Поз.
Артикул
Описание
5
STEERING BOX ASSEMBLY , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
5
STEERING BOX ASSEMBLY
5
STEERING BOX ASSEMBLY , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
5
STEERING BOX ASSEMBLY , Replaced By: A3454608101
160
NUT
161
COTTER PIN , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
172
PITMAN ARM
172
PITMAN ARM , USED WITH ZF STEERING GEAR UP TO IDENT-NO.: 549889.
172
PITMAN ARM
172
PITMAN ARM
172
PITMAN ARM , USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
174
STEERING SUPPORT , Replaced By: A3454617040
174
STEERING SUPPORT , USED WITH ZF STEERING GEAR UP TO IDENT-NO.: 549889.
175
RIVET12X28 MM
176
STEERING BRACKET
180
SCREW STEERING TO STEERING BRACKET
185
SCREW STEERING TO BEARING BRACKET
185
SCREW STEERING TO STEERING BRACKET
186
WIRE STEERING TO STEERING BRACKET
188
DRAG LINK , Replaced By: A3454609505
188
DRAG LINK , Replaced By: A3454609505
188
DRAG LINK
188
DRAG LINK
188
DRAG LINK
188
DRAG LINK
188
DRAG LINKNAKATA, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
188
DRAG LINK
191
JOINTTO 345 460 94 05
191
JOINTTO 345 460 94 05
191
JOINTTO 345 460 94 05
191
JOINT
191
JOINT
191
JOINT
191
JOINTTO 344 460 79 05
191
DRAG LINK END , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004602648
191
DRAG LINK END , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004602648
197
DUST CAPTO 345 460 86 05
197
DUST CAP"NAKATA",344 460 79 05
197
BOOT FIXED PART OF JOINT TO 345 460 88 05
197
BOOT FIXED PART OF JOINT TO 345 460 88 05
197
DUST CAPTO 345 460 81 05,376 460 01 05
197
DUST CAPTO 345 460 81 05,376 460 01 05
197
DUST CAPTO 345 460 81 05,376 460 01 05
197
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0004621796
203
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
203
CLAMPING RING FIXED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
203
CLAMPING RINGTO 345 460 86 05
212
SPACER RING SCREWED PART OF JOINT TO 345 460 86 05, USED WITH AIR BRAKE, 341.041,042,044 FROM CHASSIS A 059729 ALSO INSTALLED ON A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
215
CLAMP , Replaced By: A0003380645
215
CLAMP , Replaced By: A0003380645
215
CLAMP JOINT TO DRAG LINK
215
CLAMP JOINT TO DRAG LINK
215
CLAMP JOINT TO DRAG LINK "NAKATA",344 460 79 05
218
SCREW CLAMP TO DRAG LINK M12X1.5X60,TO 682 460 31 05
221
NUT CLAMP TO DRAG LINK
221
NUT ALTERNATOR TO SUPPORT
221
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
224
NUT BALL PIVOT TO STEERING ARM
224
NUT DRAG LINK TO LEVER
227
COTTER PIN SHIFT LEVER TO CASE
227
COTTER PINTO 345 460 94 05
227
COTTER PINROCKINGER TYP 260 G140
230
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 12X1.5X50
230
SCREW STEERING BRACKET TO FRAME M 12X1.5X50
233
SCREW , Replaced By: N308676012016
236
SCREW STEERING BRACKET TO FRAME M 12X1.5X55
236
SCREW , Replaced By: N308676012016
236
SCREWM 12X1.5X58
236
SCREW STEERING BRACKET TO FRAME M 12X1.5X60
236
SCREW , Replaced By: N308676012018
239
SCREW ALTERNATOR TO SUPPORT
239
SCREW ALTERNATOR TO SUPPORT
239
SCREW STEERING BRACKET TO FRAME M 12X1.5X68
242
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
243
COTTER PIN , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
243
COTTER PIN , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
245
STEERING SHAFT BOTTOM,16039640, 344.030,031,032,03316005512, 345.001,002,003,300
245
STEERING SHAFT BOTTOM,16039640, 344.030,031,032,03316005512, 345.001,002,003,300
245
STEERING SHAFT BOTTOM, 344.030,031,032,033,034,040,041 UP TO IDENT NO. 16039639 344.132,133,140,141 UP TO IDENT NO. 16000510
245
STEERING SHAFT BOTTOM
245
STEERING SHAFT BOTTOM,16005511
685
DRAG LINK
690
JOINTTO 344 460 79 05
695
DUST CAP"NAKATA",344 460 79 05
700
NUT DRAG LINK TO LEVER
705
CLAMP JOINT TO DRAG LINK "NAKATA",344 460 79 05
710
SCREW CLAMP TO DRAG LINK M12X1.5X60,TO 682 460 31 05
715
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
718
COTTER PINTO 345 460 94 05
718
COTTER PINTO 345 460 94 05
999
OIL LINE , 030360
999
REINFORCEMENT , Replaced By: A0004660095
999
BRACKET , Replaced By: A0004660640
999
HOUSING
999
COVER , Replaced By: A0004664405
999
TANK , Replaced By: A3454667002
999
SCREW , Replaced By: A3449907002
999
RIVET , Replaced By: N910005012017
999
NUT , Replaced By: N000937035000
999
CLAMP , Replaced By: N916016012201
999
CLAMP , Replaced By: N916016022202
999
LOOM TIE , Replaced By: N916017025000
999
FITTING , Replaced By: A0004660571
999
HOSE , 344.030,031,032,033,034,040,041,132,133,140,141 UP TO IDENT NO. 12068000 345.001,002,003,021,024,300 UP TO IDENT NO. 12009117
999
FITTING ,12068000, 344.030,031,032,03312009117, 345.001,002,003,300
999
FILTER CARRIERTO 000 466 38 02
999
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
999
SEAL RING , Replaced By: A0059970848
999
SEAL RING , Replaced By: A0099970145
999
HOSE , Replaced By: A0019972652
999
BRACKET , Replaced By: A3444660240
999
BRACKET ,14011500
999
LINE , Replaced By: A0454600524
999
LINE , Replaced By: A0454600224
999
BRACKET , Replaced By: A3454667040
999
BRACKET ,14011500
999
LINE , Replaced By: A3454607424
999
LINE FROM OIL TANK TO HOSE,1401150112068000, 344.030,031,032,03312009117, 345.001,002,003,300
999
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE
999
BRACKET
999
BRACKET
999
SCREW
999
SCREW STEERING TO STEERING BRACKET
999
NUT STEERING TO STEERING BRACKET TO 327 990 01 14,322 990 09 14
999
SCREW STEERING TO STEERING BRACKET
999
PITMAN ARM
999
DRAG LINK"THOMSON"
999
DRAG LINK ,680436, 344.012-344.015
999
SCREW STEERING TO FRAME, INAPPLICABLE TO SUPERCHARGING SYSTEM
999
SCREW
999
SCREW
999
LINE , Replaced By: A3454607524
999
DRAG LINK
999
DRAG LINK"NAKATA",651890
999
DRAG LINKGEMMER THOMPSON, USED WITH AIR BRAKE,FROM CHASSIS 588186
999
NUT , Replaced By: A0004660458
999
TANK OIL TANK
999
HOSE , 344.058 UP TO ENGINE 256208
999
SEAL HOLDERTO 364 330 70 03
999
BOOT , Replaced By: A3503387056
999
PITMAN ARM
999
PITMAN ARM
999
BRACKET OIL TANK
999
LINE FROM HOSE TO POWER STEERING PUMP
999
STEERING SHAFT BOTTOM,A 058201
999
BRACKET OIL TANK
999
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.670951
999
LOOM TIE , Replaced By: A3449978490
999
JOINT , Replaced By: A3443307135
999
BOOT , Replaced By: A3443387056
999
STEERING BRACKET , Replaced By: A3444600229
999
LINE , Replaced By: A3444608624
999
BRACKET , Replaced By: A3454290040
999
LINE , Replaced By: A3444660064
999
LINE , Replaced By: A3444609024
999
LINE , Replaced By: A3454607524
999
STEERING SHAFT , Replaced By: A3454620001
999
STEERING SHAFT , Replaced By: A3454620201
999
NUT. PART NAME MISSING , Replaced By: A0004660458
999
HOSE , Replaced By: A0109971682
999
COTTER PIN6.3X63 MM
999
LOCK WASHER TAIL LAMP TO BRACKET
999
LOCK WASHER , Replaced By: N912004010102
999
SCREW COMPRESSED AIR ELBOW
999
SCREW , Replaced By: N304017010040
999
NUT
999
NUT , Replaced By: N304032008006
999
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
999
SCREW-IN FITTING RETURN LINE TO STEERING
999
SEAL RING VALVE TO VALVE,K 025179
999
NUT BRACKET TO SIDE MEMBER,XB209706
999
NUT , Replaced By: N910113012003
