Поз.
Артикул
Описание
34
FOLLOWER 1ST AND 2ND SPEED
36
SYNCHRONIZER RING 1ST AND 2ND SPEED TO 000 262 29 35
38
SYNCHRONIZER BODY 1ST AND 2ND SPEED
40
SPRING SPLITTER BOX
42
SPRING SPLITTER BOX
44
END PIECE SPLITTER BOX
46
SPRING 1ST AND 2ND SPEED
50
SLIDING COLLAR 1ST AND 2ND SPEED
52
GEAR 1ST SPEED, THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE
52
GEAR , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002624111
54
FOLLOWER 1ST AND 2ND SPEED
56
SYNCHRONIZER RING 1ST THRU 4TH SPEED
56
SYNCHRONIZER RING , Replaced By: A0002626834
60
SYNCHRONIZER BODY 3RD AND 4TH SPEED,10/20879180, 50/60880936
62
SPRING SPLITTER BOX
64
SPRING SPLITTER BOX
66
END PIECE SPLITTER BOX
70
SPRING 3RD THRU 6TH SPEED TO 336 262 07 34
72
SLIDING COLLAR 1ST THRU 4TH SPEED
76
FOLLOWER 5TH AND 6TH SPEED
80
SYNCHRONIZER RING 1ST THRU 4TH SPEED
80
SYNCHRONIZER RING , Replaced By: A0002626834
82
SYNCHRONIZER BODY 5TH AND 6TH SPEED,10/20879180, 50/60880936
86
SPRING SPLITTER BOX
90
SPRING SPLITTER BOX
92
END PIECE SPLITTER BOX
94
SPRING 3RD THRU 6TH SPEED TO 336 262 07 34
97
SLIDING COLLAR 1ST THRU 4TH SPEED
100
FOLLOWER
100
FOLLOWER , Replaced By: A0002621740
104
SPACER RING AS REQUIRED 3.00 MM,10/20879180, 50/60880936
104
SPACER RING , Replaced By: A0002620651
104
SPACER RING AS REQUIRED 3.50 MM
104
SPACER RING , Replaced By: A0002620451
104
SPACER WASHER , Replaced By: A0002620351
104
SPACER RING AS REQUIRED 3.80 MM
104
SPACER RING AS REQUIRED 4.00 MM,10/20879180, 50/60880936
104
SPACER WASHER , Replaced By: A0002620251
104
SPACER RING , Replaced By: A0002620951
104
SPACER RING AS REQUIRED 4.40 MM,10/20879180, 50/60880936
104
SPACER RING , Replaced By: A0002621151
104
SPACER WASHER , Replaced By: A0002621051
104
SPACER RING AS REQUIRED 4.80 MM,10/20879180, 50/60880936
104
SPACER RING , Replaced By: A0002621351
104
SPACER RING AS REQUIRED 4.90 MM
104
SPACER WASHER , Replaced By: A0002621351
104
SPACER RING , Replaced By: A0002621551
104
SPACER RING AS REQUIRED 5.50 MM
104
SPACER WASHER , Replaced By: A0002621551
104
SPACER RING AS REQUIRED 5.80 MM
104
SPACER WASHER , Replaced By: A0002621651
104
SPACER WASHER , Replaced By: A0002621651
999
SYNCHRONIZER BODY 5TH AND 6TH SPEED
999
SHIFTING FORK , Replaced By: A0002601630
999
SHAFT ,175046, Replaced By: A0002604638, +002A0002640749
999
SWITCH , Replaced By: A0002600771
999
SHAFT ,175046, Replaced By: A0002604738, +002A0002640749
999
SHIFTING FORK , Replaced By: A0002601330
999
SHAFT , Replaced By: A0002604838
999
SHAFT (SHIFTING SHAFT),175047
999
COVER SHIFTING ROD, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
999
GEAR 37/25 TEETH
999
GEAR , Replaced By: A0002621410
999
LOCK DRIVE SHAFT,047093
999
GEAR , Replaced By: A0002621310
999
RING AS REQUIRED 7.60 MM,047093
999
RING AS REQUIRED 7.40 MM,047093
999
GEAR 6TH SPEED
999
SYNCHRONIZER HUB 1ST AND 2ND SPEED,10/50 792025, 20/60 766369
999
SYNCHRONIZER BODY , Replaced By: A0002623135
999
RING AS REQUIRED 7.20 MM,047093
999
RING AS REQUIRED 7.00 MM,047093
999
SLIDING COLLAR REVERSE SPEED
999
RING AS REQUIRED 6.80 MM,047093
999
SLIDING COLLAR 1ST AND 2ND SPEED, WITH AK 6-90 FROM TRANSMISSION 068148,WITH AK 6-80 FROM TRANSMISSION 279574
999
RING AS REQUIRED 6.40 MM,047093
999
GEAR DRIVE GEAR Z50
999
GEAR , Replaced By: A0002624611
999
GEAR 6TH SPEED
999
SPACER WASHER , Replaced By: A0002634652, +001A0002635152
999
SPACER WASHER AS REQUIRED 2.55 MM
999
SPACER WASHER AS REQUIRED 2.50 MM
999
SPACER WASHER , Replaced By: A0002635152
999
SPACER WASHER AS REQUIRED 2.40 MM
999
SPACER WASHER AS REQUIRED 2.35 MM
999
SPACER WASHER AS REQUIRED 2.30 MM
999
SPACER WASHER AS REQUIRED 2.25 MM
999
SPACER WASHER AS REQUIRED 2.20 MM
999
SPACER WASHER AS REQUIRED 2.15 MM
999
SPACER WASHER AS REQUIRED 2.10 MM
999
SPACER WASHER AS REQUIRED 2.05 MM
999
SPACER WASHER AS REQUIRED 2.00 MM
999
SPACER WASHER AS REQUIRED 1.95 MM
999
SPACER WASHER AS REQUIRED 1.90 MM
999
SPACER WASHER AS REQUIRED 3.10 MM
999
SPACER WASHER AS REQUIRED 2.90 MM
999
SPACER WASHER AS REQUIRED 2.45 MM
999
SPACER WASHER , Replaced By: A0002634252
999
SPACER WASHER AS REQUIRED 3.15 MM
999
SPACER WASHER AS REQUIRED 3.20 MM
999
SPACER WASHER AS REQUIRED 3.25 MM
999
SPACER WASHER , Replaced By: A0002632152
999
SPACER WASHER AS REQUIRED 3.35 MM
999
SPACER WASHER AS REQUIRED 1.65 MM
999
SPACER WASHER AS REQUIRED 3.45 MM
999
SPACER WASHER , Replaced By: A0002631752
999
SPACER WASHER AS REQUIRED 3.55 MM
999
SPACER WASHER AS REQUIRED 3.60 MM
999
SPACER WASHER AS REQUIRED 3.65 MM
999
SPACER WASHER , Replaced By: A0002631752, +001A0002634652
999
SPACER WASHER AS REQUIRED 3.75 MM
999
SPACER WASHER AS REQUIRED 3.80 MM
999
SPACER WASHER AS REQUIRED 3.85 MM
999
SPACER WASHER , Replaced By: A0002632452
999
SPACER WASHER AS REQUIRED 3.95 MM
999
SPACER WASHER AS REQUIRED 4.00 MM
999
STRAINER SHIFTING CYLINDER
999
BOOT , Replaced By: A0002640596
999
BOOT , Replaced By: A0002640796
999
BOOT SHIFTING CYLINDER
999
INTERMEDIATE SHAFT
999
HOUSING ,175046 IN ADDITION,AS REQUIRED:1X 003 264 30 52,1X 003 264 36 52,1X 003 264 42 52,1X 003 264 48 52,1X 002 264 59 52,1X 002 264 65 52 IN ADDITION,AS REQUIRED:1X 000 264 20 10,1X 000 264 26 10,1X 000 264 32 10,1X 000 264 38 10,1X 000 264 44 10,1X 000 264 50 10, Replaced By: A0002645402, +001A0002610418, +001A0002614880, +001A0002641174
999
COVER , Replaced By: A0002646310
999
COVER , Replaced By: A0002646410
999
HOUSING ,175046 IN ADDITION,AS REQUIRED:1X 003 264 30 52,1X 003 264 36 52,1X 003 264 42 52,1X 003 264 48 52,1X 002 264 59 52,1X 002 264 65 52 IN ADDITION,AS REQUIRED:1X 000 264 20 10,1X 000 264 26 10,1X 000 264 32 10,1X 000 264 38 10,1X 000 264 44 10,1X 000 264 50 10, Replaced By: A0002645402, +001A0002610418, +001A0002614880, +001A0002641174
999
COVER , Replaced By: A0002646510
999
HOUSING ,175046 IN ADDITION,AS REQUIRED:1X 003 264 30 52,1X 003 264 36 52,1X 003 264 42 52,1X 003 264 48 52,1X 002 264 59 52,1X 002 264 65 52 IN ADDITION,AS REQUIRED:1X 000 264 20 10,1X 000 264 26 10,1X 000 264 32 10,1X 000 264 38 10,1X 000 264 44 10,1X 000 264 50 10, Replaced By: A0002645402, +001A0002641174
999
RING HALF AS REQUIRED 8.00 MM,047093
999
COVER , Replaced By: A0002646610
999
RING HALF AS REQUIRED 7.80 MM,047093
999
COVER , Replaced By: A0002646710
999
RING HALF , Replaced By: A0002620677
999
RING HALF , Replaced By: A0002620777
999
RING HALF , Replaced By: A0002620877
999
RING HALF , Replaced By: A0002620977
999
RING HALF , Replaced By: A0002621077
999
COVER , Replaced By: A0002647110
999
RING HALF , Replaced By: A0012620530
999
RING HALF AS REQUIRED 6.50 MM,047093
999
RING HALF , Replaced By: A0002621177
999
RING HALF AS REQUIRED 4.05 MM
999
RING HALF AS REQUIRED 6.20 MM,047093
999
RING HALF AS REQUIRED 6.10 MM,047093
999
RING HALF AS REQUIRED 6.00 MM
999
COVER AS REQUIRED 2.50 MM,313052
999
COVER AS REQUIRED 3.10 MM,313052
999
COVER AS REQUIRED 3.70 MM,313052
999
COVER AS REQUIRED 4.30 MM,313052
999
COVER AS REQUIRED 4.90 MM,313052
999
COVER AS REQUIRED 5.60 MM,130782
999
RING HALF AS REQUIRED 6.70 MM,047093
999
RING HALF , Replaced By: A0012621130
999
COVER AS REQUIRED 5.50 MM,313052
999
RING HALF AS REQUIRED 7.10 MM,047093
999
RING HALF AS REQUIRED 7.30 MM,047093
999
RING HALF AS REQUIRED 7.50 MM,047093
999
SCREW , Replaced By: A0002650871
999
SLIDE , Replaced By: A0002650549
999
PIN , Replaced By: A0002670474
999
SHIFTING FORK 5TH AND 6TH SPEED, WITH 10/50 FROM IDENT NO. 792025 ALSO INSTALLED ON 500001-599999, WITH 2060 FROM IDENT NO. 766369 ALSO INSTALLED ON 500001-599999264170
999
SHIFTING FORK , Replaced By: A0002601730
999
SHIFTING FORK 5TH AND 6TH SPEED
999
YOKE , Replaced By: A0009962301
999
BOOT , Replaced By: A0002640796
999
BUSHING SHIFTING DOME,TOP
999
BUSHING , Replaced By: A0002684950
999
BUSHING , Replaced By: A0002682650
999
BUSHING SHIFTING CYLINDER
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
NUT , Replaced By: A0029906251
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
PIN BUSHING , Replaced By: A0075458226
999
BUTTON TWO-SPEED REAR AXLE CONTROL,4 188089
999
SWITCH , Replaced By: A3445457111
999
CLAMP CABLE HARNESS MOUNTING,4 494992
999
REPAIR KIT SHIFTING CYLINDER WABCO
999
REPAIR KITHERION,94171034/0711/24V,94172034/0711
999
RUBBER MOUNTING , Replaced By: A0002682650
999
SPRING 5TH AND 6TH SPEED
999
YOKE SHIFTING CYLINDER
999
REPAIR KITTO 001 997 34 36,002 997 58 36,
999
RING HALF AS REQUIRED 6.60 MM,047093
999
RING HALF AS REQUIRED 6.90 MM,047093
999
SPACER WASHER AS REQUIRED 2.40 MM,279826-313051
999
SPACER WASHER AS REQUIRED 2.20 MM,078888
999
SPACER WASHER , Replaced By: A0042644852
999
SPACER WASHER AS REQUIRED 1.8 MM,152 797
999
SPACER WASHER AS REQUIRED 1.60 MM,279826-313051
999
FLEXIBLE SHAFT , Replaced By: A0015427407
999
FLEXIBLE SHAFT2700 MM
999
PIN BUSHING HOUSING 4-POLE
999
REPAIR KIT , Replaced By: A0012608357
999
SCREW SHIFTING ROD TO SHIFT LEVER
999
LOCK AS REQUIRED 2,55 MM
999
LOCK , Replaced By: A0099947141
999
LOCK AS REQUIRED 2.65 MM
999
LOOM TIE TO MOUNT PLASTIC PIPING
999
SPACER WASHER AS REQUIRED 1.00 MM,313052
999
SPACER WASHER AS REQUIRED 1.60 MM,313052
