Поз.
Артикул
Описание
100
HOUSING CLUTCH
100
HOUSING CLUTCH
105
BUSHING RELEASE SHAFT,BOTTOM
107
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
109
BUSHING TOP
111
BUSHING TOP
113
FELT RING
115
COVER PLATE
120
SHAFT (PARTS KIT),RELEASE SHAFT, DELIVER ADDITIONALLY:AS REQUIRED 1X 317 293 01 77-06 77
120
RELEASE SHAFT
120
REPAIR KIT , DELIVER ADDITIONALLY:AS REQUIRED 1X 317 293 01 77-06 77, Replaced By: A3632500114
125
WASHER AS REQUIRED 1.10 MM
125
WASHER AS REQUIRED 0.80 MM
125
WASHER AS REQUIRED 0.90 MM
125
WASHER AS REQUIRED 1.20 MM
125
WASHER AS REQUIRED 1.00 MM
125
WASHER AS REQUIRED 1.3 MM
130
FELT RING
135
SPACER WASHER RELEASE SHAFT,BOTTOM
140
LOCK RING RELEASE SHAFT,BOTTOM
145
RELEASE YOKE , Replaced By: A3452937111
150
SPACER TUBE
155
WASHER
160
CLAMPING SLEEVE
165
WASHER
170
LEVER LEFT
175
LEVER RIGHT
180
LOCK
185
DISC SPRING WORM TO BRACKET,5 143211 ON VEHICLES HAVING MERCEDES BENZ BODY
190
SHIM. FITTED WASHER HYDRAULIC LINE MOUNTING PARTS
190
FITTED WASHER AS REQUIRED 1.0 MM
190
FITTED WASHER AS REQUIRED 1.5 MM
200
WASHER RADIATOR TO RUBBER MOUNTING
200
WASHER , Replaced By: N000125010532
202
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
210
LOCK WASHER FITTING TO BRACKET
212
SCREW RELEASE LEVER TO SHAFT
212
SCREW , Replaced By: N000933012102
212
SCREW , Replaced By: N304017012018
220
LOCK WASHERROCKINGER TYP 59 G140,59 G150
222
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
222
NUT , Replaced By: N308673016001
230
COVER ,079773
235
SCREW LICENSE PLATE TO BRACKET
235
SCREW , Replaced By: N304017006020
237
NUT BALL PIVOT TO LEVER
245
SPRING
250
PRESSURE PLATE CLUTCH BRAKE
255
BRAKE LINING
257
RIVET CLUTCH BRAKE
257
RIVET
265
BRAKE DISC
270
GUIDE
270
GUIDE , Replaced By: A3432540216
275
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
277
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
285
SPACER TUBE GUIDE TO BELL HOUSING
287
FRICTION PIECE
289
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
291
SCREW , Replaced By: N304017010055
291
SCREW , Replaced By: N304017010050
300
RELEASE COLLAR
310
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
312
SEAL RINGTO 000 550 00 83
320
SPRING LOCK RELEASE COLLAR TO RELEASE YOKE
325
RELEASE BEARING
330
HOSE RELEASE BEARING LUBRICATION 170 MM
335
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
337
UNION SCREW RELEASE COLLAR LUBRICATION
345
BULKHEAD FITTING RELEASE COLLAR LUBRICATION
347
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
349
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
351
GREASE NIPPLE FOR SPRING
360
PROTECTIVE PLATE BOTTOM
365
WASHER RADIATOR TO RUBBER MOUNTING
365
WASHER , Replaced By: N000125010532
367
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
369
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SLEEVE CLUTCH PRESSURE PLATE
999
PRESSURE PLATE
999
SPRING SUSPENDED BELOW LEAF SPRING
999
SCREW , Replaced By: N000960018109
999
SCREW , Replaced By: N308676018009
999
LOCK PLATE RELEASE LEVER TO SHAFT
999
LOCK PLATE LEVER TO BRACKET
999
LOCK WASHER BELL HOUSING TO TRANSMISSION
