Поз.
Артикул
Описание
18
CONNECTING ROD ,082679
30
SCREW CONNECTING ROD COVER TO CONNECTING ROD, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
36
NUT
39
BUSHING ,082679
42
BEARING SHELL PARTS KIT,REPAIR SIZE II 31.50 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
42
BEARING SHELL PARTS KIT,REPAIR SIZE III 31.25 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
42
BEARING SHELL PARTS KIT,REPAIR SIZE I 31.75 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
42
BEARING SHELL CONNECTING ROD BEARING SHELLS,31.90 MM STANDARD SIZE I,082679
42
BEARING SHELL CONNECTING ROD BEARING SHELLS,32.00 MM STANDARD SIZE,082679
48
CYLINDER LINER WITH PISTON 94 MM
54
PISTON PIN
60
LOCK RING
66
GASKET , Replaced By: A3211310080
66
GASKET , Replaced By: A3211310180
72
CYLINDER HEAD
78
VALVE CYLINDER HEAD
84
VALVE (PRESSURE VALVE)
90
NUT PRESSURE VALVE TO CYLINDER HEAD
90
NUT PRESSURE VALVE TO CYLINDER HEAD
90
NUT PRESSURE VALVE TO CYLINDER HEAD
96
SEAL RING
102
GASKET AS REQUIRED 0.90 MM
102
GASKET , Replaced By: A3661310280
102
GASKET , Replaced By: A3661310180
102
GASKET AS REQUIRED 0.65 MM
108
SCREW BEARING BRACKET TO CAB M 8X30
115
SEAL RINGTO 376 131 74 01
122
CONNECTOR , Replaced By: A6012030008
132
HOSE FROM HEAT EXCHANGER TO WATER PUMP,073289
144
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
144
CLAMP , Replaced By: N000000000667
