Поз.
Артикул
Описание
302
SHIFT CASE , Replaced By: A3452600172
302
SHIFT CASE , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
311
BEARING , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
319
BUSHING SHIFTING ROD
323
BUSHING SHIFTING ROD
330
SLIDE SHIFT CASE
339
SPRING SHIFT CASE,BOTTOM
342
SPHERICAL PIECE GEARSHIFT LEVER LOWER PART,D 203092
355
COVER
358
LOCK WASHER RAIL TO BATTERY SUPPORT
362
NUT LEVER TO SHIFTING SHAFT
366
BRACKET
370
SCREW SUPPORT TO SIDE MEMBER M 10X65,B 884219
373
LOCK WASHER , Replaced By: N912004010102
377
LOCK WASHER RAIL TO BATTERY SUPPORT
381
NUT LEVER TO SHIFTING SHAFT
390
BOOT , Replaced By: A3522680497
390
BOOT , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
392
LOOM TIE , Replaced By: A3459977390
392
LOOM TIE ELECTRIC CABLE MOUNTING
393
BOOT , Replaced By: A3442677096
393
BOOT , Replaced By: A3442677096
393
BOOT , Replaced By: A3442677096
393
BOOT , Replaced By: A3442677096
393
BOOT ,522754
393
BOOT , 030,032,033,040,041 UP TO CHASSIS 521825
396
LOOM TIE
397
SHIFTING ROD , Replaced By: A3452600533
397
SHIFTING ROD
400
BUSHING SHIFT CASE
405
BOOT SHIFT CASE
409
SNAP RING , NOT USED
413
SNAP RING SHIFT CASE
417
CLAMPING PIECE SHIFTING TUBE TO TRANSMISSION
420
SCREW CROSS MEMBER TO SIDE MEMBERS
424
SHIFTING ROD , Replaced By: A3442608033
424
SHIFTING ROD REAR
425
JOINT
427
SCREW SHIFTING TUBE TO TRANSMISSION
430
LOCK WASHER RAIL TO BATTERY SUPPORT
434
NUT LEVER TO SHIFTING SHAFT
440
SHIFT LEVER LOWER PART
450
SHIFT LEVER
458
NUT SHIFT LEVER
461
HANDLE
461
HANDLE (GEARSHIFT LEVER KNOB)
461
HANDLE
471
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
475
NUT SPRING BOLT
999
STUD , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
999
STUD , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
999
COTTER PIN , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
COTTER PIN PULL ROD TO SHIFTING SHAFT
999
REPAIR KIT , Replaced By: A3452600468
999
TRANSMISSION , Replaced By: A3442601300
999
SPRINGTO 384 268 04 29, UP TO CHASSIS 447270,FROM CHASSIS SEE SPARE PARTS LIST 0817
999
PLATE , Replaced By: A3452600046
999
SHIFTING ROD , UP TO CHASSIS 447270,FROM CHASSIS SEE SPARE PARTS LIST 0817
999
SHIFTING ROD , Replaced By: A3522605433
999
SELECTOR LEVER SHIFTING ROD
999
TRANSMISSION CASE COVER ,475057, Replaced By: A3522602914, +001A3852600046, +004A1362650272, +004A1369908240
999
GASKET KIT , UP TO CHASSIS 447270,FROM CHASSIS SEE SPARE PARTS LIST 0817
999
PLATE , FROM TRANSMISSION
999
TRANSMISSION
999
TRANSMISSION , Replaced By: A3442601600
999
GEAR REVERSE SPEED
999
SYNCHRONIZER BODY 2ND AND 3RD SPEED
999
SHIFTING ROD
999
SPRING , DISCONTINUED,PART IS NO LONGER REQUIRED
999
THREADED BUSHING
999
BALL SOCKET , DISCONTINUED,PART IS NO LONGER REQUIRED
999
SPACER WASHER AS REQUIRED 0.15 MM,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
