Поз.
Артикул
Описание
6
RUBBER MOUNTING ENGINE FRONT SUSPENSION
6
RUBBER MOUNTING ENGINE FRONT SUSPENSION
12
RUBBER MOUNTING
12
RUBBER MOUNTING
24
ENGINE STAY RUBBER MOUNTING TO FRONT CROSS MEMBER
30
ENGINE STAY RUBBER MOUNTING TO ENGINE REAR SUPPORT
36
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
42
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
48
SCREW SUPPORTING ARM TO FRONT RUBBER MOUNTING M 16X16
54
WASHER CONSOLE TO FRAME
60
BEARING BRACKET
60
BEARING BRACKET , Replaced By: A3442410035
66
LOCK
72
SCREW ENGINE TO REAR RUBBER MOUNTING M 14X45,609836 345.300 UP TO IDENT NO. 704163 "1316"
72
SCREW BATTERY CASE
72
SCREW BATTERY CASE TO SIDE MEMBER
84
WASHER CROSS MEMBER TO SUPPORT
156
ROD , Replaced By: A3452407125
156
ROD
162
NUT
168
NUT L.H. THREAD TO 352 240 02 25
174
ROD ENDTO 345 240 71 25
174
ROD ENDTO 352 240 02 25
180
ROD ENDTO 345 240 71 25
180
ROD ENDTO 352 240 02 25
186
BUSHINGTO 345 240 71 25
192
RUBBER MOUNTINGTO 345 240 71 25
198
CLAMPTO 345 240 71 25
204
SCREW COVERING TO BRACKET
210
LOCK WASHER TAIL LAMP TO BRACKET
216
NUT
222
BRACKET ENGINE ALONGSIDE FIXING, USED WITH AIR BRAKE,FROM CHASSIS 588186 345.300 UP TO IDENT NO. 704163 "1316"
228
SCREW REAR CROSS MEMBER AND GUSSET PLATES TO SIDE MEMBERS M 12X30
228
SCREW FUEL LINE TO SIDE MEMBER
228
SCREW BEARING BRACKET TO SIDE MEMBER
231
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
234
NUT BRACKET TO SIDE MEMBER
234
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
240
SCREW , Replaced By: N304017010002
246
NUT BRACKET TO SIDE MEMBER,XB209706
252
BEARING BRACKET
258
SCREW PULL ROD TO BEARING BRACKET
264
NUT PULL ROD TO BEARING BRACKET
270
COTTER PIN STRAP TO SUPPORT
999
RODTO 352 240 02 25
