Поз.
Артикул
Описание
5
RADIATOR
10
RADIATOR CAP
15
SCREW PLUG
20
SEAL RING
30
FAN SHROUD
35
SUPPORT
40
COVER PLATE RETURN, FROM HOSE CONNECTION I TO HOSE CONNECTION II
45
SCREW PLUG SOCKET TO FRAME
45
SCREW LINES TO BRACKET
50
WASHER TRAILER PLUG SOCKET TO BRACKET
55
LOCK WASHER RAIL TO BATTERY SUPPORT
60
NUT LEVER TO SHIFTING SHAFT
68
ANGLE RIGHT
68
ANGLE LEFT
70
SCREW REAR CROSS MEMBER AND GUSSET PLATES TO SIDE MEMBERS M 12X30
72
WASHER BRACKET TO ENGINE CROSS MEMBER
75
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
80
HEX. NUT. NUT FUEL TANK TO CONSOLE,167609
85
RUBBER MOUNTING TRANSMISSION TO INTERMEDIATE RING
87
WASHER GROUND CABLE
88
RUBBER BUFFER EXHAUST MUFFLER
90
LOCK WASHER , Replaced By: N912004010102
95
NUT BRACKET TO RETARDER
97
BRACKET RUBBER BUFFER TO BASE FRAME
100
LOCK WASHER , Replaced By: N912004010102
105
NUT BRACKET TO RETARDER
110
RADIATOR STRUT LEFT, FROM CHASSIS 12000005
115
SPACER TUBE RADIATOR STRUT TO SUPPORT AND TO CAB
120
RUBBER RING SHOCK ABSORBER MOUNTING
125
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
130
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
135
TANK EXPANSION TANK
135
TANK EXPANSION TANK,604879
140
RADIATOR CAPTO 345 500 76 49
145
BRACKET
150
SCREW PARKING BRAKE VALVE TO INSTRUMENT PANEL,TB108828
155
LOCK WASHER CLUTCH TO FLYWHEEL
160
NUT
165
SCREW PLUG SOCKET TO FRAME
170
WASHER TRAILER PLUG SOCKET TO BRACKET
175
WASHER BRACKET TO CAB REAR PANEL
180
HOSE FROM CONNECTION TO EXPANSION TANK
190
CLAMP HOSE TO FITTING AND TO OIL TANK
190
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
190
LOOM TIE. CLAMP HOSE TO HEATING PIPE
195
SCREW PLUG SOCKET TO FRAME
200
LOCK WASHER CLUTCH TO FLYWHEEL
205
SCREW SWITCH TO BRACKET 8X16
210
WASHER TRAILER PLUG SOCKET TO BRACKET
215
NUT
220
CLAMP ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
230
HOSE FROM THERMOSTAT TO RADIATOR FILLER NECK
235
BRACKET
235
LOOM TIE HOSE TO FILLER NECK
235
CLAMP COMPRESSED AIR LINE
250
HOSE FROM RADIATOR OUTLET TO OIL COOLER
260
LOOM TIE (DRY FILTER)
260
CLAMP. LOOM TIE (DRY FILTER)
260
LOOM TIE FROM THERMOSTAT TO RADIATOR FILLER NECK
999
RADIATOR CAP , Replaced By: A3445010315
999
CLAMP , Replaced By: A0019972590
999
RADIATOR , Replaced By: A3455017101
