Поз.
Артикул
Описание
63
STRAP OIL BATH AIR CLEANER,ON L 335.0 UPTOCHASSIS 006235,ON LA 335.1 UP TO CHASSIS 002744,ON L 336.0 UP TO CHASSIS 600133 CONTINUED ON FOOT NOTE 004
63
STRAP OIL BATH AIR CLEANER,ON L 335.0 UPTOCHASSIS 006235,ON LA 335.1 UP TO CHASSIS 002744,ON L 336.0 UP TO CHASSIS 600133 CONTINUED ON FOOT NOTE 004
72
STRAP ,5 386581
81
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
81
SCREW , Replaced By: N304017008027
90
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
90
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
90
NUT , Replaced By: N913004008001
99
SCREW BRACKET TO SIDE MEMBER
99
SCREW , Replaced By: N304017010002
99
SCREW BRACKET TO SIDE MEMBER
99
SCREW BRACKET TO SIDE MEMBER
99
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
108
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
116
WASHER , Replaced By: N009021010209
116
WASHER BRACKET TO COVERING
116
WASHER , Replaced By: N007349010007
116
WASHER STRUT TO CROSS MEMBER
124
NUT , Replaced By: N910113010000
124
NUT STRAP TO BRACKET
132
SCREW , Replaced By: N304017008021
132
SCREW PIPE CLAMP
132
SCREW PIPE CLAMP
132
SCREW , Replaced By: N304017008034
132
SCREW BRACKET TO CROSS CONNECTION STRUT
140
WASHER , Replaced By: N009021008213
140
WASHER BRACKET TO LEFT SIDE MEMBER
140
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
148
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
156
BRACKET , Replaced By: A3365280640
156
BRACKET ,ON L 335.0 UPTOCHASSIS 006235,ON LA 335.1 UP TO CHASSIS 002744,ON L 336.0 UP TO CHASSIS 600133 CONTINUED ON FOOT NOTE 004
156
BRACKET ,ON L 335.0 UPTOCHASSIS 006235,ON LA 335.1 UP TO CHASSIS 002744,ON L 336.0 UP TO CHASSIS 600133 CONTINUED ON FOOT NOTE 004
156
BRACKET STRAP TO SUPPORT,5 386581
164
BRACKET STRAP TO SUPPORT,5 386581
172
SCREW , Replaced By: N304017008021
172
SCREW PIPE CLAMP
172
SCREW , Replaced By: N304017008034
172
SCREW BRACKET TO CROSS CONNECTION STRUT
180
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
188
WASHER , Replaced By: N000125008443
188
WASHER EXHAUST MUFFLER TO STRAP
188
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
196
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
204
NUT , Replaced By: N913004008001
204
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
204
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
212
SCREW , Replaced By: N304017008034
212
SCREW BRACKET TO CROSS CONNECTION STRUT
212
SCREW BRACKET TO CROSS CONNECTION STRUT
220
WASHER , Replaced By: N009021008213
220
WASHER BRACKET TO LEFT SIDE MEMBER
220
WASHER BRACKET TO LEFT SIDE MEMBER
228
BRACKET
236
SCREW , Replaced By: N304017008021
236
SCREW PIPE CLAMP
244
WASHER EXHAUST MUFFLER TO STRAP
244
WASHER , Replaced By: N000125008443
252
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
252
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
252
NUT , Replaced By: N913004008001
999
AIR CLEANER OIL BATH
999
STRAP OIL BATH AIR CLEANER
999
BEARING BRACKET OIL BATH AIR CLEANER
999
AIR INTAKE PIPE
999
AIR INTAKE PIPE
999
BUSHING INTAKE MANIFOLD
999
BRACKET OIL BATH AIR CLEANER
999
COVERING INTAKE MANIFOLD
999
SHIM
