Поз.
Артикул
Описание
5
BEARING BRACKET FRONT
5
BEARING BRACKET PEDAL ASSEMBLY
5
BEARING BRACKET , Replaced By: A3442900319
85
BEARING , Replaced By: A3442900520
85
BEARING
85
BEARING
86
BUSHING
86
BUSHING , Replaced By: A3442940150
87
GREASE NIPPLE
89
SCREW
89
HEADLESS SETSCREW , Replaced By: A3529900080
90
PEDAL , Replaced By: A3442900616
90
PEDAL
91
PEDAL CLUTCH
92
BUSHING
93
GREASE NIPPLE PROTECTIVE TUBE
94
STOP
94
RUBBER BUFFER , Replaced By: A3442910041
95
SPACER RING PEDAL TO BEARING BRACKET
96
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
97
SCREW BRACKET TO BUMPER STRUT
97
SCREW , Replaced By: N000960012335
98
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 12X1.5X50
99
SCREW BRACKET TO FRAME M 12X35
100
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
101
BRACKET
102
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
103
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
104
SCREW BRACKET TO FRAME M 12X35
105
SCREW CLAMP TO DRAG LINK M12X1.5X60,TO 682 460 31 05
106
SCREW , Replaced By: N000960012335
106
SCREW BRACKET TO BUMPER STRUT
107
NUT SUPPORT TO SIDE MEMBER
108
LEVER CLUTCH
111
SCREW SPARE WHEEL CARRIER
113
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
114
LOCK WASHER , Replaced By: N912004010102
116
PULL ROD PULL ROD TO CLUTCH LEVER
117
YOKE PULL ROD TO LEVER
118
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
130
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
139
SPRING WASHER. LOCK RING SHIFTING ROD TO BRACKET
143
WASHER 10,5 DIN 433. WASHER , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
672
SPRING CLUTCH PEDAL
714
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
718
YOKE PULL ROD TO LEVER
718
YOKE , Replaced By: A0009961501
730
PIN ,16005089
760
PEDAL PLATE CLUTCH
765
PAD BRAKE AND CLUTCH LEVERS
770
SCREW , Replaced By: N304017010040
999
BUSHING MANUAL CONTROL,D 249954
