Поз.
Артикул
Описание
5
ACCELERATOR PEDAL ,793543 345.200,220 FROM CHASSIS 11008097
5
ACCELERATOR PEDAL , Replaced By: A3443000104
10
BUSHING MANUAL CONTROL,D 249954
15
GREASE NIPPLE
19
PLATE ACCELERATOR PEDAL CONTROL,GB718836
19
PLATE , Replaced By: A3453007002
29
SHEET METAL SCREW MAIN CABLE HARNESS TO FIRE WALL
30
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
35
NUT
102
WASHER PEDAL BEARING
106
LOCK RING BELT TIGHTENER
110
CLAMP ACCELERATOR PEDAL, 345.200,220 FROM CHASSIS 11008097793543
115
SCREW PLUG SOCKET TO FRAME
119
ROLLER ACCELERATOR PEDAL,793543 345.200,220 FROM CHASSIS 11008097
119
ROLLER ,GB718836
123
PIN ROLLER TO LEVER
127
WASHER PLUG SOCKET TO BRACKET
130
COTTER PIN BATTERY COVER TO 388 540 70 14
140
BEARING BRACKET PEDAL BEARING,793543 345.200,220 FROM CHASSIS 11008097
140
PART NAME MISSING , Replaced By: A3453007136
144
SCREW LINES TO BRACKET
148
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
220
ROD REVERSING LEVER,793543 345.200,220 FROM CHASSIS 11008097
220
ROD , Replaced By: A3453007115
224
NUT
228
YOKE ACCELERATOR CONTROL
232
PIN REVERSING LEVER,793543 345.200,220 FROM CHASSIS 11008097
236
WASHER PLUG SOCKET TO BRACKET
241
COTTER PIN BATTERY COVER TO 388 540 70 14
245
BRACKET AT LEFT SIDE MEMBER
245
BRACKET
245
PART NAME MISSING , Replaced By: A3453007240
249
SCREW , Replaced By: N304017010002
249
SCREW , Replaced By: N304017010040
253
LOCK WASHER , Replaced By: N912004010102
257
NUT BRACKET TO SIDE MEMBER,XB209706
262
PULL ROD REVERSING LEVER 6X5280,793544
266
YOKE ACCELERATOR CONTROL
272
NUT FROM TURNBUCKLE NUT TO INTERMEDIATE LEVER
274
NUT FRONT SHIFTING ROD
280
PULL ROD FROM TURNBUCKLE NUT TO INTERMEDIATE LEVER 6X930,793543
284
NUT FROM TURNBUCKLE NUT TO INTERMEDIATE LEVER
288
NUT
292
YOKE ACCELERATOR CONTROL
296
PIN OPERATING ROD TO BRACKET
297
PULL ROD FROM FRONT INTERMEDIATE LEVER TO REAR INTERMEDIATE LEVER 6X1260X50 MM
298
NUT FROM TURNBUCKLE NUT TO INTERMEDIATE LEVER
301
BALL SOCKET AT CONTROL LEVER
302
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
303
NUT FRONT SHIFTING ROD
305
LEVER (INTERMEDIATE LEVER)
309
BUSHING MANUAL CONTROL,D 249954
316
PULL ROD PULL ROD TO LEVER II
320
NUT
324
YOKE ACCELERATOR CONTROL
328
LEVER (INTERMEDIATE LEVER),793544
336
BUSHING MANUAL CONTROL,D 249954
344
PIN OPERATING ROD TO BRACKET
369
YOKE ACCELERATOR CONTROL
370
NUT
373
NUT FROM TURNBUCKLE NUT TO INTERMEDIATE LEVER
377
NUT FRONT SHIFTING ROD
381
BALL SOCKET AT CONTROL LEVER
385
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
395
LEVER
395
LEVER , Replaced By: A3643000025
399
BUSHING MANUAL CONTROL,D 249954
403
WASHER
407
LOCK RING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
415
BEARING BRACKET ,C 079749
419
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X35
423
SPRING WASHER CAB FLOOR
425
LEVER (INTERMEDIATE LEVER) I
426
BUSHING MANUAL CONTROL,D 249954
427
NUT , Replaced By: N308675012000
427
NUT , Replaced By: N000936012005
435
PULL ROD FROM CONTROL LEVER TO ENGINE 6X130X30/30
435
PULL ROD
439
NUT
443
BALL SOCKET AT CONTROL LEVER
447
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
600
LEVER ACCELERATOR PEDAL CONTROL,793543 345.200,220 FROM CHASSIS 11008097
600
LEVER , Replaced By: A3453007225
608
BUSHING , Replaced By: A3443020150
608
BUSHING , USED WITH AIR BRAKE
612
FITTED WASHER , USED WITH AIR BRAKE
616
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
999
ROD CONTROL,REAR
999
ROD
999
BUSHING
999
ROD FROM INTERMEDIATE LEVER TO REVERSING LEVER
999
ROD FROM LEVER TO BEARING BRACKET, 345.200,220 FROM CHASSIS 11008097793543
999
ROD FROM INTERMEDIATE LEVER I TO INTERMEDIATE LEVER II
999
ROD FROM INTERMEDIATE LEVER II TO TURNBUCKLE NUT,D 100682
999
SCREW 3/2-WAY VALVE TO BRACKET
999
PULL ROD6X155X30/30
999
PULL ROD FROM INTERMEDIATE LEVER II TO CONTROL LEVER 6X600X30/30
999
PULL ROD FROM CONTROL REVERSING LEVER I TO TURNBUCKLE 6X4900X50/50
999
PULL ROD FROM INTERMEDIATE LEVER II TO CONTROL LEVER TO 345 300 77 15
