTO 001 431 06 06,BOSCH 0 481 039 101,5 148812
999
SCREW BRAKE MASTER CYLINDER, UP TO IDENT NO. 734559,FROM CHASSIS,STANDARD EQUIPMENT
999
PRESSURE REGULATORBOSCH,4 208907 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KITTO 001 430 68 01,002 430 19 01
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING AT BRAKE BOOSTER
999
VALVE , Replaced By: A0014296144
999
VALVE , Replaced By: A0024297244
999
PRESSURE REGULATOR , Replaced By: A0024313406
999
REPAIR KITTO 001 429 52 44
999
REPAIR KIT , Replaced By: A0004301407
999
VALVE REAR AXLE AIR RESERVOIR, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
REPAIR KIT , UP TO 625
999
REPAIR KIT , FROM 626
999
999
999
999
999
999
SCREW , Replaced By: H993414320006
999
STUD , Replaced By: A3024230170
999
CLAMP
999
LOCK
999
CLAMP , Replaced By: A3049950120
999
CLAMP , Replaced By: A1109950401
999
BRACKET
999
999
END PIECE , Replaced By: A3224200347, +001A3529910707
999
END PIECE
999
999
999
999
999
999
GROMMET
999
HOSE PRESSURE REGULATOR BREATHING
999
999
999
999
999
999
SPHERICAL PIECE , UP TO REAR AXLE 11016,FROM REAR AXLE SEE SPARE PARTS LIST 816
999
BRACKET COMPRESSED AIR LINE MOUNTING
999
999
999
BRACKET COMPRESSED AIR LINE MOUNTING
999
ELBOW FITTING AT TRUCK-TRACTOR BRAKE VALVE
999
999
999
999
999
999
REPAIR KIT BRAKE BOOSTER
999
999
BRACKET BRAKE HOSE
999
BRAKE CYLINDER. BRAKE BOOSTER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
999
RING
999
SCREW , Replaced By: A3544230171
999
999
SCREW PROTECTION PLATE TO BRACKET
999
COTTER PIN BATTERY COVERING TO A 386 540 70 14
999
COTTER PIN PULL ROD TO LEVER
999
COTTER PIN STRAP TO CONSOLE 20 L
999
COTTER PIN
999
COTTER PINTO 000 431 24 05
999
COTTER PINTO 000 431 24 05
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER TRAILER PLUG SOCKET TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW , Replaced By: N000933008134
999
SCREW BRACKET TO EXHAUST PIPE BRACKET
999
SCREW SCREENING PLATE TO BRACKET,K 142858
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N304017008034
999
NUT BALL PIVOT TO LEVER
999
PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
TURNBUCKLE
999
GLAND , Replaced By: A0019901167
999
SEAL RING
999
SEAL RING LINE CONNECTION
999
SHEET METAL SCREW WIRE CABLE TO MOUNTING CLAMP,774712
999
UNION SCREW , Replaced By: A0004280072
999
SLIP RING. SEAL RING AT DISTRIBUTOR
999
SEAL RING COMPRESSED AIR LINE TO DOUBLE FITTING
999
SLIP RING BRAKE LINE COUPLING
999
THRUST RING , Replaced By: N915065018101
999
UNION NUT
999
DOUBLE FITTING ,376447
999
ELBOW FITTING
999
ELBOW FITTING LINE CONNECTION
999
NUT CHECK VALVE TO AIR RESERVOIR
999
LOOM TIE , ELIMINATED NO LONGER REQUIRED
999
RING , Replaced By: A0005830296
999
UNION NUT , 10/20 UP TO CHASSIS 4 191895,50/60 UP TO CHASSIS 4 189545
999
CLAMP LINE MOUNTING
