Поз.
Артикул
Описание
228
BRACKET AT CROSS MEMBER
229
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
232
CLAMP FUEL LINES TO BRACKET
233
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
237
SCREW CLAMP TO BRACKET
242
WASHER , Replaced By: N009021006208
245
NUT PUMP TO BRACKET
257
WASHER BRACKET TO CAB REAR PANEL
260
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
280
HOLLOW SCREW FUEL LINE TO TANK,659794
290
SEAL RING AT TANK
290
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
300
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
305
INSULATING HOSE CHECK VALVE,CONNECTION "2"
305
INSULATING HOSE , ORDER BY THE METER
310
DISTRIBUTOR LEAK LINE,659794
315
BANJO UNION , Replaced By: N915052008019
320
BANJO UNION FEED 8/14 MM,659794
325
CONNECTOR
330
NUT. UNION NUT RETURN
335
HOSE , Replaced By: A3769978182
335
HOSE , ORDER BY THE METER
345
CLAMP LINE MOUNTING
350
GROMMET LINE PASSAGE AT SIDE MEMBER
355
CLAMP LINE MOUNTING
360
LOOM TIE ELECTRIC CABLE MOUNTING
360
LOOM TIE , Replaced By: A3459977390
365
LINE FUEL LINE TO CYLINDER HEAD,689885
370
SEAL CONE FUEL LINE TO CYLINDER HEAD,689885
375
UNION NUT
380
CLAMP LINE MOUNTING
999
CLAMP FROM EXPANSION TANK TO HEATING PIPE, NOT USED
999
SENDER UNIT , Replaced By: A3455427617
999
BRACKET , Replaced By: A3444760336
999
FUEL TANK , Replaced By: A3444707901
999
RISING PIPE , Replaced By: A3444700126
999
LINE , Replaced By: A3440700032
999
LINE , Replaced By: A3444702864
999
LINE , Replaced By: A3454709364
999
LINE , Replaced By: A3454709664
999
LINE , Replaced By: A3444708665
999
LINE , Replaced By: A3454709764
999
HOSE , Replaced By: A3449977582
999
STRAP , Replaced By: A3224700140
999
RUBBER STRIP , Replaced By: A3459837391
999
FUEL TANK , Replaced By: A3444707901
999
FUEL STRAINER , Replaced By: A3504700006
999
FILLER CAP , Replaced By: A3444700205
999
FUEL TANK , Replaced By: A3444709001
999
SENDER UNIT , Replaced By: A3455427917
999
LINE ,689885, Replaced By: A3504707665
999
FUEL STRAINER AT TANK
999
BALL-TYPE NIPPLE. SEAL CONE , Replaced By: A3449907067
999
BANJO UNION FUEL LINE TO FUEL TANK
