Поз.
Артикул
Описание
23
REPAIR KIT CHECK VALVE IN BEARING COVER
90
SCREW
90
SEAL RING FUEL LINE TO FEED PUMP
90
SPRING , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
90
BALL10 MM
90
REPAIR KIT CHECK VALVE IN BOX
93
INSTALLATION KIT CONICAL SPRING WASHER CUSHIONING
94
BEARING RING
95
BEARING RING
96
BEARING RING
97
WASHER
98
NEEDLE BEARING
99
DISC SPRING
100
DISC SPRING
101
ROLLER BEARING
105
REPAIR KIT STEERING WORM WITH NUT
107
REPAIR KIT (GASKET KIT), 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
GASKET KITTO 346 460 00 01
999
GASKET KITTO 346 460 50 01
999
VALVE VALVE BOX TO STEERING BOX TO 346 460 00 01
999
VALVE VALVE BOX TO STEERING BOX TO 346 460 00 01
999
SCREW VALVE BOX TO STEERING BOX TO 346 460 00 01
999
RING
999
RING
999
FILTER , 993034
999
FILLER CAP
999
WASHER , 993034
999
SPACER TUBETO 000 466 38 02
999
CONNECTOR , 993034
999
VALVE DISC , 993034
999
FILTER , Replaced By: A0004660604
999
PIPETO 000 466 38 02
999
COVER PLATETO 000 466 38 02
999
CONNECTOR , 993034
999
SEAL RINGTO 000 466 38 02
999
OIL DIPSTICK , Replaced By: A0004660867
999
WASHER , Replaced By: A9402680552
999
GASKET , 993034
999
SPRING , 993034
999
GASKET , Replaced By: A0004660580
999
COVER , 993034
999
CONNECTORTO 000 466 38 02
999
FITTING , 993034
999
GASKET , 993034
999
FILTER
999
COVER , 993034
999
CENTERING RINGTO 000 466 38 02
999
BRACKET
999
OIL DIPSTICK
999
TANK , 993034
999
SEAL RING
999
COVERTO 000 466 38 02
999
TANK , Replaced By: A0004664502
999
FILTER CARRIER , 993034
999
RUBBER SLEEVETO 000 466 38 02
999
SEALING CORD , Replaced By: A0059970848
999
SPACER WASHER VALVE BOX TO STEERING BOX 9X15.8X0.10 TO 346 460 00 01, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
SPACER WASHER VALVE BOX TO STEERING BOX 9X15.8X0.15 TO 346 460 00 01, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
SPACER WASHER VALVE BOX TO STEERING BOX 9X15.8X0.30 TO 346 460 00 01, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
FILTER CARRIERTO 000 466 38 02
999
LINE FROM STEERING TO OIL TANK, 10/20 UP TO IDENT NO. 4 213496, 50/60 UP TO IDENT NO. 4 212522 EXCEPT FOR 4 212522 EXCEPTO 4 212522 EXCEPT FOR 523209-599999
999
LINE , Replaced By: A3434600124
999
LINE FROM RETURN LINE TO OIL TANK 22MM
999
NUT DRAG LINK END M 24X1.5
999
SCREW , Replaced By: N000000001149
999
SPRING VALVE BOX TO STEERING BOX TO 346 460 00 01
999
SEAL RING , Replaced By: A0059970848
999
SPACER WASHER VALVE BOX TO STEERING BOX 9.5X15.8X0.80 TO 346 460 00 01
999
SPACER WASHER VALVE BOX TO STEERING BOX 9.5X15.8X1.00 TO 346 460 00 01
999
SPACER WASHER VALVE BOX TO STEERING BOX 9.5X15.8X1.50 TO 346 460 00 01
999
SEAL RINGTO 000 466 38 02
999
SEAL RING , Replaced By: A0129975948
999
SEAL RING , Replaced By: A0129976148
999
SEAL RING
999
SEAL RING , Replaced By: A0129976148
999
SEAL RING OIL LINE,019226
999
SEAL RING VALVE BOX TO STEERING BOX TO 346 460 00 01, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
SEAL RING , Replaced By: A0149976948
999
SEAL RING , Replaced By: A0149976848
999
SEAL RING IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 009 997 14 48, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
CLAMP FUEL LINE TO BRACKET
999
PROTECTIVE CAP
999
CLAMP , Replaced By: A3129952420
999
CLAMP , Replaced By: A1109950401
999
SCREW UNIVERSAL JOINT TO STEERING COLUMN M 8X38,5 463984
999
SCREW , Replaced By: A3169900114
999
BRACKET OIL LINE MOUNTING,5 059970
999
CLAMP AT ENGINE
999
LINE FROM POWER STEERING PUMP TO STEERING 12MM
999
LINE , Replaced By: A0014666365, +002N003861015004, +002N003870015101
999
LINE , Replaced By: A0014666765, +002N003861022004, +002N915017022100
999
LINE FROM RETURN LINE TO OIL TANK,5 217241
999
LINE FROM STEERING TO OIL TANK, 10/20 FROM IDENT NO. 4 213497, 50/60 FROM IDENT NO. 4 212523 ALSO INSTALLED ON 523209-599999
999
LINE FROM OIL TANK TO PUMP
999
STEERING SUPPORT , Replaced By: A3434610340
999
STEERING SUPPORT AT FRAME
999
PITMAN ARM ,5 055225
999
PITMAN ARM ,5 055226
999
LINE FROM STEERING TO OIL TANK, 10/20 FROM IDENT NO. 4 213497, 50/60 FROM IDENT NO. 4 212523 ALSO INSTALLED ON 523209-599999
999
LINE FROM OIL TANK TO PUMP,4 213497, 10/20, 4 212523, 50/60
999
LINE FROM OIL TANK TO PUMP,4 213497, 10/20, 4 212523, 50/60
999
HOSE , Replaced By: A3859971582
999
STEERING SHAFT BOTTOM, 344.030,031,032,033,034,040,041 UP TO IDENT NO. 16039639 344.132,133,140,141 UP TO IDENT NO. 16000510
999
STEERING SHAFT BOTTOM
999
STEERING SHAFT BOTTOM
999
STUD LINE TO BRACKET
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
STEERING SHAFT BOTTOM
999
STEERING SHAFT BOTTOM, WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938 UP TO CHASSIS 738939-4 193076
999
SCREW STEERING TO STEERING BRACKET M 16X64,5 180679
999
UNIVERSAL JOINT , UP TO IDENT NO. 709912 EXCEPT FOR 500001-599999
999
SCREW , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
999
WASHER , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
999
SPRING , PART NO LONGER AVAILABLE,ORDER RANGE OF DELIVERY
999
HOSE , Replaced By: A3859971582
999
STEERING BOX ,035454, Replaced By: A3664607802, +001A3664607214
999
SCREW STEERING SHAFT TO STEERING M 8X42
999
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
999
SCREW UNIVERSAL JOINT TO STEERING COLUMN TUBE M 10X45,4 492616
999
SCREW UNIVERSAL JOINT TO STEERING COLUMN TUBE M 10X48,4 4926175 212624
999
SPACER WASHERTO 000 466 38 02
999
SCREW APPARATUS SUPPORT TO FRAME
999
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
SCREW , Replaced By: N007985005175
999
SCREW SHIFT CASE TO SLOTTED GATE
999
SCREW , Replaced By: A0029903712
999
COTTER PIN SHOCK ABSORBER TO UPPER BEARING BRACKET,4 168884
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
NUT , 993035
999
LOCK RING ,4 208907
999
SCREW , Replaced By: N304017008016
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SIDE MEMBER
999
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
SCREW , Replaced By: N000960012384
999
SCREW ,5 903514, Replaced By: N000960012353
999
SCREW TORSION BAR TO SHACKLE,5 903514
999
SCREW , Replaced By: N308676012017
999
SCREW STEERING SUPPORT TO FRAME M 14X50
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW BRACKET TO REAR AXLE
999
SCREW , Replaced By: N308676016014
999
SCREW , Replaced By: A9429901304
999
SCREW , Replaced By: N308676014012
999
SCREW , Replaced By: N308676016013
999
SCREW , Replaced By: N308676016006
999
TIGHTENING SLEEVE. CLAMPING SLEEVE , UP TO IDENT NO. 629394 EXCEPT FOR 500001-599999
999
SCREW HOOK TO BRACKET
999
SCREW OIL TANK TO BRACKET
999
MOUNTING CLAMP. CLAMP OIL LINE TO BRACKET, AND BRACKET TO OIL TANK BRACKET, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
NUT
999
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
999
SCREW SUPPORT TO SIDE MEMBER M 14X45
999
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
999
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
999
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
NUT CONSOLE TO SUPPORT
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
999
NUT , Replaced By: N913002006009
999
NUT OIL TANK TO BRACKET
999
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
999
NUT , Replaced By: N910113012003
999
NUT , Replaced By: N910113016001
999
CLAMP HOSE TO FITTING AND TO OIL TANK
999
CLAMP , Replaced By: N000000000667
