Поз.
Артикул
Описание
4
WATER PUMP
8
HOUSING
12
SHAFT
12
SHAFT ,A 057418
12
SHAFT , Replaced By: A3662010205
12
SHAFT , Replaced By: A3662010105
16
GROOVED BALL BEARING
16
GROOVED BALL BEARING , FROM ENGINE 937666-999999 YEAR OF MANUFACTURE 1989-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
20
SEAL RING
20
SEAL RING
20
SEAL RING
24
SEAL , Replaced By: A0012012619
24
SEAL , Replaced By: A0012011919
24
SEAL , Replaced By: A0012011919
24
SEAL , Replaced By: A0012011819
24
SEAL , Replaced By: A0012011719
24
SEAL , Replaced By: A0002019219
24
SEAL , Replaced By: A0002016719
24
SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002018019
24
SEAL , Replaced By: A0002015719
24
SEAL , Replaced By: A0002019919
24
SEAL WITH THRUST RING AND BOOT
28
THRUST RINGTO 000 201 66 19/72 19
32
BOOTTO 000 201 66 19,000 201 72 19
36
IMPELLER
40
GROOVED BALL BEARING , FROM ENGINE 937666-999999 YEAR OF MANUFACTURE 1989-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
40
GROOVED BALL BEARING INTERMEDIATE BEARING
40
GROOVED BALL BEARING
44
SEAL RING WATER PUMP
48
SEAL HOLDER
48
SEAL HOLDER
52
SEAL RING
52
SEAL RING ,A 057418
52
SEAL RING
52
SEAL RING
56
SCREW LEVER TO THROTTLE VALVE SHAFT
60
HUB
60
HUB
60
HUB , Replaced By: A3452010039
62
SCREW PLUG STABILIZER
64
GASKET KIT , Replaced By: A3442000201
64
GASKET KIT WATER PUMP
68
GASKET WATER PUMP TO CYLINDER CRANKCASE
68
GASKET , Replaced By: A3642010280
72
SCREW CROSS MEMBER TO FRAME
76
SCREW PLATE TO TRANSMISSION CASE M 8 X 70
80
GASKET1 MM
80
GASKET , Replaced By: A3522032380
84
HOUSING
88
SCREW CLUTCH TO FLYWHEEL M 8X50,838705
92
GASKET , Replaced By: A3522032280
96
THERMOSTAT ELEMENT , Replaced By: A0042038375
96
THERMOSTAT ELEMENT , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 430461YEAR OF MANUFACTURE 1996, Replaced By: A0052032675
96
THERMOSTAT ELEMENT
96
THERMOSTAT ELEMENT
103
COVER THERMOSTAT
107
SCREW BRACKET TO OIL FILLER PIPE BRACKET,D 200055
112
PULLEY
116
HUB RING
120
FAN 6-BLADE,A 068264 USED 314 200 12 23 DELIVER ADDITIONALLY 000933 008062
120
FAN ,270118, Replaced By: A3142000123, +006N000931008320
124
SCREW FAN TO WATER PUMP PULLEY M 8X47, UP TO ENGINE 203748 YEAR OF MANUFACTURE 1977 FROM ENGINE 465549-999999 YEAR OF MANUFACTURE 1984-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
128
V-BELT ,5 345185
132
LINE UPPER COOLING WATER LINE
135
THREADED INSERT REPAIR PURPOSES M 14X1.5X10.5
137
FLANGE
140
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
140
GASKET , Replaced By: A3662030380
140
GASKET HEATING PIPE TO ENGINE
145
SCREW UPPER COOLING WATER LINE TO CYLINDER HEAD M8X80
145
SCREW UPPER COOLING WATER LINE TO CYLINDER HEAD M 8X70
149
GASKET , Replaced By: A3522032680
149
GASKET , Replaced By: A3522032480
152
SCREW LEVER TO PEDAL,4 247126
159
WASHER TRAILER PLUG SOCKET TO BRACKET
